Sida 1/63
T U R N
O V E R
1998-2013 Harley-Davidson®
PMX-HD9813 Radio Tuning Guide for
STAGE1, STAGE2 & STAGE3 Systems.
0 9 -03-2019 E r i c R u s s e l l
1 2 2 0 - 7 2 8 8 5 - 0 1 - A
7 BAND EQ: FLAT
CROSSOVER:
FRONT HPF: 60Hz @ 12dB/Oct.
REAR HPF: 60Hz @ 12dB/Oct.
SUB LPF: APF
PU N C H EQ: GAIN 0
FLAT: Use on non-Rockford Fosgate systems.
ST AGE1:
Upper Fairing
ST AGE2:
Upper Fairing + Baglid s
RADIO DEFAU LTS
ST AGE3:
Upper Fairing + TourPak
Upper Fairing + TourPak + Baglid s INTERNAL AMPLIFIER: ON
HD9813RG-STAGE1
HD9813RG-STAGE2
HD9813RG-STAGE3
HD9813RGU-STAGE1
HD9813RGU-STAGE2
HD9813RGU-STAGE3
HD9813SG-STAGE1
HD9813SG-STAGE2
HD9813SG-STAGE3
HD9813SGU-STAGE1
HD9813SGU-STAGE2
HD9813SGU-STAGE3
AUDIO KIT PRESE T :
These PMX-HD9813 tunings are
independently optimized ONLY
for Rockford Fosgate TMS speaker
systems due to their unique
frequency response. They are not
for use with other speaker brands.
1) P ress & Hold MEN U to
access SETTINGS.
2) Rotate VOLUME,
press to select AUDIO.
3) Rotate VOLUME, press to
select AUDI O KIT P RESET.
4) Radio will automatically
reboot & load preset.
TURN
OVER
1998-2013 Harley-Davidson
®
TM400X4ad Amp Tuning Guide for PMX-HD9813
on STAGE2 & STAGE3 Systems.
For other radi os, refer to Knowledge Base Answer ID #1355.
REAR INPUT LEVEL: 9:00 (1/4)
Matches the amp to the radio.
Tells the amp where to “cli p.”
FRONT INPUT LEVEL: 8:00 to 9:00
When using baglids or TourPak ,
reduce fai ring speaker output
by tri mmi ng front gain so fr ont
& rear are equally balanced.
FRONT & REAR EQUALIZER: 12:00
Works with PM X-HD9813 DSP
to pr ovide excepti onal
bass & treble response.
INPU T SWITCH: 4CH
Number of i nputs to feed amp.
New harness supports
integrated 4-channel
front/rear audio.
Must use rear speak er
harness on PM X-HD9813.
CROSSOVER FREQUENCY: 50Hz
Tells amp what fr equencies to pass.
Motorcycles use thi s as a “bass blocker”
to pr event subwoofer frequenci es from
damagi ng fai ri ng and bagli d speakers.
(latched to HP/AP/LP swi tch)
CROSSOVER SWITCH: HP (Hig h-Pass)
Type of crossover needed.
(works with crossover frequency dial)
[HP (High-Pass) allows frequenci es above to pass]
[AP (All-P ass) allows all frequencies to pass]
[LP (L ow-Pass) allows frequencies below to pass]
TURN-ON O.K.
blue remote wire not required
0 9 -0 3 - 2 0 1 9 E r i c R u s s e l l
1 2 2 0 - 7 2 8 8 5 - 0 1 - A
RADIO O.K.
no flash required
Ro ckfor d Fos gate
PMX- HD 981 3
