Installation & Operation

Serial Number: Date of Purchase:

P1L 10" 12"

Single P1L-1X10 P1L-1X12

Dual P1L-2X10 P1L-2X12

P2L 10" 12"

Single P2L-1X10 P2L-1X12

Dual P2L-2X10 P2L-2X12

P3L 10" 12"

Single P3L-1X10 P3L-1X12

Dual P3L-2X10 P3L-2X12

P1L – P2L – P3L - LOADED ENCLOSURES

SVC - SINGLE VOICE COIL SUBWOOFERS DVC - DUAL VOICE COIL SUBWOOFERS

INSTALLATION – ENGLISH

FEATURES

CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.

Run the speaker cable from the amp. When routing the speaker cable from the amplifier, avoid running it close to any sources of high current

(wiring harnesses).The positive (+) speaker output from the amp connects to the red terminal of the enclosure, and the negative (-) connects to the

black terminal.

INSTALACIÓN – ESPAÑOL

PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo de la batería (-) para prevenir daño a la unidad, incendio

y/o posibles lesiones.

Recorrido del Cable de Altavoz Desde el Amplificador.Al llevar el cable de altavoz desde el amplificador, evite que pase cerca de cualquier

fuente de alto corriente (cables de alimentacion). El terminal positive (+) de las salida de rojo, y el terminal negativo (-) al terminal negro.

INSTALLATION – FRANÇAIS

MISE EN GARDE : avant d'entamer l'installation, déconnectez la broche négative (-) de la batterie pour éviter tout risque de

blessures, d’incendie ou de dommages à l'appareil.

Branchement du câble du haut-parleur de l’amplificateur. En plaçnt le câble du haut-parleur de l’ampli, éviter de l’approcher d’une source

de courant important. La sortie positive de l’ampli se branche sur le terminal rouge du caisson, et le négatif se branche sur le terminal noir.

EINBAU – DEUTSCH

VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu

vermeiden.

Anschluß des Lautsprecherkabels. Beim Anschluß des Lautsprecherkables sollten Sie darauf achten, daß das Kabel keine Fahrzeugstromkabel

kr um Einsteuungen zu verhindern. Die Plus-Leitung des Lautsprecherkabels kommt in die rote Klemme des Terminals, die Negativ-Leitung in dieeuzt,

schwarze Klemme des Terminals.

INSTALLAZIONE – ITALIANO

ATTENZIONE: Prima dell’installazione scollegate il terminale negativo (-) della batteria per evitare danni all’unità,,

pericoli d’incendio e/o potenziali lesioni personali.

Far correre il cavo dell’altoparlante all’amplificatore. Quando fate correre il cavo dell’altoparlante all’amplificatore non

fatelo passare vicino a qualsiasi cavo dell’impianto elettrico di serie dell’auto. Il segnale positivo dell’altoparlante (+) in uscita dall’amplificatore á col-

legato al terminale rosso del diffusore, e il negativo (-) al terminale nero.

Strip 5/8"

(16mm)

From

Amplifier

Amplifier 4Ω Mono

Amplificador 4Ω Mono

Amplificateur de 4Ω Mono

Amplifier 4Ω Mono

Amplificatore 4Ω Mono

Black

Negro

Noir

Schwarz

Nero

Red

Rojo

Rouge

Rot

Rosso

Vented Enclosure Features

• Proprietary High-Flow, Low-Noise Ports

• High Current Binding Posts

• Constructed with 5/8" MDF

• Covered with High Density Carpet

• Wired Exclusively with Rockford Accessories

16 AWG

-to-

12 AWG

FEATURES SPECIFICATIONS

Specifications subjct to change without notice

P2L-1X10 Single 10" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Woofer P2D210 (wired internally)

Power Handling (Watts) 250 RMS / 500 Max

Overall Dimensions (HxWxD) 13.125” x 17.0” x 15.75”

(33.3cm x 43.2cm x 40.0cm)

P2L-2X10 Dual 10" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Woofer P2D410 (wired internally)

Power Handling (Watts) 500 RMS / 1000 Max

Overall Dimensions (HxWxD) 13.125” x 31.125” x 15.75”

