Sida 1/8
BCF102010
1230-56535-01 Printed in China
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:
Length of Warranty
Speakers – 1Year. Any Factory Refurbished Product – 90 days (receipt required)
What is Covered
This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate
Dealers in the United States of America or its possessions. Product purchased by consumers from an
Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and
not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockford product purchased from an Authorized
Rockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provide
Rockford with a copy of the receipt stating the customer name, dealer name, product purchased and date of
purchase. Products found to be defective during the warranty period will be repaired or replaced
(with a product deemed to be equivalent) at Rockford's discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations, water, theft, shipping
2. Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center
4. Any product which has had the serial number defaced, altered, or removed
5. Subsequent damage to other components
6. Any product purchased outside the U.S.
7. Any product not purchased from an Authorized Rockford Fosgate Dealer
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above.Some states do not allow limitations on the length of an implied
warranty, so this limitation may not apply.No person is authorized to assume for Rockford Fosgate any other
liability in connection with the sale of the product.
How to Obtain Service
Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further
assistance, call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment
of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements, see your Authorized dealer for details.
Designed and Engineered by Rockford Fosgate,Tempe, AZ. USA.
2010 Rockford Corporation.All rights reserved.
Rockford Fosgate and the Rockford Fosgate logo are either
registered trademarks or trademarks of Rockford Corporation.
L WIMITED ARRANTY TATEMENTS
Rockford Fosgate
Rockford Corporation
600 South Rockford Drive
Tempe,Arizona 85281 U.S.A.
In U.S.A., (480) 967-3565 - Customer Service 1-800-669-9899
www.rockfordfosgate.com
2
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to
install these speakers.
2. For safety, disconnect the negative lead from the battery prior to beginning the
installation.
3. For easier assembly, we suggest you run all wires prior to mounting your speakers
in place.
4. Use high quality connectors for a reliable installation and to minimize signal or
power loss.
5. Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines,
brake or hydraulic lines, vacuum lines or electrical wiring when working on any
vehicle. If installation in a boat, take care not to cut or drill through the main hull.
6. Never run wires underneath the vehicle. Running the wires inside the vehicle or
hull area provides the best protection.
7. Avoid running wires over or through sharp edges. Use rubber or plastic
grommets to protect any wires routed through metal, especially the firewall.
1. Determine where the speakers will be mounted. Ensure an area large enough for
the speaker to mount evenly. Be sure that the mounting location is deep enough
for the speaker to fit; if mounting in a door,operate all functions (windows, locks,
etc.) through their entire operating range to ensure there is no obstruction.
2. Refer to the specification chart to determine the proper diameter hole to cut
for your speaker model.The template provided also gives the proper cutout size.
3. Mark the locations for the mounting screws. Drill the holes with a 1/8" bit.
4. Feed the speaker wires through the cutout and connect to the speaker terminals.
Be sure to observe proper polarity when connecting the wires.The speaker's
positive terminal is indicated with a "+".
5. On models with slotted holes, fit the speaker into the cutout and install the
screws in the slots at the top and bottom.This will allow you to rotate the speak-
er to match the remaining mounting holes.When aligned, tighten the screws.
6. Tighten the screws until the speaker is snug in place to prevent rattling. Do not
over tighten the screws.
SAFETY
CARTON ONTENTSC
CAUTION: Before installation, disconnect the battery
negative (-) terminal to prevent damage
to the unit, fire and/or possible injury.
•(1) Set T3 Series Speakers with Tweeters and 2-Way Crossover
•(1) Set of grilles/trim rings
•(2) Sets of tweeter trim rings:
(1 set of polished aluminum)
(1 set of brushed aluminum)
• Tweeter Mounting Hardware with Surface, Angle, and Flush Mounts
INSTALLATION ONSIDERATIONSC
MOUNTING
Discreet Dual Clamp (DDC™) Tweeter Mount
Every aspect of the new Tweeter design has been completely re-engi-
neered to allow for maximum ease of installation and fitment.This opti-
mized patent pending design provides concentric clamping pressure
around the perimeter of the mounting hole.
The “mounting cups” are in fact not “cups” at all, but rather unobtrusive
“clamps” that quickly and easily mount in a standard 1.75 inch (45mm)
hole saw opening with a single center screw securing with balanced pres-
sure to both faces of the mounting surface. From there, the tweeter sim-
ply snaps into place and is secured by a snap-on trim ring. Removal is easy
if needed.The protective grille on the tweeter is non-removable and an
intergral part of the design.
PRACTICE SAFE SOUND™
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered auto sound systems
may produce sound pressure levels well over 130dB. Use common
sense and practice safe sound.
3
Specifications subject to change without notice.
T3 Components T3652-S
Nominal Diameter - inch (mm) 6.5 (165)
Description Component System
Nominal Impedance (ohms) 4Ω
Frequency Response (Hz) 40Hz - 30kHz
Crossover Frequency (Hz) 3kHz
High-Pass Butterworth Crossover 18dB/octave
Low Pass Butterworth Crossover 12dB/octave
Voice Coil Diameter - inch (mm) 1.5 (38)
Fs - Free Air Resonance (Hz) 50
Qts 0.71
Vas - cu. ft. (Liter) 0.57 (16.28)
Xmax - inch (mm) 0.5 (12.6)
SPL (dB @ 1w/1m) 87.5 dB
Power Handling-Watts (RMS / Peak) 125 / 250
Rec. Amp Power-Watts (RMS) 37.5W ~ 125W
Mounting Diameter-inch (mm) 5.67(144)
Mounting Depth-inch (mm) 2.79(71)
Includes Grille/Trim Ring YES
Trim Ring Diameter-inch (mm) 7.14(181)
Trim Ring Height-inch (mm) 0.95(24)
SPECIFICATIONS
