TABLE OF CONTENTS

1. Introduction

2. Delivery contents

3. Using the IPCAM for the ﬁ rst time

3.1 App installation

3.2 Connecting the IPCAM to WLAN

3.3 Connecting the IPCAM via WPS

3.4 Operating previously conﬁ gured IPCAMs again

3.5 Adding IPCAMs that are set up for operation to the app

4. General troubleshooting

5. Technical speciﬁ cations

1. INTRODUCTION

Congratulations and thank you for purchasing the Schwaiger

IPCAM310M.

This user manual should assist you in handling and operating

the network camera. Please make sure that you ﬁ rst become

familiar with the characteristics of your IPCAM and WLAN

router to rule out potential sources of error.

2. DELIVERY CONTENTS

»1x camera (IPCAM310M)

»1x holder

»1x power supply

»1x user manual

3. USING THE IPCAM FOR THE FIRST TIME

3.1 APP INSTALLATION

Download and install the „UCare Cam” app. You can ﬁ nd the

app in Google Play or the app store for your smartphone. You

require at least Android 4.0 or IOS 5.0 to ensure full compa-

tibility between the app and your smartphone´s operating

system.

iOS Android

App Store

“uCare Cam” Download Link

Google Play Store

“uCare Cam” Download Link

IPCam Passwort: 0000

Benutzer Passwort: admin

Passwort: 0000

3.2 CONNECTING THE IPCAM TO WLAN

Use the delivered connection cable to operate your IPCAM for

the ﬁ rst time before subsequently establishing a connection

between the network camera and the network.

Step 1

After the camera has been connected to the electricity, wait

until the red and green LEDs alternately light up.

If only one of the two LEDs lights up after 1 minute, hold

down the Reset/WPS button for approximately 10 seconds.

The camera will then restart and try to establish a connection

again.

Step 2

As soon as the LEDs alternately light up, you can search for

the network „WIFI-CAM-p2p” in the WLAN settings in your

terminal device and establish a connection to it.

Step 3

Open the „UCare Cam” app and select „WIFI Connect” at the

lower edge of the display.

Activate the „Router Mode” and press „Next” until you can see

a picture of your IPCAM.

Select „Next” once more. You will now be requested to enter

the name (SSID) and the password of your available WLAN

network. In the ﬁ nal window you can give your IPCAM a

name and a password.

Once the setup is complete, the IPCAM will connect itself to

your WLAN. This can take several minutes. If a connection

cannot be established, reset the IPCAM by holding down the

Reset/WPS button and make sure the SSID and password of

your WLAN network have been entered correctly.

3.3 CONNECTING THE IPCAM VIA WPS

You can also connect the IPCAM via WPS if your WLAN router

supports WPS.

Step 1

Use the delivered connection cable to operate your IPCAM for

the ﬁ rst time.

Wait until the red and green LEDs alternately light up (ca. 15

seconds).

If only one of the two LEDs lights up after 1 minute, hold

down the Reset/WPS button for approximately 10 seconds.

The camera will then restart and try to establish a connection

again.

Step 2

As soon as the LEDs alternately light up, hold down the

Reset/WPS button for 2 seconds and activate the WPS

function in your WLAN device. With successful WLAN-Router-

verbindung both LED’s (red green) shine at the same time.

Step 3

Open the „UCare Cam” app and select „WIFI Connect” at the

lower edge of the display.

Conﬁ rm the „WPS Setup Mode” and press „Next”. The UID

and IP address of your IPCAM will now be displayed; select

them. In the ﬁ nal window you can give your IPCAM a name

and a password.

Once the setup is completed, the IPCAM will connect itself to

your WLAN.

3.4 OPERATING A PREVIOUSLY CONFIGURED

IPCAM AGAIN

Your IPCam will connect itself automatically to the WLAN

network again when you turn it on. If this does not happen,

connect the IPCam again by following the instructions listed

in sections 3.2 or 3.3.

3.5

ADDING IPCAMS THAT ARE SET UP FOR

OPERATION TO THE APP

Start the app and select „Import Installed WIFICAM”. You now

have 3 options.

Option 1 Option 2 Option 3

You can manually

enter the UID found

on the back of

the IPCAM as well

as the name and

password of the

IPCAM.

You can use the

menu item „Scan

Camera´s UID in

Intranet”. Your

WLAN will search for

existing IPCAMs.

You can select

„Scan Camera QR

Code”. The QR

code on the back of

your IPCam will be

scanned here. To

scan the QR code,

hold the terminal

device´s camera

over the QR code.

4. GENERAL TROUBLESHOOTING

Disconnect the device from the electricity for 10 seconds.

You can reset the settings in your IPCAM by holding down the

Reset/WPA button for approximately 10 seconds.

Make sure that the IPCAM is within the range of your WLAN

router.

5. TECHNICAL SPECIFICATIONS

Frequency Band 2.400~2.4835GHz

2.4GHz Antenna omni-directional antenna

Compression M-JPEG

Image Sensor 1/4” color CMOS

View Angle Lens: f3.6mm

Horizontal: 39.3°

Vertical: 26.8°

Diagonal: 46.5°

Pan Range 300° (Left 175° ~ Right 175°)

Tilt Range 110° (Up 90° ~ Down 20°)

Resolution VGA 640x480 / QVGA 320x240

Frame Rate 1~25 fps

Alarm Motion Detection /Sound Detection/

Email Alarm / Smartphone Notify

Message

Microphone Electronic Condenser

Wireless Security WEP & WPA WPA2 Encryption

Wireless Standard WiFi 802.11 b/g/n

Audio Input Built-in Microphone

IR-LED night vision 10 meters (8 infrared LEDs)

3 Alarm Control ports /+5Vin / +5Vout /GND/

LAN Network RJ45 Interface

Dimensions 90mm*90mm*130mm

Weight Approx.: 290g

Power supply 5VDC /2A

MANUAL

Motorized WiFi network IP camera

IPCAM 310M

Schwaiger GmbH www.schwaiger.de

Würzburger Str. 17 90579 Langenzenn

Irrtümer, Abweichungen und Änderungen bei den technischen

Angaben und Abbildungen vorbehalten. All technical data and

illustrations are subject to error s, deviations & modiﬁ cations. 0700
