Sida 1/8
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
rockfordfosgate.com
112719 1230-72888-01-A Printed In China
RGB LIGHT CONTROLLER
PMX-RGB
Installation & Operation
Installation assistance available at:
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand crasmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rock-
ford Fosgate product installed by an Authorized Rockford Fosgate
Dealer. Please read your warranty and retain your receipt and original
carton for possible future use.
Great product and competent installations are only a piece of the
puzzle when it comes to your system. Make sure that your installer is
using 100% authentic installation accessories from Rockford Fosgate in
your installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer
all, your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image, order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all
other countries, call +001-480-967-3565 or FAX +001-480-966-
3983.
Table of Content
If, aer reading your manual, you still have questions regarding
this product, we recommend that you see your Rockford Fosgate
dealer. If you need further assistance, you can call us direct at
1-800-669-9899. Be sure to have your serial number, model num-
ber and date of purchase available when you call.
Safety
This symbol with “WARNING” is intend-
ed to alert the user to the presence of
important instructions. Failure to heed
the instructions could result in severe
injury or death.
This symbol with “CAUTION” is intend-
ed to alert the user to the presence of
important instructions. Failure to heed
the instructions could result in injury
or unit damage.
• To prevent injury and damage to the unit, please read and
follow the instructions in this manual.
• If you feel unsure about installing this system yourself, have
it installed by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, fire and/or possible
injury.
Introduction
©2019 RockfordCorporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH® and associated logos where applicable are registered trademarks of
Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications sub-
ject to change without notice.
2 Introduction
3 Specifications
4 Diagrams
5 Wiring
6 Installation Considerations
Mounting
7-19 Additional Languages
French
Spanish
German
Italian
20 Limited Warranty Information
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
may produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique
upérieurs à 100 dB peut causer une perte d’acuité auditive
permanente. Les systèmes audio de forte puissance pour auto
peuvent produire des niveaux de pression acoustique bien au-delà
de 130 dB. Faites preuve de bon sens et pratiquez une écoute sans
risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores
a 100 dB puede causar la pérdida permanente de la audición. Los
sistemas de sonido de alta potencia para automóviles pueden
producir niveles de presión de sonido superiores a los 130 dB. Aplique
el sentido común y practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit
über 130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an
und praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica
ben superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle
regole del suono senza pericoli
3
Contents
• (1) PMX- RGB Color Optix Controller™
• (1) Power Connector
• (2) Bolts
• (2) Washers
• (2) Nuts
CONTENTS
38.25”
(971.25mm)
17.43”
(442.6mm)
3.5”
(89mm)
2.38”
(60.56mm)
6.45”
(163.9mm)
38.25”
(971.25mm)
17.43”
(442.6mm)
3.5”
(89mm)
2.38”
(60.56mm)
6.45”
(163.9mm)
Specs
• Element Ready - IPX7™
• Operating Voltage - 9-24VDC
• Current Draw - Up to 2 Amps
