Installation & Operation
RFX317-FSE
CAN-AM MAVERICK X3®
FRONT SPEAKER
ENCLOSURES
R O C K F O R D F O S G AT E . C O M
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
Installation assistance available at:
www.rockfordfosgate.com/rech
2
Dear Customer,
Congratulations on your purchase of the world’s finest brand of
audio products. At Rockford Fosgate we are fanatics about musical
reproduction at its best, and we are pleased you chose our product.
Through years of engineering expertise, hand crasmanship and critical
testing procedures, we have created a wide range of products that
reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new
Rockford Fosgate product installed by an Authorized Rockford Fosgate
Dealer, as we provide specialized training through Rockford Technical
Training Institute (RTTI). Please read your warranty and retain your
receipt and original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! Aer all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
hats.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Contents
If, aer reading your manual, you still have questions regarding this
product, we recommend that you see your Rockford Fosgate dealer.
If you need further assistance, you can call us direct at 1-800-669-
9899. Be sure to have your serial number, model number and date of
purchase available when you call.
Safety
This symbol with “WARNING” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
can result in injury or unit damage.
• To prevent injury and damage to the unit, please read and
follow the instructions in this manual. We want you to enjoy
this system, not get a headache.
• If you feel unsure about installing this system yourself, have
it installed by a qualified Rockford Fosgate technician.
• Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, fire and/or possible
injury.
Contents
Installation Tools
The following is a list of suggested tools needed for installation:
Introduction
©2017 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered
trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective
owners. Specifications subject to change without notice.
2Introduction
3Installation
4Warranty
• T30 Torx
• 10 mm Socket
• Ratchet
• Wire Cutters
• Panel Tool
• (2) Front Speaker Enclosures
• Mounting Hardware
• Plastic Wire Tie Wraps
• Wire Harness
• Foam Pads
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB
may cause permanent hearing loss. High powered auto
sound systems may produce sound pressure levels well
over 130dB. Use common sense and practice safe sound.
3
Installation Considerations
This section focuses on some considerations for installing your Can-Am
Maverick X3 front speaker enclosures. These speaker enclosures are
designed to work in conjunction with Rockford’s other X3 specific audio
kits and parts.
If you feel unsure about installing this system yourself, have it installed
by a qualified technician.
When drilling holes, make sure what is on the other side. Be sure that
any electrical, fuel lines or any other important components are free
and clear from the area.
Before installation, disconnect the battery
negative (-) terminal to prevent damage to
the unit, fire and/or possible injury.
Before beginning any installation, follow
these simple rules:
Be sure to carefully read and understand
the instructions before attempting to install
these speaker enclosures.
• Consult your UTV’s service manual for model specific information.
Models may dier from year to year depending on factory options
and aermarket accessories added.
• This speaker kit is specifically designed to work with Rockford
Fosgate’s PM and RM series of speakers.
• With the addition of an amplifier or source unit, be sure that your
current charging system is in proper working order.
• Visit rockfordfosgate.com for more comprehensive product
information.
• Visit our YouTube channel for comprehensive installation videos
demonstrating complete installation guides and install tips.
Applicable Models:
Can-Am Maverick X3 (2 & 4 seat models)
These front speaker enclosures are designed to work with Rockford
Fosgate’s RFX3-K4 / RFX3-K8 amplifier wiring kits and RFX3-PMXDK dash
kit. The enclosure can be installed in both 2-seat and 4-seat models
replacing the factory dash panels.
Step 1. Remove the fuse cover and the (4) plastic rivets that are
adjacent to the fuse panel access hole.
Installation
Step 2. Remove the remaining screws that secure the driver /
passenger dash panel.
NOTE: There are (2) factory clips that need to be transferred from the
original panels to the new Rockford panels.
Step 3. Reattach the factory module to the underside of the speaker
panel using the 4 mounting holes and existing hardware.
Step 4. Mount the new speaker panels using the existing hardware.
Step 5. Place speaker harness down the speaker cutout hole and
route toward the center of the vehicle to behind the fuse block
access hole.
Step 6. Connect the speaker harness to the speaker.
Step 7. Secure the speaker with the supplied speaker hardware.
Step 8. Repeat steps for the enclosure on the other side.
Step 9. Feed the speaker wire up into the dash and connect to either
the source unit or amplifier.
Step 10. Power up and test the system
Step 11. Reinstall the fuse cover.
Clip
Clip
