Sida 1/10

POWER

ST EREO COMPACT DISC PLAYER RCD-951

RANDOMREVIEWPROG

T IMESC ANREPTHDCD

OPE N/CLS PLAY ST OP PAUSE T RACK

REMAIN

PROGRAM REPEAT 1 ALL

MIN SEC

RANDOM

OVER

INT RO 1 2 3 4

5678

9 10 11 12

13 14 15 16

RCD-951

STEREO COMPACT DISC PLAYER

STEREO-CD-PLAYER

LECTEUR DE DISQUES COMPACTS STÉRÉO

LECTOR DE DISCOS COMPACTOS

Owner’s Manual

Guide d’utilisation

Bedienungsanleitung

Manual de Instrucciones

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE

OF PLUG TO WIDE SLOT. INSERT FULLY.

APPLICABLE FOR USA, CANADA OR WHERE

APPROVED FOR THE USAGE

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE

DANS LA BORNE CORRESPONDANTE DE LA PRISE ET

POUSSER JUSQU AU FOND.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING:

There are no user serviceable parts inside. Refer all servicing to

qualified service personnel.

WARNING:

To reduce the risk of fire or electric shock, do not expose the

RCD-951 to moisture or water. Do not allow foreign objects to get

into the enclosure. If the unit is exposed to moisture, or a foreign

object gets into the enclosure, immediately disconnect the power

cord from the wall. Take the unit to a qualified service person for

inspection and necessary repairs.

Read all the instructions before connecting or operating the RCD-951. Keep this

manual so you can refer to these safety instructions.

Heed all warnings and safety information in these instructions and on the

product itself. Follow all operating instructions.

Clean the RCD-951 only with a dry cloth or a vacuum cleaner.

Keep the ventilation inlets on the unit unobstructed. For example, do not place

the unit on a bed, sofa, rug, or similar surface that could block the ventilation

slots. If the RCD-951 is placed in a bookcase or cabinet, there must be sufficient

clearance around the unit and ventilation of the cabinet to allow proper cooling.

Keep the RCD-951 away from radiators, heat registers, stoves, or any other

appliance that produces heat.

The RCD-951 must be connected to a power supply only of the type and voltage

specified on the rear panel of the unit.

Connect the RCD-951 to the power outlet only with the supplied 2-pin polarized

power supply cable or an exact equivalent. Do not modify the supplied cable in

any way. Do not attempt to defeat grounding and/or polarization provisions. The

cable should be connected to a 2-pin polarized wall outlet, matching the wide

blade of the plug to the wide slot of the receptacle. Do not use extension cords.

Do not route the power cord where it will be crushed, pinched, bent at severe

angles, exposed to heat, or damaged in any way. Pay particular attention to the

power cord at the plug and where it exits the back of the unit.

The power cord should be unplugged from the wall outlet if the unit is to be left

unused for a long period of time.

Immediately stop using the RCD-951 and have it inspected and/or serviced by a

qualified service agency if:

• The power supply cord or plug has been damaged.

• Objects have fallen into or liquid has been spilled into the unit.

• The unit has been exposed to rain.

• The unit shows signs of improper operation

• The unit has been dropped or damaged in any way

Place the RCD-951 on a fixed, level surface strong

enough to support its weight. Do not place the

RCD-951 on a moveable cart that could tip over.

This symbol is to alert the user to the

presence of uninsulated dangerous

voltages inside the product's enclosure

that may constitute a risk of electric shock.

This symbol is to alert the user to important

operating and maintenance (service)

instructions in this manual and literature

accompanying the product.

DANGER: INVISIBLE LASER RADIATION WHEN YOU OPEN THE

TOP COVER. AVOID DIRECT EXPOSURE TO LASER BEAM.

CLASS 1 LASER PRODUCT

Complies with DHHS 21 CFR 1040.10 and 1040.11

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR

PERFORMANCE OF PROCEDURES OTHER THAN THOSE

SPECIFIED IN THIS MANUAL MAY RESULT IN HAZARDOUS

RADIATION EXPOSURE.

COMPACT DISC PLAYER

MODEL NO. RCD-951

POWER CONSUMPTION: 20W

RCD-951

POWER

STEREO COMPACT DISC PLAYER RCD-951

WARNING:

TO REDUCE T HE RISK OF FIRE

OR ELECTRICAL SHOCK, DO NOT EXPOSE

THIS EQUIPMENT TO RAIN OR MOISTURE.

DIGITAL

OUTPUT

CLASS 1

LASER PRODUCT

PRODUCT COMPLIES WITH DHHS

21 CFR 1040.10 AND 1040.11

RIGHT LEFT

OUTPUT

ANALOG

RANDOMREVIEWPROG

TIMESCANREPTHDCD

OPEN/CLS PLAY ST OP PAUSE TRACK

REMAIN

PROGRAM REPEAT 1 ALL

MIN SEC

RANDOM

OVER

INT RO 1 2 3 4

5 6 7 8

9 10 11 12

13 14 15 16

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

AVIS:

RISQUE DE CHOC ELECTRIQUE–NE PAS OUVRIR

1 2

14 16

3 4

8 9 10 11

12 13 15 17

18 19 20

6 7

RR-D91

SCAN

CLEARREPT

OPN/CLS TIME

1 32

456

789

10 PROG

RANDOM TRACK

STOP PAUSE PLAY

REV

>10

Figure 1: Controls and Connections / German Translation?

Commandes et prises de connexion / Controles y Conexiones
