Sida 1/12
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
rockfordfosgate.com
08312020 1230-73789-01-A Printed In China
Installation assistance available at:
MARINE WAKE CANS
M2WL-8
M2WL-8B
M2WL-8H
M2WL-8HB
Installation & Operation
2
Dear Customer,
Congratulations on your purchase of the world’s nest brand of audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand crasmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rock-
ford Fosgate product installed by an Authorized Rockford Fosgate
Dealer. Please read your warranty and retain your receipt and original
carton for possible future use.
Great product and competent installations are only a piece of the
puzzle when it comes to your system. Make sure that your installer is
using 100% authentic installation accessories from Rockford Fosgate in
your installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer all,
your new system deserves nothing but the best.
To add the nishing touch to your new Rockford Fosgate image, order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all
other countries, call +001-480-967-3565 or FAX +001-480-966-
3983.
Table of Content
If, aer reading your manual, you still have questions regarding
this product, we recommend that you see your Rockford Fosgate
dealer. If you need further assistance, you can call us direct at
1-800-669-9899. Be sure to have your serial number, model num-
ber and date of purchase available when you call.
Safety
This symbol with “WARNING” is intend-
ed to alert the user to the presence of
important instructions. Failure to heed
the instructions could result in severe
injury or death.
This symbol with “CAUTION” is intend-
ed to alert the user to the presence of
important instructions. Failure to heed
the instructions could result in injury
or unit damage.
• To prevent injury and damage to the unit, please read and
follow the instructions in this manual.
• If you feel unsure about installing this system yourself, have
it installed by a qualied Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, re and/or possible
injury.
Introduction
2 Introduction
3 Specifications
4-5 Diagrams
6Wiring
Installation Considerations
Mounting
7-8 Additional Languages
French
Spanish
German
Italian
12 Limited Warranty Information
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique upérieurs à
100 dB peut causer une perte d’acuité auditive permanente. Les systèmes
audio de forte puissance pour auto peuvent produire des niveaux de
pression acoustique bien au-delà de 130 dB. Faites preuve de bon sens et
pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores a 100
dB puede causar la pérdida permanente de la audición. Los sistemas de
sonido de alta potencia para automóviles pueden producir niveles de
presión de sonido superiores a los 130 dB. Aplique el sentido común y
practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über
130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an und
praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica ben
superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle regole
del suono senza pericoli
©2020 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH® and associated logos where applicable are registered trademarks
of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications
subject to change without notice.
3
Specifications
Model M2WL-8
M2WL-8B
M2WL-8H
M2WL-8HB
Nominal Diameter - inch
(mm)
8
(203mm).
8
(203mm).
Description 2-Way 2-Way
Nominal Impedance (Ohms) 4Ω 4Ω
Frequency Response (Hz) 35-24kHz 35-25kHz
Power Handling - Watts
(RMS/Peak) 250/1000 300/1200
Sensitivity (2.83V/1M) 93.1dB 94dB
Grille/Trim Ring YES YES
LED Current Draw .25 Amps .25 Amps
Recommended Fused Rating 1 Amp 1 Amp
LED Voltage Range 9-16 Volts 9-16 Volts
Overall Speaker (A) 9”
(230.4mm)
9”
(230.4mm)
Bolt Diameter (B) 7.75”
(197.0mm)
7.75”
(197.0mm)
Overall Height (C) 12.75”
(324.0mm)
12.75”
(324.0mm)
Overall Length (D) 14.4”
(365.7mm)
14.4”
(365.7mm)
*Rockford Fosgate determines its rated frequency response range at -6 dB below its nominal sensitivity
at upper and lower extents of a speaker’s output.
M2 Wake Can Dimensions
VERIFIED WITH KLIPPEL
To adorn the ‘Veried with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be trained
and certied by Klippel prior to using the three separate Klippel systems to design, develop and test. Rockford Fosgate
has made the investment in Klippel to deliver the best possible speakers and subwoofers to their customers.
illus.-1.1
A
B
C
D
