Owner’s Guide

v1.0

English

Deutsch

Italiano

Français

English

Technical Support

Should you encounter problems using this product, please refer to

the troubleshooting section on page 20 of this owner’s guide.

Alternatively, call Revo technical support on :

UK 01555 666 161

From outside the UK + 44 1555 666 161

Alternatively, e-mail support@revo.co.uk or visit the troubleshooting

section of our website at: www.revo.co.uk

Environmental Info

PRODUCT DISPOSAL INSTRUCTIONS (WEEE DIRECTIVE)

The symbol shown here and on the product means that it is classed

as Electrical or Electronic Equipment and should not be disposed with

other household or commercial waste at the end of its working life.

The Waste of Electrical and Electronic Equipment (WEEE) Directive

(2002/96/EC) has been put in place to recycle products using best

available recovery and recycling techniques to minimise the impact

on the environment, treat any hazardous substances and avoid the

increasing landﬁ ll.

For more information please contact your local authority or the

retailer where the product was purchased.

RoHS COMPLIANT & CE MARK

This product has been designed to comply with international

directives on the Restriction of Hazardous Substances (RoHS) and

has been designed and type-tested to comply with EU

requirements and carries a CE mark.

SAFETY WARNINGS

• Do not operate this radio near water

• Do not remove screws or casing parts

• Use only the power supply unit supplied

• Avoid small objects and liquids from entering the product

Warranty

Revo Technologies Ltd warrants to the end user that this

product will be free from defects in materials and workmanship

in the course of normal use for a period of one year from the

date of purchase. This guarantee covers breakdowns due

to manufacturing faults and does not apply in cases such as

accidental damage, general wear and tear, user negligence,

modiﬁ cation or repair not authorised by Revo Technologies Ltd.

To register your purchase please visit www.revo.co.uk

Copyrights and

Acknowledgements

No part of this publication may be copied, distributed, transmitted

or transcribed in any form or by any means, electronic, mechanical,

magnetic, manual or otherwise, without the permission of Revo

Technologies Limited.

REVO and PiXiS IR are trademarks or registered trademarks of

Revo Technologies Ltd.

Revo Technologies Ltd

The Inox Building, Caldwellside, Lanark,

Scotland, United Kingdom, ML11 7SR

Tel: 01555 66 61 61 Int. Tel: +44 1555 66 61 61

Fax: 01555 66 33 44 Int. Fax: +44 1555 66 33 44

Email: enquiries@revo.co.uk Website: www.revo.co.uk

Disclaimer

Revo Technologies Limited makes no representation or

warranties with respect to the content of this publication, and

speciﬁ cally disclaims any implied warranties of merchantability

or ﬁ tness for any particular purpose. Further, Revo Technologies

Limited reserves the right to make changes to this publication from

time to time, without notiﬁ cation to any person or organisation.

English

Contents

Power Supply

Support, Warranty and Environmental Information

Contents / Welcome / Unpacking PiXiS / Power Supply

Guiding Principles / Home Screen

Second–Level Navigation

Internet Setup

Internet Radio Mode

Finding Stations

Podcasts / Listen Again / Presets

Internet Radio Portal

Network Audio Mode

Network Audio Setup

Network Audio Finding Tracks

Alarms

Alarm Snooze / Sleep / USB Update

System Settings

Miscellaneous Settings

Troubleshooting

Welcome

Thank you for purchasing PiXiS. We are

sure that it will provide you with years

of enjoyment and reliable service.

This guide has been designed to

quickly get you up and running

with your radio, offer guidance on

the product’s features and provide

information on operation, safety,

warranty details and troubleshooting.

Unpacking PiXiS

Carefully remove your radio from

its packaging and remove the

other items from the box.

The box should contain the following:

• PiXiS touchscreen radio

• Multi-region power supply with adaptors

for UK, Europe, USA and Australia

• Operating guide

• Warranty Card

If any items are missing or damaged, please

contact your point of purchase or call

Revo directly on +44 (0) 1555 66 61 61

Your PiXiS radio is supplied with a multi-region power supply, meaning

that it can be operated in a number of countries around the world.

Simply choose the correct adaptor for your country from the

selection supplied, then follow the instructions opposite.

UK EURO U.S.A AUSTRALIA

PUSH
