INSTRUCTION MANUAL
Texto en español, página 16 Deutscher Text Seiten 22 Svensk text sida 28
中文文字说明请参见第 34 页
Texte français page 19 Nederlandse tekst op pagina 25
Русский текст: стр. 37
日本語は 31 ページ
Scan for easy install video
SANUS.com/3002
We’ll Make It Stress-Free
If you have any questions along
the way, just give us a call.
• US: +1 (800) 359-5520
• EMEA: +31 (0) 495 580 852
• UK: +44 (0) 800 056 2853
• AUS: +61 (0) 7 3299 7000
We’re ready to help!
2
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE
Before getting started, let’s make sure this mount is perfect for you!
No
—
Perfect!
Yes
—
This mount is NOT compatible.
Visit decora.sanus.com or call US: +1 (800) 359-5520 • EMEA: +31 (0) 495 580 852
• UK: +44 (0) 800 056 2853 • AUS: +61 (0) 7 3299 7000 to find a compatible mount.
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Also check your TV owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service at
US: +1 (800) 359-5520 • EMEA: +31 (0) 495 580 852 • UK: +44 (0) 800 056 2853 • AUS: +61 (0) 7 3299 7000.
Do you have
all the tools
needed?
1
2
3
4
What is your
wall made of?
80 lbs.
(36.2 kg)
Ready to begin?
Does your TV
(including accessories)
weigh more than
80 lbs. (36.2 kg)?
CAUTION:
DO NOT install into
drywall alone
Unsure?Drywall with
wood studs?
Solid concrete or
concrete block?
Call Customer Service
Perfect!
CAUTION: Avoid potential personal injuries and property damage!
●This product is designed for use in wood stud, solid concrete, and concrete block walls - DO NOT install into drywall alone
●The wall must be capable of supporting five times the weight of the TV and mount combined
●Do not use this product for any purpose not explicitly specified by manufacturer
●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
Wood Stud Install
Concrete Install
Awl
Pencil Level Stud Finder
Screwdriver
Tape
Measure
7/32 in.
(5.5 mm)
Wood
Drill Bit
Electric Drill
Hammer
1/2 in.
(13 mm)
Socket
Wrench Drill Bit
3/8 in.
(10 mm)
Concrete
Concrete Installation Kit Required (not included)
3
Dimensions
1.97in
50mm
MIN
15.75in
400mm
MAX
15.75in
400mm
MAX
1.97in
50mm
MIN
15.42in
391.7mm
2.93in
74.4mm
0.75in
19.1mm
3.91in
99.4mm
17.78in
451.6mm
6.50in
165.2mm
4.00in
101.6mm
16.93in
430mm
18.26in
463.8mm
0.38in
9.7mm
OFFSET
1.5°
LEVEL
ADJUST
5deg
UP
2.04in
51.9mm
LEVEL ADJUST SCREW
7.87in
200mm
LATERAL SHIFT
AT 200MM VESA
TV INTERFACE
WALL PLATE
FRONT VIEW - LATERAL SHIFT
3-D
SIDE VIEW
SIDE VIEW - TILT
FRONT VIEW - ROLL & CENTER OFFSET
FULLY ASSEMBLED MOUNT
10deg
DOWN
