Installation Sheet 02-16006-22-en,May 2021 |1
SpaceLogic™ Central IO
I/O Module Models
Regulatory Compliance and Safety Information
Electrical equipment should be installed,operated,serviced,and maintained only by qualified personnel.No responsibility is assumed by
Schneider Electric for any consequences arising out of the use of this material.
Carefully read these instructions and all information relevant for this product before trying to install it.See the list of technical literature.
The technical literature and declarations of conformity can be accessed on the Schneider Electric Exchange website,ecobuilding.schneider-
electric.com.Contact your local Schneider Electric sales office for a hard copy of the documentation or for additional information.
Technical Literature
• SpaceLogic Hardware Reference Guide, 04-XX001-XX-en
• EcoStruxure Building Management -Smoke Control System Design Guide, 04-16014-XX-en
Dimensions
Installing the Module
WARNING
HAZARDHAZARD OFOF ELECTRICELECTRIC SHOCKSHOCK OROR EQUIPMENTEQUIPMENT DAMAGEDAMAGE
Install only the module type that is indicated on the label on the
terminal base backplane.
FailureFailure toto followfollow thesethese instructionsinstructions cancan resultresult inin death,death,seriousserious
injury,injury,oror equipmentequipment damage.damage.
Labeling the Module
02-16006-22-en,May 2021 |2
www.se.com/buildings
©2021 Schneider Electric.All rights reserved.Trademarks and registered trademarks are the property of their respective owners.
Smoke Control Application Note
All Universal Inputs (UI), Digital Inputs (DI), and Analog Outputs
(AO)are power-limited per UL 864 requirements.All Digital Output
(DO)relays are non-power-limited.For more information on the use
of the I/O modules for a UL 864 smoke control application,see the
latest version of the EcoStruxure Building Management -Smoke
Control System Design Guide (04-16014-XX-en).
Terminal Base for All Central IOs
DeviceDevice PartPart numbernumber
TB-IO-W1Terminal Base SXWTBIOW110001
Specifications
Operation environment
AmbientAmbient temperature,temperature,operatingoperating
0to 50 °C(32 to 122 °F)
HumidityHumidity
Maximum 95 % RH non-condensing
Mechanical
IngressIngress protectionprotection ratingrating
IP 20
PlasticPlastic flameflame ratingrating
UL94-5VB
Electrical
I/OI/O busbus powerpower
24 VDC max. 30 W per I/O bus power
supply,Class 2
MaximumMaximum addressesaddresses perper I/OI/O busbus
32
AO-8 (-H)Module
DCDC inputinput powerpower
24 VDC , 4.9 W
OutputOutput ratingrating
0to 10 VDC , 0 to 20 mA
ChannelsChannels
8output
AO-V-8 (-H)Module
DCDC inputinput powerpower
24 VDC , 0.7 W
OutputOutput ratingrating
0to 10 VDC
ChannelsChannels
8output
DI-16 Module
DCDC inputinput powerpower
24 VDC , 1.6 W
InputInput ratingrating
24 V, 2.4 mA
ChannelsChannels
16 input
UI-16 Module
DCDC inputinput powerpower
24 VDC , 1.8 W
InputInput ratingrating
24 V, 2.4 mA
ChannelsChannels
16 input
RTD-DI-16 Module
DCDC inputinput powerpower
24 VDC , 1.6 W
InputInput ratingrating
24 V, 2.4 mA
ChannelsChannels
16 input
UI-8/DO-FC-4 (-H)Module
DCDC inputinput powerpower
24 VDC , 1.9 W
RelayRelay contactcontact ratingrating
250 VAC / 30 VDC , 3 A
Pilot Duty (Power Factor 0.35)
InputInput ratingrating
24 V, 2.4 mA
ChannelsChannels
4output/8 input
UI-8/AO-4 (-H)Module
DCDC inputinput powerpower
24 VDC , 3.2 W
OutputOutput ratingrating
0to 10 VDC , 0 to 20 mA
InputInput ratingrating
24 V, 2.4 mA
ChannelsChannels
4output/8 input
UI-8/AO-V-4 (-H)Module
DCDC inputinput powerpower
24 VDC , 1.0 W
OutputOutput ratingrating
0to 10 VDC
InputInput ratingrating
24 V, 2.4 mA
ChannelsChannels
4output/8 input
DO-FA-12(-H)Module
DCDC inputinput powerpower
24 VDC , 1.8 W
RelayRelay contactcontact ratingrating
250 VAC / 30 VDC , 2 A
Pilot Duty (Power Factor 0.35)
ChannelsChannels
12 output
DO-FC-8 (-H)Module
DCDC inputinput powerpower
24 VDC , 2.2 W
RelayRelay contactcontact ratingrating
250 VAC / 30 VDC , 3 A
Pilot Duty (Power Factor 0.35)
ChannelsChannels
8output
Addendum -California Proposition 65 Warning Statement for California Residents
WARNING:WARNING:This product can expose you to chemicals including lead which is known to the State of California
to cause cancer and which is known to the State of California to cause birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
