WSSMM
1
INDOOR/OUTDOOR MOUNT FOR
SONOS® MOVE
INSTRUCTION MANUAL
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call.
P: 800-359-5520 UK: (0) 800 056 2853 EMEA: +31 (0) 495 580 852
We’re ready to help!
2
IMPORTANT SAFETY INSTRUCTIONS PLEASE READ ENTIRE MANUAL PRIOR TO USE SAVE THESE INSTRUCTIONS CAUTION: — —
This mount is designed to support the Sonos
® Move™ speaker.
CAUTION: Avoid potential personal injuries and property damage!
Check your speaker owners manual to see if there are any special requirements for mounting your speaker.
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Do not use this product for any purpose not explicitly specified by manufacturer.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
The wood stud or drywall must have a minimum thickness of 1¾ inch (44 mm) and must be capable of supporting five times the
weight of the speaker and mount combined.
Warrantied for outdoor use; UV-resistant plastics fight against sun damage; Galvanized plating and stainless steel hardware prevents against
corrosion and leads to longer life of the mount.
Outdoor primer protects against rusting and provides better paint adhesion; outdoor-rated paint meets AAMA 2604-05 Standard for 5-year
color retention and chalk resistance.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service.
Before getting started, lets make sure this product is perfect for you!
6.7 lbs.
(3.0 kg)
Speaker Weight Limit
DO NOT EXCEED
Tools
Needed
Wood Stud Install
Awl
Pencil Level Stud Finder
Screwdriver Wood Drill Bit
Electric Drill
Sonos® Move
3/8 in.
(10 mm)
1/8 in.
(3 mm)
Drywall Install
Hammer Drill Bit
3
2.28in
58mm
3.01in
76.3mm
0.48in
12.1mm
0.51in
13mm
0.22in
5.5mm
0.52in
13.1mm
0.31in
8mm
4.91in
124.8mm
3.59in
91.2mm
0.63in
16.1mm
0.12in
3mm
3.01in
76.5mm
7.04in
178.8mm
9.42in
239.2mm
6.85in
174mm
6.89in
175mm
3D VIEW FRONT
3D VIEW REAR
FIXED MOUNT - TOP VIEW
FIXED MOUNT - SIDE VIEW
FIXED MOUNT - FRONT VIEW
Dimensions
