Sida 1/4
T3BMW-1 T3BMW-2•
T3BMW-3
BMW® DIRECT FITMENT
SPEAKERS
Serial Number: Date of Purchase:
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may produce
sound pressure levels well over 130dB. Use common sense and practice safe
sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique upérieurs à 100 dB peut
causer une perte d’acuité auditive permanente. Les systèmes audio de forte puissance
pour auto peuvent produire des niveaux de pression acoustique bien au-delà de 130 dB.
Faites preuve de bon sens et pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores a 100 dB puede causar
la pérdida permanente de la audición. Los sistemas de sonido de alta potencia para
automóviles pueden producir niveles de presión de sonido superiores a los 130 dB.
Aplique el sentido común y practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim Menschen zu
permanentem Hörverlust führen. Leistungsstarke Autosoundsysteme können
Geräuschdruckpegel erzeugen, die weit über 130 dB liegen. Bitte wenden Sie gesunden
Menschenverstand an und praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei 100dB possono
causare la perdita permanente dell’udito. I sistemi audio ad alta potenza possono
produrre livelli di pressione acustica ben superiori ai 130dB. Si consiglia il buon senso e
l’osservanza delle regole del suono senza pericoli
Dear Customer,
Congratulations on your purchase of the world’s finest brand of car audio speakers. At Rockford Fosgate
we are fanatics about musical reproduction at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing procedures, we have created a wide
range of products that reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford Fosgate product installed by an
Authorized Rockford Fosgate Dealer, as we provide specialized training through Rockford Technical Training
Institute (RTTI). Please read your warranty and retain your receipt and original carton for possible future
use.
Great product and competent installations are only a piece of the puzzle when it comes to your system.
Make sure that your installer is using 100% authentic installation accessories from Rockford Fosgate in
your installation. Rockford Fosgate has everything from RCA cables and speaker wire to power wire and
battery connectors. Insist on it! After all, your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order your Rockford accessories, which
include everything from T-shirts to jackets.
Visit our web site for the latest information on all Rockford products; www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other countries, call +001-480-967-3565 or FAX
+001-480-966-3983.
Introduction
©2014 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where ap-
plicable are registered trademarks of Rockford Corporation in the United States and/or other countries. All
other trademarks are the property of their respective owners. Specifications subject to change without notice.
Contents
Installation Considerations
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to install these speakers.
2. For safety, disconnect the negative lead from the battery prior to beginning the installation.
3. For easier assembly, we suggest you run all wires prior to mounting your speakers in place.
4. Use high quality connectors for a reliable installation and to minimize signal or power loss.
5. Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines, brake or hydraulic lines, vacuum
lines or electrical wiring when working on any vehicle. If installation in a boat, take care not to cut or drill
through the main hull.
6. Never run wires underneath the vehicle. Running the wires inside the vehicle or hull area provides the best
protection.
7. Avoid running wires over or through sharp edges. Use rubber or plastic grommets to protect any wires routed
through metal, especially the firewall.
Installation
1. Using a Torx screw driver/socket, loosen and remove all door panel bolts.
2. Next, starting at the bottom of the door panel, carefully pry away the panel away from the door. Work your way
around to the top making sure all plastic clips are detached.
3. Disconnect all wiring and door latch cables. Proceed with removing and disconnecting the tweeter and
midrange speaker.
4. Replace the original tweeter and midrange speakers with the new T3BMW model speakers.
5. Reconnect the new tweeter and midrange wires. Be sure to use the provided in line crossover that connects
between the factory speaker wire connector and the new tweeter. 0 dB matches the amplitude (no increase/
no attenuation) of the tweeter to the same level as the midrange. +3dB increases the amplitude of the tweeter
in relation to the midrange. (Ideal when matching offset installation like tweeters located high in door panels
and midranges low in kick panel.)
6. Once all speakers are connected and mounted, reconnect all other wire and cables before attaching the door
panel back onto the door.
VISIT ROCKFORDFOSGATE.COM FOR:
rockfordfosgate.com/products/details/t3-bmw1
rockfordfosgate.com/products/details/t3-bmw2
rockfordfosgate.com/products/details/t3-bmw3
Installation
• (1) Pair 4” Midrange Speaker
• (1) Pair 1” Tweeter
• (1) Pair Inline Crossover
• (1) Pair Optional Tweeter Bezel
Make
Vehicle Fitment Guide
Model
Body Style
Year
Installation Videos
