This water heater must be installed and serviced by a qualified person.
Please leave this guide with the householder.
Owner s Guide ’
and
Installation Instructions
Solar Loline Water Heater
WARNING: Plumber Be Aware –
Use copper pipe ONLY. Plastic pipe MUST NOT be used.
It is a requirement of a solar water heater installation that all pipe work be in copper
and not plastic, due to the effects of high water temperatures and pressures.
PATENTS
This water heater may be protected by one or more patents or registered designs in the name of
Rheem Australia Pty Ltd.
TRADE MARKS
® Registered trademark of Rheem Australia Pty Ltd.
™ Trademark of Rheem Australia Pty Ltd.
Note: Every care has been taken to ensure accuracy in preparation of this publication.
No liability can be accepted for any consequences, which may arise as a result of its application.
WARNING: Plumber Be Aware –
The solar hot and solar cold pipes between the solar storage tank and the solar collectors MUST BE
of copper. All compression fittings must use brass or copper olives.
MUST The full length of the solar hot and solar cold pipes BE insulated.
The insulation must:
of a closed cell type or equivalent, suitable for a solar water heating application and capable be
of withstanding the temperature of the water generated by the solar collectors under stagnation
conditions
The specification of the chosen insulation material should be checked with the insulation
manufacturer prior to installation as different materials may vary in temperature tolerance.
be at least 13 mm thick, however thicker insulation may be required to comply with the
requirements of AS/NZS 3500.4
be weatherproof and UV resistant if exposed
extend through any penetrations in the eaves, ceiling and roof
ver valves and fittings in the solar hot and solar cold pipe work co
be fitted up to and cover the connections on both the solar storage tank and the solar collectors.
Note: Failure to observe these requirements also increases the risk of freeze damage.
Uninsulated pipe work, including concealed in cavities and roof spaces or where it may be in contact
with a metal roof, may lead to freeze damage. There is NO WARRANTY for freeze damage if the solar
hot and solar cold pipes are not insulated in accordance with the installation instructions.
The insulation is essential to assist in providing freeze protection, will offer corrosion protection to a
metal roof against water runoff over the copper pipes, assist in avoiding accidental contact with the
solar pipe work as very high temperature water can flow from the solar collectors to the solar storage
tank, also reduce pipe heat losses. and
The insulated copper pipe work:
should be fixed at suitable locations to prevent or reduce the possibility of noise from water
hammer and vibration from occurring
is not to be placed or installed in contact with plastic pipe work.
Likewise, plastic pipe work is not to be placed or installed in contact with the insulated copper
pipe work after the collector circuit is installed.
MUST NOTPlastic pipe be used, as it will not withstand the temperature and pressure of the water
generated by the solar collectors under stagnation conditions. Extremely high water temperatures of
up to 150°C for non-selective surface collectors and greater than 200°C for selective surface collectors
and high water pressures exceeding 1000 kPa can be generated under these conditions. Plastic pipe
cannot withstand these temperatures and pressures and be used. Failure of plastic pipe MUST NOT
can lead to the release of high temperature water and cause severe water damage and flooding.
A non-return valve installed on the cold water line to the solar storage tank MUST BE AFTER the cold
water branch to a temperature limiting device. Due to the higher water temperatures generated under
certain conditions in the solar collectors of this solar water heater, an additional effective back-flow
prevention device also should be used as an extra safeguard. Valve manufacturer RMC recommends
Dual Check Valve model N7155, as being suitable for this application.
Plumber: It is important to refer to and read in full the complete
“Warning: Plumber – Be Aware” statement commencing on page . 38
3
CONTENTS
HOUSEHOLDER We recommend you read pages 4 . –to 22
The other pages are intended for the installer but may be of interest.
About Your Water Heater ............................................................................................................ 4
Regular Care .............................................................................................................................. 13
Water Supplies ........................................................................................................................... 16
Save A Service Call ................................................................................................................... 19
Installation System –................................................................................................................. 23
Installation Solar Storage Tank –............................................................................................. 25
Installation Solar Control Unit –............................................................................................... 32
Installation Solar Collectors –.................................................................................................. 35
Connections Plumbing –.......................................................................................................... 40
Connections Electrical –........................................................................................................... 43
Commissioning .......................................................................................................................... 46
Draining The Solar Collectors .................................................................................................. 49
Draining The Water Heater ....................................................................................................... 49
Warranty ..................................................................................................................................... 51
