Sida 1/28

Serial Number: Date of Purchase:

Installation & Operation

INTERACTIVE

SIGNAL PROCESSOR

3SIXTY.3

Quick Setup Guide

1. Install 3Sixty.3 software

2. Open 3Sixty.3 Software (See pg 9)

3. Connect 3Sixty.3 USB cable to 3Sixty.3 and then to the PC. (See pg 9)

4. Open the 3Sixty.3 user interface (UI). A pop up window will appear telling you the unit is not conﬁgured.

Click “OK” (See pg 10)

5. If the conﬁguration pop up window above does not appear telling you that the unit is not conﬁgured,

open the “Device” tab and select “Conﬁguration” in the top left corner. (See pg 9)

6. When the input conﬁguration page appears, select your source interface type and label your input

channels. Click “Next” (See pg 15)

7. When the output conﬁguration page appears, label your output channels if one or more channels is not

being used select “Not Connected”. Click “Next” (See pg 15)

8. When the input channel summing page appears, select the output channel from the vehicle illustration,

then select the input(s) you would like to use/sum to create that output channel. After assigning ALL

output channels there inputs, Click “Next” (See pg 15)

9. When the assign source presets page appears, select the preset(s) you would like to assign to each

source. Click “Next” (See pg 16)

10. When the input level setup prompt appears, insert the 3Sixty.3 setup disk and play track #1 at max

volume and follow the on screen directions. Click “Next”(Outputs will be muted) (See pg 16)

11. When the adjust source level appears, reduce the volume of the source until all the level meters are

green. Click “Next” (The 3Sixty.3 is not looking for a hard clipped signal you would typically see when

level setting an ampliﬁer) (Make a note of the MAXIMUM volume level on the source unit achieved

keeping the level meters green for future steps) (See pg16)

12. When the input attenuator controls appears, select “Auto Range” to automatically match the input

voltage, to the input voltage range of the DSP. (See pg 16)

13. a) If using a low level input, the mute warning page will appear prompting you to reduce your

volume. Click “Finish” and go to Step #15 (See pg 17)

b) If using a high level input, the input denormalization setup prompt appears, use the 3Sixty.3 setup

disk and play track #2 at half of the noted source volume in step #11. Click “Next” (See pg 17)

14. During the input normalization page, select “Auto Normalize”. This may take up to 5 min. Once

completed, Click “Next” (See pg 17)

15. The mute warning page will appear prompting you to reduce your volume, and Click “Finish”. Device

setup is now complete. Please proceed with system tuning.

16. Select the crossover type, class, slope, and frequencies for each channel. (See pg 13 & 21)

17. Level set the ampliﬁers to the main source unit, then adjust each additional source level. (See pg 14

& 22)

18. Select the time delay for each channel. (See pg 14 & 28)

19. Adjust the EQ for each channel, for each source or preset. (See pg 14 & 28)

20. After adjusting the EQ, level set the ampliﬁers to the main source unit, then adjust each additional

source level. (See pg 22)

21. Under the ”File” tab select “Save File”. (See pg 10)

Dear Customer,

Congratulations on your purchase of the world’s ﬁnest brand of car audio signal

processors. At Rockford Fosgate we are fanatics about musical reproduction at

its best, and we are pleased you chose our product. Through years of engineering

expertise, hand craftsmanship and critical testing procedures, we have created a

wide range of products that reproduce music with all the clarity and richness you

deserve.

For maximum performance we recommend you have your new Rockford Fosgate

product installed by an Authorized Rockford Fosgate Dealer, as we provide special-

ized training through Rockford Technical Training Institute (RTTI). Please read

your warranty and retain your receipt and original carton for possible future use.

Great product and competent installations are only a piece of the puzzle when

it comes to your system. Make sure that your installer is using 100% authentic

installation accessories from Rockford Fosgate in your installation. Rockford Fos-

gate has everything from RCA cables and speaker wire to power wire and battery

connectors. Insist on it! After all, your new system deserves nothing but the best.

To add the ﬁnishing touch to your new Rockford Fosgate image order your Rock-

ford accessories, which include everything from T-shirts to jackets.

