RFK-HD14
2014+
HARLEY-DAVIDSON®
AMPLIFIER INSTALL KIT
Installation & Operation
Serial Number: Date of Purchase:
Installation assistance availible at:
www.rockfordfosgate.com/rftech
R O C K F O R D F O S G A T E . C O M
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford
Fosgate product installed by an Authorized Rockford Fosgate Dealer,
as we provide specialized training through Rockford Technical Training
Institute (RTTI). Please read your warranty and retain your receipt and
original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! After all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Content
If, after reading your manual, you still have questions regarding this prod-
uct, we recommend that you see your Rockford Fosgate dealer. If you need
further assistance, you can call us direct at . Be sure to 1-800-669-9899
have your serial number, model number and date of purchase available
when you call.
Safety
This symbol with “WARNING” is intended
to alert the user to the presence of important
instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
can result in injury or unit damage.
• To prevent injury and damage to the unit, please read and follow the
instructions in this manual. We want you to enjoy this system, not get
a headache.
• If you feel unsure about installing this system yourself, have it installed
by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, fire and/or possible injury.
Introduction
©2014 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered trademarks of Rockford
Corporation in the United States and/or other countries. Ultra Classic ®, Electra Glide®, Street Glide®, Tri Glide®, Road Glide®, Road Glide Ultra®, CVOTM and
Harley-Davidson® are registered trademarks of Harley-Davidson, Inc, and if used or implied are for reference only. There is no affiliation between Harley-
Davidson, Inc., and Rockford Corporation. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
2 Introduction
3-4 Contents
5 Warranty
Installation Considerations
This section focuses on some considerations for installing your motorcycle
amplifier installation kit. This manual will illustrate the installation of two
different fairing styles offered by Harley-Davidson® from the production
years ranging from 1998 to 2013. (Ultra Classic®, Electra Glide®, Street
Glide®, Tri Glide®, Road Glide®, Road Glide Ultra® and CVOTM.)
If you feel unsure about installing this system yourself, have it installed by
a qualified technician.
Before installation, disconnect the battery negative (-) terminal to prevent
damage to the unit, fire and/or possible injury.
Before beginning any installation, follow these simple rules:
• Be sure to carefully read and understand the instructions before
attempting to install this motorcycle audio kit.
• Consult your motorcycle’s service manual for model specific
information. Models may differ from year to year depending on factory
options and aftermarket accessories added.
• This motorcycle amplifier installation kit is specifically designed to
work with Rockford Fosgate’s POWER and PUNCH® compact chassis
amplifiers in both 2 or 4-channel configurations.
• With the addition of an amplifier, be sure that your current charging
system is in proper working order.
• Utilize a blanket or fender cover to protect the front fender from tools
or any other items that may be accidentally dropped while removing
the fairing.
• Visit rockfordfosgate.com for more comprehensive installation
videos and product information.
3
Contents
Contents
• (1)Power Harness
• (1)HD Radio Interupt Harness
• (2) Speaker Output Y-Adapter
• (2) Boom amp Bypass Harness
• (1) CVO 6 Speaker bypass (left)
• (1) CVO 6 Speaker bypass (right)
• (8) Wire Zip Tie Wraps
• (4) Amp Screws
• (1) Road Glide® Amp Mounting Brackets
• () Road Glide® Amp Bracket Bolts
• (4) Road Glide® Heat Sink Screws
• (4) Street Glide® Heat Sink Screws
• (4) Street Glide® Heat Sink Spacers
• (1) Amp Heat Sink
