VODLF125-B2
INSTRUCTION MANUAL
WE’RE HERE TO HELP
Our US-based install experts
are standing by to help.
Call us at:
US: +1 (800) 359-5520
EMEA: +31 (0) 495 580 852
UK: +44 (0) 800 056 2853
Get it right the first time.
HeightFinder™ shows you
where to drill.
Check it out at:
SANUS.com/2567
Want to watch a video that
shows how easy this DIY
project will be?
Watch it now at:
SANUS.com/3124
Texto en español, gina 14 Deutscher Text Seiten 18 Svensk text sida 22
中文文字说明请参见第 26
Texte français page 16 Nederlandse tekst op pagina 20
Русский текст: стр. 24 日本語は 28
2
120 lb
(54.4 kg)
IMPORTANT SAFETY INSTRUCTIONSPLEASE READ MANUAL PRIOR TO USE SAVE THESE INSTRUCTIONS
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Check your TV owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service at +1-800-359-5520 (EMEA: +31 (0) 495 580 852; UK: +44 (0) 800 056 2853).
CAUTION: Avoid potential personal injuries and property damage!
This product is designed ONLY to be installed into wood studs, solid concrete or concrete block.
— DO NOT INSTALL INTO DRYWALL ALONE — DRYWALL ALONE WILL NOT HOLD THE WEIGHT OF YOUR TV .
The wall must be capable of supporting five times the weight of the TV and mount combined.
Do not use this product for any purpose not explicitly specified by manufacturer.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
TV Weight Limit
(including accessories)
DO NOT EXCEED
If your TV (including accessories) exceeds
this weight, this mount is NOT compatible.
Visit SANUS.com or call customer service to
find a compatible mount.
US: +1-800-359-5520
EMEA: +31 (0) 495 580 852
UK: +44 (0) 800 056 2853)
Call Customer Service
1-800-359-5520
Tools Needed
Wall
Construction
ONLY install on
these acceptable
wall types. Drywall alone
will NOT hold
the weight of
your TV.
Unsure?
Wood concretestuds Solid or
concrete block
Perfect!
Wood Stud Install
Concrete Install
Awl
Pencil Level Tape
Stud
Finder
ScrewdriverTape
Measure
7/32 in.
(5.5 mm)
Wood
Drill Bit
Electric
Drill
Hammer
1/2 in.
(13 mm)
Socket
Wrench
Drill Bit
3/8 in.
(10 mm)
Concrete
CAUTION:
DO NOT install
in drywall alone
Concrete Anchor Kit
#CMK1 is required
(not included)
Contact Customer Service
to inquire about the
CMK1 Concrete Anchor Kit.
3
3.94in
100mm
MIN
15.75in
400mm
MAX
3.94in
100mm
MIN
23.62in
600mm
MAX
10.36in
263.1mm
1.77in
45mm
16.00in
406.4mm
17.01in
432mm
26.97in
685.1mm
2.74in
69.5mm
7deg
UP
13deg
DOWN
25.0in
634mm
44deg 44deg
SIMULATED 65"
FLAT SCREEN TV
79,17(5)$&(
:$//3/$7(
7239,(:(;7(1'('
熆'
6,'(9,(:(;7(1'('
6,'(9,(:5(75$&7('7239,(:5(75$&7('
)8//<$66(0%/('02817
Dimensions
BEFORE YOU BEGIN
Remove the stand
from your TV if attached.
Install any accessories
you may have purchased, if they
require TV removal prior to assembly.
The TV is removable for future
accessory purchases.
Soft clean surface
Protect the face
of your TV when laying it
down for installation.
