LR1A INSTRUCTION MANUAL
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-800-359-5520 (UK: 0800-056-2853) We’re ready to help!
2
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE
1/8 in.
(3 mm)
7/16 in.
(11 mm)
Thank you for choosing the LR1A in-wall mount.
The LR1A in-wall mount is designed to be used with VSF415 or MF215 adjustable arm wall mounts. Range of motion and size limitations will vary
depending on the adjustable arm wall mount selected; the maximum extension of the arm will be reduced by 9 cm (3 1/2 in.) when using the LR1A.
VSF415: The weight of the monitor and adjustable arm wall mount must not exceed 22.7 kg (50 lb).
MF215: The weight of the monitor and adjustable arm wall mount must not exceed 27.2 kg (60 lb).
CAUTION: Avoid potential personal injuries and property damage!
Do not use this product for any purpose not explicitly specified by manufacturer.
The wall must be capable of supporting five times the weight of the monitor and mount combined.
This product is designed for use in wood frame walls only!
If you do not understand these instructions, or have doubts about the safety of the installation, assembly or use of this product,
contact manufacturer Customer Service or call a qualified contractor.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
WARNING: DO NOT INSTALL THIS ACCESSORY IN A FIREWALL. Contact your local building inspector before cutting a hole in the
drywall if unsure.
Tools
Needed
3
Supplied Parts and Hardware
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included
and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
Housing
Wall Mount Adapter
Housing Template
3/16 in.
1/4 in.
03 x6
09 x207 x8
06 x8
05 x6
10 x1
Quick Shim
Fastener
Washer
Hex Key
Hex Key
Screw
[Junction Box]
Button Head Screw
[Wall Mount Adapter]
Parts for STEP 1
Hardware for STEP 4
Parts and Hardware for STEP 2
Parts and Hardware for STEP 5
Hardware for STEP 3
08 x1
01 x1 02 x1 04 x1
Lag Bolt
#6-20 x 3/8 in.
1/4 x 2 1/2 in.
5/16-18 x 5/8 in.
