Sida 1/36
AM25600
AM22870
AM22860
AM25600
AM22870
AM22860
THREE SPEED
AIR MOVER
FOR QUESTIONS OR INFORMATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the US and Canada 
01-800-701-9811 from Mexico
www.RIDGIDvacs.com
Part No. SP7019 Printed in Mexico
OWNER’S MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE
WARNING:
To reduce the risk of injury, the user must read and understand the owner’s manual
before using this product.
!
Thank you for buying a RIDGID product. • Español - página 13
• Français - page 25
SP7019 3-Speed Air Mover.qxp_SP7019 Air Mover 2/23/17 11:19 AM Page 1
2
Table of Contents
Section Page
Important Safety Instructions . . . . . . .2-3
Motor Specifications and Electrical
Requirements . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking Carton
Contents . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . . 5-6
Section Page
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance . . . . . . . . . . . . . . . . . . . . . 8
Wiring Diagram . . . . . . . . . . . . . . . . . . . 9
User Servicing/Troubleshooting
Instructions . . . . . . . . . . . . . . . . . . 10
Repair Parts . . . . . . . . . . . . . . . . . . . . 11
Warranty . . . . . . . . . . . . . . . . . . . . . . . .12
IMPORTANT SAFETY INSTRUCTIONS
Safety is a combination of using common
sense, staying alert, and knowing how your
Air Mover works.
Safety Signal Words
DANGER: Indicates a hazardous
situation which, if not avoided, resultwill
in death or serious injury.
WARNING: Indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
When using your Air Mover, always follow
basic safety precautions including the
following:
WARNING
- To reduce the risk of fire,
electric shock, or injury:
• Read and understand this manual and
all labels on the Air Mover before
operating.
• Use only as described in this manual.
• To reduce the risk of electric shock,
do not expose to rain, or immerse in
or use in standing water. Store and use
indoors only.
• Use only with GFCI-protected outlets.
• When storing, do not stack Air Movers
more than 2 units high.
• Do not use an extension cord with this
Air Mover.
• Electrical appliances can ignite
flammable vapors or dust. Do not use
near combustible liquids, gases,
or dusts.
!
!
!
!
• Do not leave plugged into outlet when
not in use or when servicing. Turn off
before unplugging.
• To reduce the risk of stirring up and
inhaling toxic vapors, do not use near
toxic or hazardous materials.
• Never operate with safety grills removed.
• This unit’s motor has an automatically-
operated thermal protective device
which may shut down the unit during
operation and can restart at any
moment. Unplug before servicing or
cleaning.
• Do not use with solid state speed
control device.
• This Air Mover is not intended for use by
persons (including children) with
reduced physical, sensory, or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
• Do not unplug by pulling on cord.
To unplug, grasp the plug, not the cord.
• Do not use with damaged cord, plug,
or other parts.
• If your Air Mover is not working as it
should, has missing parts, has been
dropped, damaged, left outdoors,
or dropped into water, call customer
service.
• Do not pull or carry by cord, use cord as
handle, close a door on cord, or pull
cord around sharp edges or corners.
Keep cord away from heated surfaces.
SP7019 3-Speed Air Mover.qxp_SP7019 Air Mover 2/23/17 11:19 AM Page 2
3
Motor Specifications and
Electrical Requirements
SAVE THIS MANUAL
This Air Mover is provided with a 3-speed,
115 volt, 60 Hz induction motor with a
grounding conductor. It is thermally
protected and will automatically shut down
if over-heated. Once it cools, the motor
will restart automatically if not unplugged.
In the event of a malfunction or
breakdown, grounding provides a path
of least resistance for electric current
to reduce the risk of electric shock.
CAUTION:
• This Air Mover has an automatic
motor shutoff device; it may
restart without notice. To reduce
the risk of injury, unplug before
servicing.
• Do not use an extension cord with
this fan.
• Do not run cord under carpeting.
Do not cover cord with throw rugs,
runners, or similar cov
erings.
Do not route cord
under furniture or
appliances
. A
rrange co
rd aw
ay from
traffic
area and where it will not be
trippe
d ov
er
.
• Do not handle plug, switc
h, or the
Air Mover with wet han
ds
.
• Observe the 8 Amp maximum on-board
convenience outlet
ratin
g w
hen
interconnec
ting units together.
• Do not put any object into air intake
openings
.
• Keep hair
, loose clothing, fingers
,
and all parts
of body a
way from
openings
and moving parts.
•Direct air discharge only at work
area.
Do not direc
t air at bystanders.
•All disass
embly and repairs sh
ould be
perf orm
ed by qualified
personnel.
• Do not op erate any fa
n with a
damaged cord or plug. Discard fan or
return to an authorized service facility
for
examination
and/or rep air.
Observe the following warnings that
appear on the motor housing of your
Air Mover:
CAUTION:
• For dusty operations, wear dust mask.
• Do not move or carry Air Mover when it
is operating.
• Only operate on a level and stable
surface to prevent it from falling and
possibly causing injury or damage to unit.
!
WARNING: To reduce the risk of
electric shock, connect only to a
GFCI protected outlet. Do not expose
to water or rain. Indoor use only.
!
!
WARNING: Do not exceed
8 Amps through the on-board
convenience outlets.
!
WARNING: TO REDUCE THE RISK
OF TIP-OVER DURING STORAGE,
STACK 2-HIGH ONLY.
!
This Air Mover is equipped with an electric
cord having an equipment grounding
conductor and a grounding plug. The plug
must be plugged into a matching outlet
that is properly installed and grounded in
accordance with all local codes and
ordinances.
Do not modify the plug provided. If it will
not fit the outlet, have the proper outlet
installed by a qualified electrician.
SP7019 3-Speed Air Mover.qxp_SP7019 Air Mover 2/23/17 11:19 AM Page 3
