RC-995

STEREO CONTROL AMPLIFIER

AMPLIFICATEUR DE COMMANDE STÉRÉO

STEREO-VORVERSTÄRKER

PREAMPLIFICATORE STEREO CON COMANDO A DISTANZA

PREAMPLIFICADOR ESTEREOFONICO

STEREO VOORVERSTERKER

Owner’s Manual

Guide de l’utilisateur

Bedienungsanleitung

Manuale di Istruzioni

Manual de Instrucciones

Gebruiksaanwijzing

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

OF PLUG TO WIDE SLOT. INSERT FULLY.

APPLICABLE FOR USA, CANADA OR WHERE

APPROVED FOR THE USAGE

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE

DANS LA BORNE CORRESPONDANTE DE LA PRISE ET

POUSSER JUSQU AU FOND.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING:

There are no user serviceable parts inside. Refer all servicing to

qualified service personnel.

WARNING:

To reduce the risk of fire or electrical shock, do not expose the unit

to moisture or water. Do not allow foreign objects to get into the

enclosure. If the unit is exposed to moisture, or a foreign object

gets into the enclosure, immediately disconnect the power cord

from the wall. Take the unit to a qualified service person for in-

spection and necessary repairs.

Read all the instructions before connecting or operating the unit. Keep this

manual so you can refer to these safety instructions.

Heed all warnings and safety information in these instructions and on the

product itself. Follow all operating instructions.

Clean the unit only with a dry cloth or a vacuum cleaner.

Keep the ventilation inlets on the unit unobstructed. For example, do not place

the unit on a bed, sofa, rug, or similar surface that could block the ventilation

slots. If the unit is placed in a bookcase or cabinet, there must be sufficient

clearance around the unit and ventilation of the cabinet to allow proper cooling.

Keep the unit away from radiators, heat registers, stoves, or any other

appliance that produces heat.

The unit must be connected to a power supply only of the type

and voltage specified on the rear panel of the unit.

Connect the unit to the power outlet only with the supplied 2-pin polarized

power supply cable or an exact equivalent. Do not modify the supplied cable in

any way. Do not attempt to defeat grounding and/or polarization provisions. The

cable should be connected to a 2-pin polarized wall outlet, matching the wide

blade of the plug to the wide slot of the receptacle. Do not use extension cords.

Do not route the power cord where it will be crushed, pinched, bent at severe

angles, exposed to heat, or damaged in any way. Pay particular attention to the

power cord at the plug and where it exits the back of the unit.

The power cord should be unplugged from the wall outlet if the unit is to be left

unused for a long period of time.

Immediately stop using the unit and have it inspected and/or serviced by a

qualified service agency if:

• The power supply cord or plug has been damaged.

• Objects have fallen, or liquid has been spilled, into the unit.

• The unit has been exposed to rain.

• The unit shows signs of improper operation

• The unit has been dropped or damaged in any way

Place the unit on a fixed, level surface strong

enough to support its weight. Do not place the

unit on a moveable cart that could tip over.

This symbol is to alert the user to the

presence of uninsulated dangerous

voltages inside the product's enclosure

that may constitute a risk of electric shock.

This symbol is to alert the user to important

operating and maintenance (service)

instructions in this manual and literature

accompanying the product.

Figure 1: Controls and Connections

Commandes et prises

Bedienelemente und Anschlüsse

Controlli e Collegamenti

Controles y Conexiones

De bedieningsorganen en de ingangen voor de bronnen

TAPE 1

IN OUT

AUXVIDEO TUNERCDPHONO

TAPE 2

IN OUT

OUTPUTS

1 2

LEFT

RIGHT

LEFT

RIGHT

MODEL NO. RC-995

OFFON

BALANCED OUTPUTS

SWIT CHED 400W MAX

POWER

SERIAL NO.

9 10 11

2 3 5 7 864

Figure 2: RCA Cable Connections

Branchement des câbles à prises RCA

Anschluß der Endstufe über Cinch-Kabel

Collegamenti cavi RCA

Conexiones RCA

De ongebalanceerde (cinch) verbindingen met de eindversterker

SERIAL NO .

LEFTRIGHT

SPEAKERS

WARNING:TO REDUCE THE RISK OF FIRE

OR LECT RICAL SHOCK, DO NOT EXPOSE

T HIS EQUIPMENT TO RAIN OR MOIST URE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

AVIS: RISQUE DE CHOC ELECTRIQUE–NE PAS OUV IR

SPEAKER IMPEDANCE

ST EREO 4 OHMS MINIMUM

BRIDGED 8 OHMS MINIMUM

POWER AMPLIFIER

MODEL NO. RB-981

POWER CONSUMPTION: 400W

SERIAL NO .

LEFT NPUTRIGHT INPUT

ROTEL RB-981

ROTEL RC-995

T APE 1

IN OUT

AUXVIDEO T UNERCDPHON O

T APE 2

IN OUT

OUT PU T S

LEFT

RIGHT

LEFT

RIGHT

MODEL NO . RC-995

OFFON

BALANC ED OUT PUT S

SWITC HED 400W MAX

POWER

STEREO CONTROL AMPLIFIER RC-995
