Sida 1/12
Printed in China
Full Range Speakers
Serial Number: Date of Purchase:
Installation & Operation
Installation et fonctionnement
Instalación y funcionamiento
Einbau und Betrieb
Installazione e funzionamento
Rockf d Corporation offers a limited warranty on Rockf d For or osgate products on the following terms:
Length of Warranty
Speakers – 1 Year. Any Factory Refurbished Product – 90 days (receipt required)
What is Covered
This war pplies onlranty a y to Rockford Fosgate products sold to consumers by Authorized Rockf d For osgate
Dealers in the United States of America or its possessions. oduct purPr chased b om any consumers fr
Authorized Rockf d Fosgate Dealer in another countror y are covered only by that country’s Distributor and
not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockford product purchased from an Authorized
Rockford Fosgate Dealer in the United States. In order to receive ser the purchaser must prvice, ovide
Rockford with a copy of the receipt stating the customer name, ,dealer name product purchased and date of
purchase. Products found to be def e during the warectiv ranty period will be repaired or replaced
(with a product deemed to be equivalent) at Rockford's discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations, water, theft,shipping
2.Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockf d Fosgate Seror vice Center
4.Any product which has had the serial number defaced, emoaltered,or r ved
5. Subsequent damage to other components
6.Any product purchased outside the U.S.
7.Any product not purchased from an Authorized Rockford Fosgate Dealer
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above.Some states do not allow limitations on the length of an implied
warranty, so this limitation may not apply. No person is authorized to assume for Rockford F y other osgate an
liability in connection with the sale of the product.
How to Obtain Service
Contact the Authorized Rockf d Fosgate Dealer you purchased this product fr If you need further or om.
assistance or Rockf d Customer Ser, call 1-800-669-9899 f or vice.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment
of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements,see your Authorized dealer for details.
2009 Rockf d Corporation. eseror All rights r ved.
Rockf d Fosgate and the Rockf d For or osgate logo are either
registered trademarks or trademarks of Rockf d Corporation.or
L WIMITED ARRANTY ST
ATEMENT
Rockford Fosgate
Rockf d Corporationor
600 South Rockford Drive
Tempe,Arizona 85281 U.S.A.
I (480) 967-3565n U.S.A.,
Customer Service 1-800-669-9899
www.rockf osgateordf .com
01/2009 B.M.
01/2009 E.R.
1230-55478-02
2
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to
install these speakers.
2. For safety, disconnect the negative lead from the battery prior to beginning the
installation.
3. For easier assembly, we suggest you run all wires prior to mounting your speakers
in place.
4. Use high quality connectors for a reliable installation and to minimize signal or
power loss.
5. Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines,
brake or hydraulic lines, vacuum lines or electrical wiring when working on any
vehicle. If installation in a boat, take care not to cut or drill through the main hull.
6. Never run wires underneath the vehicle. Running the wires inside the vehicle or
hull area provides the best protection.
7. Avoid running wires over or through sharp edges. Use rubber or plastic
grommets to protect any wires routed through metal, especially the firewall.
1. Determine where the speakers will be mounted. Ensure an area large enough for
the speaker to mount evenly. Be sure that the mounting location is deep enough
for the speaker to fit; if mounting in a door, operate all functions (windows, locks,
etc.) through their entire operating range to ensure there is no obstruction.
2. Refer to the specification chart to determine the proper diameter hole to cut
for your speaker model. Cutting and mounting templates can be found at
www.rockfordfosgate.com.
3. Mark the locations for the mounting screws. Drill the holes with a 1/8" bit.
4. Feed the speaker wires through the cutout and connect to the speaker terminals.
Be sure to observe proper polarity when connecting the wires.The speaker's
positive terminal is indicated with a "+".
5a. On models with slotted holes, fit the speaker into the cutout and install the
screws in the slots at the top and bottom.This will allow you to rotate the speak-
er to match the remaining mounting holes. When aligned, tighten the screws.
5b. On models with a trim ring, fit the trim ring over the speaker and mount into
place using four (4) screws.
6. Tighten the screws until the speaker is snug in place to prevent rattling. Do not
over tighten the screws.
NOTE: For P142, P1462, P152, P1S652 and P1653 only, if needed use the
adapter plate provided to mount the speaker. See Adapter Plate
Templates at the end of this manual.
SAFETY
CARTON CONTENTS
CAUTION: Before installation, disconnect the battery
negative (-) terminal to prevent damage
to the unit, fire and/or possible injury.
• (1) Pair Punch Series Full Range Speakers
• (1) Pair of grilles/trim rings (P152, P1S652, P1653, P1692 and P1694 only)
• (1) Pair of adapter plates (P142, P1462, P1572 only)
• (2) Pair of adapter plates (P152, P1S652, P1653 only)
• Mounting Hardware
INSTALLATION ONSIDERATIONSC
MOUNTING
Cutout
Hole
Position to
Ali Holesgn
Example of stand door installatiard on
Rear
Deck
Cutout
Hole
Example of
rear deck i llationnsta
PRACTICE SAFE SOUND™
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
may produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
3
Specifications subject to change without notice.
