Sida 1/10
APD-200
Wireless passive infrared detector
Firmware version -200_ 03/ 1.00 apd en 21
SATEL sp. z o.o. ul. Budowlanych 66 - POLAND • • 80 298 Gdańsk •
tel. +48 58 320 94 00
www.satel.eu
IMPORTANT
The device should be installed by qualied personnel.
Prior to installation, please read carefully this manual.
Changes, modications or repairs not authorized by the manufacturer shall void your rights
under the warranty.
The rating plate of the device is located on the enclosure base.
SATEL aims to continually improve the quality of its products, which may result in changes in
their technical specications and software. Current information about the changes being
introduced is available on our website.
Please visit us at:
https://support.satel.eu
Hereby, SATEL sp. z o.o. declares that the radio equipment type APD-200 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: www.satel.eu/ce
In the EU, th radio equipment is only permitted to operate in the 868 MHz frequency is
band.
The following symbols may be used in this manual:
- note,
- caution.
The APD-200 detector can detect motion in a protected area. It is designed for operation
within the ABAX 2 / ABAX two-way wireless system. This manual applies to the detector with
rmware version 1.00 (or newer), which is supported by:
ABAX 2:
– ACU-220 / ACU-280 controller,
– ARU-200 repeater.
ABAX:
– ACU-120 / ACU-270 controller (rmware version 5.04 or newer),
– ARU-100 repeater (rmware version 2.02 or newer),
– INTEGRA 128-WRL control panel (rmware version 1.19 or newer and rmware
version of processor used to operate ABAX system 3.10 or newer).
1 Features
Dual element pyrosensor.
Digital motion detection algorithm.
Digital temperature compensation.
Option to enable / disable the creep zone protection.
Ability to replace the lens with a curtain or long-range one.
Encrypted two-way radio communication in the 868 MHz / MHz frequency band (AES 915
standard for the ABAX 2 system).
Transmission channel diversity 4 channels for automatic selection of the one that will –
enable transmission without interference with other signals in the 868 MHz / M 915 Hz
frequency band (ABAX 2 system only).
Remote update of detector rmware (ABAX 2 system only).
Remote conguration.
Built-in temperature sensor (temperature measurement range from - 10°C to +55°C).
LED indicators.
Supervision of motion detection system.
2 system only). “ECO” option for longer battery life (ABAX
Battery status control.
Tamper protection against enclosure opening and removal from mounting surface.
Adjustable mounting bracket included.
2 Specifications
Operating frequency band ............................... 868.0 MHz MHz / 915 MHz 928 MHz ÷868.6 –
Radio communication range (in open area)
ABAX 2
ACU- 220.............................................................................................. up to 2000 m
ACU- 280.............................................................................................. up to 1600 m
ABAX .............................................................................................................. up to 500 m
Battery ................................................................................................................... CR123A 3 V
Battery life expectancy .......................................................................................... up to 2 years
Temperature measurement range ....................................................................... - 10°C...+55°C