(33.3cm x 79.1cm x 40.0cm)

P2L-1X12 Single 12" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P2D212 (wired internally)

Power Handling (Watts) 250 RMS / 500 Max

Overall Dimensions (HxWxD) 15.125” x 19.125” x 16.375”

(38.4cm x 48.6cm x 41.6cm)

P2L-2X12 Dual 12" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P2D412 (wired internally)

Power Handling (Watts) 500 RMS / 1000 Max

Overall Dimensions (HxWxD) 15.125” x 33.875” x 16.375”

(38.4cm x 86.0cm x 41.6cm)

P3L-1X10 Single 10" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P3D210 (wired internally)

Power Handling (Watts) 400 RMS / 800 Max

Overall Dimensions (HxWxD) 13.125” x 17.0” x 15.75”

(33.3cm x 43.2cm x 40.0cm)

P3L-2X10 Dual 10" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P3D410 (wired internally)

Power Handling (Watts) 800 RMS / 1600 Max

Overall Dimensions (HxWxD) 13.125” x 31.125” x 15.75”

(33.3cm x 79.1cm x 40.0cm)

P3L-1X12 Single 12" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P3D212 (wired internally)

Power Handling (Watts) 500 RMS / 1000 Max

Overall Dimensions (HxWxD) 15.125” x 19.125” x 16.375”

(38.4cm x 48.6cm x 41.6cm)

P3L-2X12 Dual 12" DVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P3D412 (wired internally)

Power Handling (Watts) 1000 RMS / 2000 Max

Overall Dimensions (HxWxD) 15.125” x 33.875” x 16.375”

(38.4cm x 86.0cm x 41.6cm)

Speaker Features - P1L - SVC (Single Voice Coil)

• High modulus closed conical polypropylene cone.

• Tear & fatigue resistant poly-cotton spider.

• High density compressed half-roll sealed poly-foam surround.

• High temp voice coil with spun-laced Nomex™ insulating

re-inforcment collar.

• Optimized motor magnetics with extended pole and bumped backplate.

• Sturdy 16 guage compound bend frame geometry.

• Proprietary spider venting/cooling technique.

Speaker Features - P2L & P3L - DVC (Dual Voice Coil)

• Venturi-effect center pole dispersion venting/cooling system.

• High modulus closed conical polypropylene cone and ABS/Acrylic dustcap

assembly geometry.

• Tear & fatigue resistant poly-cotton spider.

• High density compressed half-roll sealed poly-foam surround.

• High temp voice coil with spun-laced Nomex™ insulating

re-inforcment collar.

• Optimized motor magnetics with extended pole and bumped backplate.

• Double stack ferrite magnet structure.

• P2 – Sturdy 16 guage compound bend frame geometry.

• P3 – Rigid die-cast aluminium frame.

• Proprietary spider venting/cooling technique.

• Diamond cut cast aluminum motor cover for improved heat dissipation.

P1L-1X10 Single 10" SVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P1S410

Power Handling (Watts) 150 RMS / 300 Max

Overall Dimensions (HxWxD) 13.125” x 17.0” x 15.75”

(33.3cm x 43.2cm x 40.0cm)

P1L-2X10 Dual 10" SVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P1S810 (wired internally)

Power Handling (Watts) 300 RMS / 600 Max

Overall Dimensions (HxWxD) 13.125” x 31.125” x 15.75”

(33.3cm x 79.1cm x 40.0cm)

P1L-1X12 Single 12" SVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P1S412

Power Handling (Watts) 150 RMS / 300 Max

Overall Dimensions (HxWxD) 15.125” x 19.125” x 16.375”

(38.4cm x 48.6cm x 41.6cm)

P1L-2X12 Dual 12" SVC

Nominal Impedance (Ohms) 4 Ω

Replacement Model P1S812 (wired internally)

Power Handling (Watts) 300 RMS / 600 Max

Overall Dimensions (HxWxD) 15.125” x 33.875” x 16.375”

(38.4cm x 86.0cm x 41.6cm)
