Rotel RA-1570S-B Bruksanvisning

Rotel mottagare RA-1570S-B

Läs nedan 📖 manual på svenska för Rotel RA-1570S-B (76 sidor) i kategorin mottagare. Denna guide var användbar för 12 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/76
Owner’s Manual
Manuel de l’utilisateur
Bedienungsanleitung
Manual de Instrucciones
Gebruikershandleiding
Manuale di istruzioni
Instruktionsbok
Инструкция пользователя
RA‑1570
Stereo Integrated Amplifier
Amplificateur Stéréo Intégré
Stereo‑Vollverstärker
Amplificador Integrado Estereofónico
Geïntegreerde stereoversterker
Amplificatore integrato stereo
Integrerad stereoförstärkare
Интегрированный стерео усилитель
2RA‑1570 Stereo Integrated Amplifier
2RA‑1570 Stereo Integrated Amplifier
WARNING: There are no user serviceable parts inside. Refer all
servicing to qualified service personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose
the unit to moisture or water. Do not expose the unit to dripping or
splashing. Do not place objects filled with liquids, such as vases, on
the unit. Do not allow foreign objects to get into the enclosure. If the
unit is exposed to moisture, or a foreign object gets into the enclosure,
immediately disconnect the power cord from the wall. Take the unit
to a qualified service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and
on the product itself. Follow all operating instructions.
Clean the enclosure only with a dry cloth or a vacuum cleaner.
Do not use this unit near water.
You must allow a minimum 10 cm or 4 inches of unobstructed
clearance around the unit.
Do not place the unit on a bed, sofa, rug, or similar surface that could
block the ventilation openings. If the unit is placed in a bookcase or
cabinet, there must be ventilation of the cabinet to allow proper cooling.
Keep the component away from radiators, heat registers, stoves, or
any other appliance that produces heat.
Rotel products are designed to comply with
international directives on the Restriction of
Hazardous Substances (RoHS) in electrical and
electronic equipment and the disposal of Waste
Electrical and Electronic Equipment (WEEE). The
crossed wheelie bin symbol indicates compliance and
that the products must be appropriately recycled
or processed in accordance with these directives.
This symbol means that this unit is double insulated.
An earth connection is not required.
Important Safety Instructions
WARNING:
The rear panel power cord connector is the mains
power disconnect device. The apparatus must be located in an
open area that allows access to the cord connector.
The unit must be connected to a power supply only of the type and
voltage specified on the rear panel. (USA: 120 V/60Hz, EC: 230V/50Hz)
Connect the component to the power outlet only with the supplied
power supply cable or an exact equivalent. Do not modify the
supplied cable. A polarized plug has two blades, with one wider than
the other. A grounding plug has two blades plus a third grounding
prong. These are provided for your safety. Do not defeat grounding
and/or polarization safety provisions. If the supplied plug does not
fit your outlet, please consult an electrician for replacement of the
obsolete outlet. Do not use extension cords.
The main plug of the power cordset is a disconnect device of the
apparatus. In order to completely disconnect the apparatus from the
supply mains, the main plug of the power cordset should be unplugged
from the mains (AC) outlet. The standby LED indicator will not be lit
up to show the power cord is unplugged. The disconnect device shall
remain readily operable.
Do not route the power cord where it will be crushed, pinched,
bent, exposed to heat, or damaged in any way. Pay particular
attention to the power cord at the plug and where the cord exits
the back of the unit.
The power cord should be unplugged from the wall outlet during
a lightning storm or if the unit is to be left unused for a long
period of time.
Use only accessories specified by the manufacturer.
Use only with a cart, stand, rack, bracket or shelf system
recommended by Rotel. Use caution when moving the unit in a
stand or rack to avoid injury from a tip‑over.
Use Class 2 wiring for speaker connections to ensure proper
installation and minimize the risk of electrical shock.
Immediately stop using the component and have it inspected and/
or serviced by a qualified service agency if:
• The power supply cord or plug has been damaged
• Objects have fallen or liquid has been spilled into the unit
• The unit has been exposed to rain
• The unit shows signs of improper operation
• The unit has been dropped or damaged in any way
The batteries in the remote control should not be exposed to
excessive temperature such as sunshine, fire or other heat sources.
Place the unit on a on a fixed, level surface strong
enough to support its weight. Do not place it on a
moveable cart that could tip over.
33
1 2 3
5
=
6 7 8
r t y
-
9
0 q w
e
4
u i
Figure 2: RR‑AX92 Remote Control
Télécommande infrarouge RR‑AX92
Fernbedienung RR‑AX92
Mando a Distancia RR‑AX92
Afstandsbediening RR‑AX92
Telecomando RR‑AX92
RR‑AX94 fjärrkontroll
Пульт ДУ RR-AX92
Figure 1: Controls and Connections
Commandes et Branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
Bedieningselementen en aansluitingen
Controlli e connessioni
Kontroller och anslutningar
Органы управления и разъемы
RR-AX92
123
456
789
0>10
USB PC-USB AUX 1 AUX 2
COAX1 COAX2 OPT 1 OPT 2
BYPASS
DIM
MENU
EXIT
ENT
ON
OFF
-
+
VOLUME
SPKR BSPKR A
- PRESET +
RPT
RND
PHONO TUNER CD BAL
MUTE
BASS TREBLE BAL
- TUNE +
XLR
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