Specifications subject to change without notice.See figures on following pages.
See figures on following pages.
P1 Full Range P132 P142 P152 P1S652 P1653 P1462
Nominal Diameter - inch (mm) 3.5” (89) 4.0” (102) 5.25” (133) 6.5” (165) 6.5” (165) 4” x 6” (102 x 152)
Description 2-Way 2-Way 2-Way 2-Way 3-Way 2-Way
Nominal Impedance (ohms) 4Ω 4Ω 4Ω 4Ω 4Ω 4Ω
Frequency Response (Hz) 120-22kHz 100-22kHz 70-22kHz 65-22kHz 60-24kHz 90-22kHz
Voice Coil Diameter - inch (mm) 0.75 (20.0) 1.0 (25.4) 1.0 (25.4) 1.0 (25.4) 1.0 (25.4) 1.0 (25.4)
Fs - Free Air Resonance (Hz) 120 Hz 100 Hz 70 Hz 65 Hz 60 Hz 90 Hz
Qts 0.60 0.80 0.68 0.68 0.68 0.80
Vas - cu. ft. (Liter) 0.03 (0.9) 0.09 (2.5) 0.19 (5.4) 0.60 (16.8) 0.60 (16.8) 0.08 (2.2)
Xmax - inch (mm) 0.04 (1.0) 0.06 (1.5) 0.08 (2.0) 0.14 (3.5) 0.14 (3.5) 0.08 (2.0)
SPL (dB @ 1w/1m) 85 dB 86.5 dB 87 dB 88 dB 89 dB 87.5 dB
Power Handling-Watts (RMS / Peak) 20 W / 40 W 30 W / 60 W 40 W / 80 W 55 W / 110 W 60 W / 120 W 35 W / 70 W
Mounting Diameter-inch (mm) 3.21 (81.59) 4.04 (102.55) 4.81 (122.21) 5.05 (128.19) 5.57 (141.35) 3.63 x 5.80 (92.28 x 147.40)
Mounting Depth-inch (mm) 1.38 (35.00) 1.69 (43.00) 1.87 (47.50) 1.89 (48.00) 2.17 (55.00) 1.81 (46.00)
Includes Grille/Trim Ring NO NO YES YES YES NO
Trim Ring Diameter-inch (mm) – – 6.22 (158.00) 6.89 (175.00) 6.97 (177.00) –
Trim Ring Height-inch (mm) – – 0.88 (22.34) 0.93 (23.68) 0.83 (21.00) –
Includes Adaptor Plate NO 4”x6”/6”x8” 5”x7”/6”x9” 5”x7”/6”x9” 5”x7”/6”x9” 6”x8”
P1 Full Range P1572 P1683 P1692 P1694
Nominal Diameter - inch (mm) 5” x 7” (127 x 178) 6” x 8” (152 x 203) 6” x 9” (152 x 229) 6” x 9” (152 x 229)
Description 2-Way 3-Way 2-Way 4-Way
Nominal Impedance (ohms) 4Ω 4Ω 4Ω 4Ω
Frequency Response (Hz) 75-22kHz 65-24kHz 60-22kHz 60-24kHz
Voice Coil Diameter - inch 1.0 (25.4) 1.0 (25.4) 1.0 (25.4) 1.0 (25.4)
Fs - Free Air Resonance (Hz) 75 Hz 65 Hz 60 Hz 60 Hz
Qts 0.68 1.00 0.72 0.72
Vas - cu. ft. (Liter) 0.19 (5.4) 0.48 (13.6) 0.78 (22.0) 0.78 (22.0)
Xmax - inch (mm) 0.08 (2.0) 0.14 (3.5) 0.18 (4.5) 0.18 (4.5)
SPL (dB @ 1w/1m) 89 dB 90 dB 91 dB 91 dB
Power Handling-Watts (RMS / Peak) 60 W / 120 W 65 W / 130 W 75 W / 150 W 75 W / 150 W
Mounting Diameter-inch (mm) 4.58 x 6.71 (116.25 x 170.42) 4.88 x 6.92 (124.00 x 175.82) 5.62 x 8.28 (142.70 x 210.42) 5.62 x 8.28 (142.70 x 210.42)
Mounting Depth-inch (mm) 2.20 (56.00) 2.28 (58.00) 3.07 (78.00) 3.07 (78.00)
Includes Grille/ Trim Ring NO NO YES YES
Trim Ring Diameter-inch (mm) – – 7.56 x 10.24 (192.00 x 260.00) 7.56 x 10.24 (192.00 x 260.00)
Trim Ring Height-inch (mm) – – 0.82 (20.86) 0.82 (20.86)
Includes Adaptor Plate 6”x8” NO NO NO
SPECIFICATIONS
SPECIFICATIONS
