Sida 1/8
11/2009 E.R. (WebWizard)
1230-56133-01 Printed in China
Component Systems
Serial Number: Date of Purchase:
Installation & Operation
Installation et fonctionnement
Instalación y funcionamiento
Einbau und Betrieb
Installazione e funzionamento
5.25” – R152-S
6.5” – R1652-S
1” Tweeter System – R1T-S
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms:
Length of Warranty
Speakers – 1 Year (r equireceipt r ed)
What is Covered
This war pplies onlranty a y to Rockford Fosgate products sold to consumers by Authorized Rockford Fosgate
Dealers in the United States of America or its possessions. oduct purPr chased by consumers from an
Authorized Rockf d Fosgate Dealer in another countror y are covered only by that country’s Distributor and
not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockf oduct purchased frord pr om an Authorized
Rockf d Fosgate Dealer in the United States. In oror der to receive ser the purchaser must prvice, ovide
Rockf d with a copy of the receipt stating the customer name dealer nameor , , product purchased and date of
purchase. Products found to be def e during the warectiv ranty period will be repaired or replaced
(with a product deemed to be equivalent) at Rockford's discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations, water, theft, shipping
2.Any cost or expense related to the removal or reinstallation of product
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center
4.An altered,y product which has had the serial number defaced, or removed
5. Subsequent damage to other components
6.Any product purchased outside the U.S.
7.Any product not purchased from an Authorized Rockford Fosgate Dealer
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the
period of the express warranty set forth above. Some states do not allow limitations on the length of an implied
warranty, so this limitation may not apply. No person is authorized to assume for Rockford F y other osgate an
liability in connection with the sale of the product.
How to Obtain Service
Contact the Authorized Rockf d Fosgate Dealer you purchased this product fr If you need further or om.
assistance or Rockf, call 1-800-669-9899 f ord Customer Service.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment
of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements, see your Authorized dealer for details.
2010 Rockf d Corporation. eseror All rights r ved.
Rockf d Fosgate and the Rockf d For or osgate logo are either
registered trademarks or trademarks of Rockf d Corporation.or
L WIMITED ARRANTY STATEMENT
Rockford Fosgate
Rockford Corporation
600 South Rockford Drive
Tempe,Arizona 85281 U.S.A.
I (480) 967-3565n U.S.A.,
Customer Service 1-800-669-9899
www.rockfordfosgate.com
2
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to
install these speakers.
2. For safety, disconnect the negative lead from the battery prior to beginning the
installation.
3. For easier assembly, we suggest you run all wires prior to mounting your speakers
in place.
4. Use high quality connectors for a reliable installation and to minimize signal or
power loss.
5. Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines,
brake or hydraulic lines, vacuum lines or electrical wiring when working on any
vehicle. If installation in a boat, take care not to cut or drill through the main hull.
6. Never run wires underneath the vehicle. Running the wires inside the vehicle or
hull area provides the best protection.
7. Avoid running wires over or through sharp edges. Use rubber or plastic
grommets to protect any wires routed through metal, especially the firewall.
1. Determine where the speakers will be mounted. Ensure an area large enough for
the speaker to mount evenly. Be sure that the mounting location is deep enough
for the speaker to fit; if mounting in a door, operate all functions (windows, locks,
etc.) through their entire operating range to ensure there is no obstruction.
2. Refer to the specification chart to determine the proper diameter hole to cut
for your speaker model.The template provided also gives the proper cutout size.
3. Mark the locations for the mounting screws. Drill the holes with a 1/8" bit.
4. Feed the speaker wires through the cutout and connect to the speaker terminals.
Be sure to observe proper polarity when connecting the wires.The speaker's
positive terminal is indicated with a "+".
5. Tighten the screws until the speaker is snug in place to prevent rattling. Do not
over tighten the screws.
SAFETY
CARTON CONTENTS
CAUTION: Before installation, disconnect the battery
negative (-) terminal to prevent damage
to the unit, fire and/or possible injury.
• (1) Set R1 Series Speakers with Tweeters or R1T-S Tweeter Kit
• (1) Set of grilles/trim rings
• Mounting Hardware and Tweeter Surface/Angle and Flush Mounts
INSTALLATION ONSIDERATIONSC
MOUNTING
Cutout
Hole
Example of Standard Door Installation
From Midrange
1/4”
(0.25”) 3/16”
(0.18”)
System Wiring
Mid-Range
Woofer
Striped
Tw eeter
(built-in 6dB
crossover)
From plifier Am
3
Specifications subject to change without notice.See figures on following pages.
PRIME Components R152-S R1652-S R1T-S
Nominal Diameter - inch (mm) 5.25 (133) 6.5 (165) 1.0 (25)
Description 2-Way Component 2-Way Component Tweeter Kit
Nominal Impedance (ohms) 4Ω 4Ω 4Ω
Frequency Response (Hz) 58Hz-20kHz 55Hz-20kHz 2.5kHz-22kHz
Crossover Frequency (Hz) 12kHz 12kHz 12kHz
6dB/octave Butterworth Crossover HP (High Pass) HP (High Pass) HP (High Pass)
Voice Coil Diameter - inch (mm) 1.04 (26.5) 1.04 (26.5) 0.55 (13.9)
Fs - Free Air Resonance (Hz) 72Hz 59Hz 2.6kHz
Qts 0.94 0.70 –
Vas - cu. ft. (Liter) 0.22 (5.8) 0.61 (15.5) –
Xmax - inch (mm) 0.07 (1.7) 0.20 (5.2) –
SPL (dB @ 1w/1m) 85dB 89dB 72.5dB
Power Handling-Watts (RMS / MAX) 40W / 80W 40W / 80W 40W / 80W
Mounting Diameter-inch (mm) 4.76 (121) 5.71 (145) 1.83 (46) (Flush Mount)
Mounting Depth-inch (mm) 1.91 (48) 2.17 (55) 0.76 (19) (Flush Mount)
Includes Grille/Trim Ring YES YES YES
Grille/Trim Ring Diameter-inch (mm) 6.10 (154.6) 7.01 (178) 2.13 (54)
Grille/Trim Ring Height-inch (mm) 0.70 (17) 0.67 (17) 0.29 (7)
SPECIFICATIONS
WIRING
FEATURES
Built-In Tweeter Crossover
For the R152-S and R1652-S, a HP (High-Pass)
crossover is integrated into the tweeter housing.
This crossover allows for easy connection of the
full component system. Just jump wires from the
secondary terminals on the mid-range/woofer to
the tweeter terminals, see diagram below.
NOTE:
The tweeter has an integrated 6dB/octave HP
crossover.The mid-range/woofer has natural roll-off
characteristics exhibit great acoustic crossover fil-
tering.
1. Use illustration for proper connection.
2. Be sure to maintain speaker polarity.
3. Connect primary tabs on Mid-Range/Woofer to Amplifier.
4. Connect secondary tabs on Mid-Range/Woofer to Tweeter.
NOTE:
The tweeter has an integrated 6dB/octave HP crossover.The
mid-range/woofer has natural roll-off characteristics exhibit
great acoustic crossover filtering.
