Sida 1/2
www.saramonic.com
The Saramonic logo is trademark which is registered
and owned by Saramonic International.
COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL
A brand of DSQN
Email: info@saramonic.com
2.2 Attach the Vmic to your camera’s or camcorder’s hot shoe. Connect
the supplied audio transmission line from Vmic’s audio output to the MIC
input of the camera or camcorder.
9
7
8
9
7
8
1
2
Audio output jack
Headphone output
Battery compartment
2 Set Up Guide
2.1 Install the battery
Lock the battery compartment
Unlock the battery compartment
Insert the AA batteries into place aligning + and - polarity as shown.
Vmic
The Saramonic Vmic is a b oadcast quality condenser microphone r
that provides professional audio with DSLR cameras and camcorders.
1 Product Introduction
1.1 General Introductions
The Vmic is a broadcast quality condenser microphone that provides
professional audio with DSLR cameras and camcorders. The Vmic allows
you to adjust level control (-10dB, 0dB, +20dB), high-pass filter(150 Hz), and
high-frequency boost(+6dB) to increase intelligibility of dialogue. The
detachable 3.5mm cable connects the Vmic to the audio input of the
camera, while the stereo headphone output allows you to monitor the
incoming audio. The shock mount system provides isolation from
vibration and mechanical noise.
1.2 Highlights
• Super-cardioid polar pattern
• Integrated shock mount system
• High pass filter (150 Hz)
• High frequency boost (+6dB)
• Three position level control (-10dB, 0dB, +20dB)
• Headphone monitor output
• 1/8’’ audio output jack to camera
• LED power on/low battery indicator
• Wind shield included
• Lightweight all-mental construction
• Powered by two AA batteries
1.3 Product Structure
Three position level control (-10dB, 0dB, +20dB)
LED indicator
Power button
High frequency boost (+6dB)
High-pass filter (150Hz)
To attenuate signals with frequencies lower than 150 Hz. It can be used
to remove rumble or other low frequency noise while recording.
Integrated shock mount
1
2
3
4
5
6
1
2
3
4
5
6
2.3 Turn on your camera and long press the power button to turn the
Vmic on, the LED indicator will turn green. When the battery power is
low, the LED indicator will turn red.
2.4 Adjust the level control according to your needs.
The -10dB level is ideal for recording loud sound sources, such as live
music, motorsport, or interviews where the subject is very close to
the camera.
The +20dB level boost is designed for use with DSLR cameras,
allowing the user to reduce the camera's preamp level (or mic-input
level), effectively reducing the amount of noise generated by the
camera's comparatively low quality audio circuitry.
2.5 Plug a headphone to the headphone output of the Vmic, then you
can monitor the audio.
We suggest you could do a test recording and playback the audio to
see if it is acceptable.
3. Specification
Type Condenser Microphone (Unidirectional)
Polar Pattern Super-cardioid
Frequency Response 35-20kHZ
Sensitivity -40dB +/- 1dB / 0dB=1V/Pa, 1kHz
Signal to Noise Ratio 75dB or more
Output Impedance 200Ohm or less
Power Two AA batteries
Plug Mini-pin plug (3.5mm)
Filter High-pass filter (150Hz)
Dimensions(L*H*D) 255 x 66 x 80 mm
Net Weight 196g (6.9 oz.)
www.saramonic.com
The Saramonic logo is trademark which is registered
and owned by Saramonic International.
COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL
A brand of DSQN
Email: info@saramonic.com
4. Packing List
• One Vmic main unit
• One foam windshield
• One signal transmission line
• User manual
• Warranty card
Frequency Response
Polar Pattern
Vmic
The Saramonic Vmic is a b oadcast quality condenser microphone r
that provides professional audio with DSLR cameras and camcorders.
