User Ma nual

Ultracompact 2.4GHz

Dual-Channel Wireless

Microphone System

Blink500

General Introduction

The Saramonic Blink500 is an incredibly lightweight,

ultracompact and easy-to-use 2-person wireless

microphone system for DSLR, Mirrorless and Video

cameras, or mobile devices that delivers detailed,

broadcast-quality sound.

The system series is comprised of three different

receivers. The RX receiver has a 3.5mm output and

includes TRS and TRRS output cables, allowing it to work

with any device with a 3.5mm audio input. The RXDi

receiver has a MFi Certiﬁed Lightning output and is

designed for Apple iOS devices. And the RXUC receiver

has a USB-C output and is designed for devices with a

USB-C port, including Android smartphones and tablets.

The clip-on transmitter has a great sounding built-in mic

and it is small and light enough to clip to shirts and

clothing, or you can use it as a traditional beltpack

transmitter with the included SR-M1 professional lavalier

microphone.

No technical knowledge of audio is required to operate.

The Blink500 system operates on the interference-free

2.4GHz spectrum and automatically hops to free channels

to avoid static noise and audio dropouts.

There are six kits available

① Power Key

Long press to turn on or off the receiver.

② Power and Pairing Indicator

Power Functions:

Solid Red Light = Low Battery

Pairing Functions:

Flashing Blue Light (every one second) = Unpaired

Quick Flashing Blue Light (every 0.5 second) = Waiting for

Pairing

Solid Blue Light = Paired Successfully

Once the receiver and transmitter are paired, they will be

connected with each other automatically, even when

powered off and on.

③ USB Type-C Charging Port

Product Structure

1. Blink500 RX: Clip-On and Shoe-Mountable Receiver

135

④ Charge Indicator
