Sida 1/23
WSWM
E11
and WSWM
E12
Tilt & Swivel Speaker Wall Mount
For SONOS® Era 100
INSTRUCTION MANUAL
Texto en español, página 20 Deutscher Text Seiten 24 Svensk text sida 28 中文文字说明请参见第 32 页
Texte français page 22 Nederlandse tekst op pagina 26 Русский текст: стр. 30 日本語は 34
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call.
US: +1 (800) 359-5520 +31 (0) 495 580 852 +44 (0) 800 056 2853 EMEA: UK:
We’re ready to help!
2
5 lbs.
(2.2 kg)
Speaker Weight Limit
DO NOT EXCEED
Tools
Needed
Wood Stud Install
Concrete Install
Awl
Pencil Level Stud Finder
Screwdriver Drill Bit
Electric Drill
Hammer Drill Bit
1/4 in.
(6.5 mm)
Masonry
1/4 in.
(6.5 mm)
1/8 in.
(3 mm)
Wood
Drywall Install
Hammer Drill Bit
CAUTION: Avoid potential personal injuries and property damage!
Check your speaker owner’s manual to see if there are any special requirements for mounting your speaker.
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Do not use this product for any purpose not explicitly specified by manufacturer.
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
The wall must be capable of supporting five times the weight of the speaker and mount combined.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service at +1 (800) 359-5520 (EMEA: +31 (0) 495 580 852; UK: +44 (0) 800 056 2853).
This mount is designed to support only Sonos® Era 100™ speakers.
Before getting started, lets make sure this product is perfect for you!
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ENTIRE MANUAL PRIOR TO USE SAVE THESE INSTRUCTIONS— —
3














3.00in
76.1mm
0.26in
6.6mm
1.73in
44mm
0.22in
5.6mm
3.50in
88.9mm
3.94in
100mm
7.36in
186.9mm
0.84in
21.3mm
1.17in
29.8mm
2.31in
58.8mm
2.64in
66.9mm
5.88in
149.3mm
2.32in
59mm
1.97in
50mm
4.04in
102.7mm
Dimensions