Visit our web site for the latest information on all Rockford products;

www.rockfordfosgate.com

or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other countries, call

+001-480-967-3565 or FAX +001-480-966-3983.

Table of Contents

If, after reading your manual, you still have questions regarding this prod-

uct, we recommend that you see your Rockford Fosgate dealer. If you need

further assistance, you can call us direct at . Be sure to 1-800-669-9899

have your serial number, model number and date of purchase available

when you call.

Safety

This symbol with “WARNING” is intended

to alert the user to the presence of important

instructions. Failure to heed the instructions

will result in severe injury or death.

This symbol with “CAUTION” is intended to

alert the user to the presence of important

instructions. Failure to heed the instructions

can result in injury or unit damage.

•To prevent injury and damage to the unit, please read and follow the

instructions in this manual. We want you to enjoy this system, not get

a headache.

•If you feel unsure about installing this system yourself, have it installed

by a qualiﬁed Rockford Fosgate technician.

•Before installation, disconnect the battery negative (-) terminal to

prevent damage to the unit, ﬁre and/or possible injury.

Contents of Carton

•3Sixty.3 Interactive Signal Processor

•Bluetooth Dongle

•Remote Level(s) Controller

•Remote Level Control Cable (20ft)

•Power Connector (4 pin)

•High Level Input Connection (16 pin)

• Installation & Operation Manual

•Multimedia Setup Disc (CD)

•USB cable (20ft)

Introduction

Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Speciﬁcations subject to change without notice.

PRACTICE SAFE SOUND

Continuous exposure to sound pressure levels over 100dB may cause

permanent hearing loss. High powered auto sound systems may

produce sound pressure levels well over 130dB. Use common sense

and practice safe sound.

2 Introduction

3 Speciﬁcations

4-5 Design Features

6-9 Installation

Installation Considerations

Input Connections

Remote Connections

Output Connections / Software Installation

9-11 Initial Setup

File / Device Tabs

Presets / Preferences

12-14 EQ Setup

EQ Controls

15-17 High Level Sample System

18-20 Low Level Sample System

21-23 EQ Sample System

24 Final Setup

25 Troubleshooting

26 Troubleshooting Noise

27 Limited Warranty Information

28 Quick Setup Guide

Operating Voltage 9 - 16 VDC

Recommended Fuse 2 A

Max REM Out Current 1 A

Input Impedance (Low Level) 10K Ohm

High Level Turn On DC Voltage 4 - 16 VDC

Input Sensitivity

Low Level (RCA) 0.1V - 2V

High Level 0.1V - 28V

AUX 0.1 - 1V

Frequency Response 20 - 20K +/- 0.5dB

Max Output Voltage 8 VAC @ 0.1% THD

THD+N <0.01 @ 1KHz

Signal to Noise Ratio (RCA) >105 dBA (A weighted)

Signal to Noise Ratio (Optical) >110 dBA (A weighted)

Signal to Noise Ratio (AUX) >105 dBA (A weighted)

Common Mode Rejection Ratio >70

Channel Separation >73dB @ 1KHz

Specications

CEA 2006

Measurements on Rockford Fosgate processors conform to CEA-2006 industry standards.

Channel Front Front2 Rear Sub

Interval (oct) Adjustable

Bands 31 31 31 31

Delay 0 - 10 msec

Q Range 0.1 - 6.0

Frequency 20 -20KHz

Presets Assignable 4

Crossover Setting AP/HP/LP/BP/Shelf

Slope (dB/oct) 12 / 24 / 36 / 48

Range (Hz) 20 - 20kHz

Class Linkwitz / Bessel / Butterworth / Chebychev

Length 5.0” 12.75 cm

Width 9.3” 23.6 cm

Height 1.7” 4.3 cm

Technical Speciﬁcations

Dimensions

Crossover

Equalizer

9.3"

(23.6)

5.0"

(12.75)

1.7"

(4.3)

RESET

WIRELESS

USB RFLINK ACC OPT IN

FRONT FRONT2 REAR SUB

OUTPUTS

UNBALANCED

BALANCED

2 4
