Sida 1/2
Install AC1200PCE
Power off your PC and open the case to find an
available PCI-E slot.
Insert the Adapter into the available PCI-E slot
and close the lid.
Attach the Antennas
Locate the antenna stand and fasten the two
antennas onto the antenna connectors.
Attach the antenna cable to the antenna connectors
on AC1200PCE or attach the antennas to the
adapter without stand.
For Windows Users
A Found New Hardware Wizard tip may show after
insert resource CD. Click to close it and Cancel
continue with the steps below.
A
B
Power on your Desktop PC
Insert the Setup CD
Follow the Instructions for your Operating System
Windows 8, 7, and Vista
Windows XP
A. From the Menu page, select Driver Installation
B. Software Installation
If you are prompted by a Windows Logo message, click
Continue Anyway to proceed.
If the Menu page does not appear, browse the CD drive
and double-click the file.Autorun.exe
B. Start the Driver/Utility Installation
If prompted, click to begin the installation.Yes
C. Restart your Computer
A prompt will appear asking you to restart your computer.
Select and click to restart.Yes Finish
D. Locate a Wireless Network
Once Windows has completed the driver installation
after restart, you may find Rosewill Wireless Utility on
your desktop. Double click the software, and select the
Available Networks to search the networks.
Pick the WiFi that you want to connect to and double
click; then your computer will scan the WiFi automatically
while available.
A. From the Menu page, select Driver Installation
If the Menu page does not appear, browse the CD drive
and double-click the file.Autorun.exe
C. Restart your Computer
D. Locate a Wireless Network
Once Windows has completed the driver installation
after restart, you may find Rosewill Wireless Utility on
your desktop. Double click the software, and select the
Available Networks to search the networks.
Pick the WiFi that you want to connect to and double
click; then your computer will scan the WiFi automatically
while available.
After the driver installation, a prompt will ask you to
restart your computer. Select Yes Finishand click to
restart.
PLEASE READ FIRST
Call Center: (800) 575-9885
Web: http://www.rosewill.com
Support: techsupport@rosewill.com
If you have any question, please feel free to contact us.
Wireless Dual Band Adapter
RNX-AC1200PCE
1
2
3
Install Adapter
Insert the Setup CD
Quick Installation Guide
Wireless PCI-E Adapter AC1200PCE
Installation Wizard
Exit
Setup Guide
Driver Installation
Support: tec hsuppor t@ros ewill.com Call Center: ( 800) 575-9885 Web: http://ww w.ros ewill.com
Wireless PCI-E Adapter AC1200PCE
Installation Wizard
Exit
Setup Guide
Driver Installation
Support: tec hsuppor t@ros ewill.com Call Center: ( 800) 575-9885 Web: http://ww w.ros ewill.com
Antenna Connectors:
1. Connect the antennas directly
2. Connect via the antenna stand for further locations.
Activity LED:
Light Blink: Data transfer via 2.4GHz or 5.0GHz
connection.
General: Show the basic information of connection and
Network Address information
Profile: Include the settings of saved WiFi network and the
staus of the adapters
Available Network: Show all the WiFi you can connect to.
WiFi Protected Setup(WPS): By a push of WPS button, you
can connect to a WiFi network with device supporting WPS
function.
Radio off: Disable the wireless function of AC1200PCE, and
you won’t be able to connect WiFi via AC1200PCE
Disable Adapter: Disables AC1200PCE from your computer.
Wireless Dual Band Adapter
1
2
3
11
3
3
4
4
5
5
2
2
6
6
Utility Introduction
LED Indications
PLEASE READ FIRST
Call Center: (800) 575-9885
Web: http://www.rosewill.com
Support: techsupport@rosewill.com
If you have any question, please feel free to contact us.
RNX-AC1200PCE
Quick Installation Guide
Best Angle for Antennas
- Interference avoidance from closed antennas
More than 10cm
