10W SOLAR
BATTERY CHARGER
MAINTAINER
User Guide
Model: RSP10BM
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 03
SPECIFICATIONS 04
PACKAGE CONTENTS 04
INSTALLATION 05
INTELLIGENT CHARGING TECHNOLOGY 08
WARRANTY 09
- 01 - - 02 -
IMPORTANT SAFETY INSTRUCTIONS
PACKAGE CONTENTS
SPECIFICATIONS
Please read the User Guide carefully before installation.
IMPORTANT SYMBOLS
Indicates potentially dangerous conditions that could result in personal
injury
Indicates conditions or practices that could result in damages to the
unit or other equipment
Indicates procedures or functions that are important for proper and
safe operation of the unit and/or other equipment
CAUTION
DO NOT operate the unit if it has been smashed, squashed, pierced, or
otherwise damaged in anyway.
The unit is designed to withstand splashes and spills but is not fully
waterproof. DO NOT submerge the unit in water or leave it in the rain.
CAUTION
Dispose of the unit according to the local recycling and environmental
regulations.
CAUTION
DO NOT step, walk, stand, or jump on the unit. Localized heavy loads may
cause variances of micro-cracks on the solar cells, which will ultimately
compromise the reliability of the unit.
CAUTION
Clean the surface of the solar battery charger maintainer as necessary for
optimal performance.
WARNING
DO NOT disassemble the unit or remove any attached components.
Incorrect reassembly may result in a risk of fire or electric shock.
WARNING
Keep the unit out of reach of children unless supervised by an adult.
WARNING
WARNING
The unit is only compatible with 12V lead-acid batteries. DO NOT connect it
to other types of batteries or batteries with nominal voltages other than 12V.
Doing so ma y cause irre ersible damages v to the uni and or ba ert / tt y explosion.
WARNING
To reduce the risk of a battery explosion, please follow the instructions
published by the battery manufacturer and review the cautionary markings
on the battery carefully.
WARNING
DO NOT place the unit on a surface constructed from combustible material.
Keep the unit away from explosives and corrosive substances.
WARNING
NOTE
NOTE
1 x Renogy 10W Solar Battery Charger Maintainer
1 x SAE to Ring Terminal Cable
1 x SAE to Alligator Clip Cable
1 x SAE to Cigarette Lighter Plug Cable
8 x Suction Cups
1 x User Guide
Rated Maximum Power
Open Circuit Voltage
Short Circuit Current
Optimum Operating Voltage
Optimum Operating Current
Operating Temperature Range
Output Connector
Dimension
Weight
10W
21.6V
0.61A
18V
0.56A
-4~140 / -20~60
SAE
7.9 x 16.1 x 0.1 inch / 200 x 410 x 3 mm
15.8 oz / 447 g
- 03 - - 04 -
Solar Panel
MPPT Charge Controller
Boost Voltage
Float Voltage
Maximum Input Current
Maximum Output Current
Operating Temperature Range
14.8V
13.55V
0.7A
0.8A
-4~185 / -20~85
INSTALLATION CONNECTING DIRECTLY TO THE BATTERY
The solar battery charger maintainer MUST be disconnected from the
battery or cigarette lighter port when starting the engine or driving the
vehicle. Electric surges from the alternator when starting and running may
damage the solar battery charger maintainer.
CAUTION
DO NOT leave the solar battery charger maintainer connected and
unattended for extended periods of time. Check the battery status frequent-
ly for safe operation.
WARNING
Place the solar battery charger maintainer as far away from the battery as
the adapter cables permit. DO NOT place it directly above the battery.
WARNING
The solar battery charger maintainer is designed to compensate for the
battery self-discharge. Please do not rely on it for a full charge.
NOTE
Check the polarity of the battery terminals. The positive (POS, P, +) terminal usually has
a larger diameter than the negative (NEG, N, -) terminal.
- 05 - - 06 -
Connect the included SAE to Ring Terminal Cable or SAE to Alligator Clip Cable to the
battery.
Connect the SAE to Ring Terminal Cable or SAE to Alligator Clip Cable to the solar battery
charger maintainer.
Place the solar battery charger maintainer, facing due south (or north), in the path of the
sun. Make sure that no shadows are cast on the solar battery charger maintainer.
If the battery is installed in the vehicle, the vehicle ground type must be identified. For a
negative-grounded vehicle, first connect the positive (red) alligator clip or ring terminal to
the positive (POS, P, +) terminal of the battery, and then connect the negative (black)
alligator clip or ring terminal to the vehicle chassis or engine block away from the battery.
For a positive-ground vehicle, first connect the negative (black) alligator clip or ring
terminal to the negative (NEG, N, -) terminal of the battery, and then connect the positive
(red) clip to the vehicle chassis or engine block away from the battery.
If the battery is outside the vehicle, a 24 inch (610mm) 6 AWG (13 mm2) insulated battery
cable must be first connected to the negative (NEG, N, -) battery terminal. Then connect
the positive (red) alligator clip or ring terminal to the positive (POS, P, +) terminal of the
battery and connect the negative (black) alligator clip or ring terminal to the free end of the
battery cable away from the battery.
Electric shock can occur if the adapter cable is damaged. DO NOT use a
damaged adapter cable to maintain or charge the battery. Position the
adapter cable properly to reduce the risk of damage by the hood, door, or
hot engine parts.
WARNING
