Features

New sleek, contemporary styling. A perfect match to Prodigy Plus cube ice machines and

other Scotsman ice machines.

Convenient, built-in scoop holder.

Easily removable bafﬂe, no tools required for cleaning.

Lightweight.

Unique recessed drain ﬁtting for maximum installation ﬂexibility.

Corrosion resistant.

Spring loaded door with hidden hinges for easy opening and closing (except for B230P).

Available in metallic ﬁnish or durable rotocast plastic.

Ice scoop included.

B322S, B330P, B530P/S, B842S, B948S -

Storage Bins

B322S, B330P, B530P/S, B842S, B948S - Storage Bins

Modular Storage Bins

Storage Capacity

Application

Capacity

lb/kg

370/168

B322S

B530S show with optional KLP8S legs.

Application

Capacity

lb/kg

344/156

B330P

Application

Capacity

lb/kg

536/244

B530P/S

Application

Capacity

lb/kg

778/353

B842S

Application

Capacity

lb/kg

893/406

B948S

Warranty

• 3 y rs rts and labor on ea pa all components.

Polyurethane

Insulation

Foam insulation is forced between the wall

and liner under heat and pressure to form a

perfect wall to wall bond, preserving ice

supply for long periods.

Bin Interior

The polyethylene bin interior is sanitary and

easy to clean. Resists scratches and scuffs

from ice scoops.

• Warranty valid in North, South & Central

America for commercial installations.

• Con ct factory for warranty er reg ns.ta in oth io

• Residential Applications: 1 year parts and labor

Application capacity is based on 90% of total volume in cubic feet x 34 lb/ft 3

Certification

D E S I G N E D

ENGINEERED

ASSEMBLED

USA

IN T HE

900 1:2 015

B322S, B330P, B530P/S, B842S, B948S -

Storage Bins

1-800-SCOTSMAN Fax: 847-913-9844 customer.relations@scotsman-ice.comwww.scotsman-ice.com

101 Corporate Woods Parkway, Vernon Hills, IL 60061

B322S, B330P, B530P/S, B842S, B948S - Storage Bins

Modular Storage Bins

In la Not A ow 6” ace at ba for u lity c ec s.stal tion e: ll sp ck ti onn tion

BIN DRAIN

Overall Dimensions

Model # Carton (W x D x H)*

Shipping Information

Model # Carton (W x D x H) Weight (lb/kg)

B322S

B330P

B530P

B530S

B842S

26” x 36” x 49”

33” x 36” x 35”

33” x 37” x 49”

45” x 36” x 49”

140/64

90/41

110/50

150/68

190/86

B948S 209/9551” x 36” x 49”

Dimensions

Model # A B C ED F G H J K L M N P R S

B322S 28.23 34 45.5 1861.24 3.88 25 32.75 44 6 22 15.5 3.25 22.5 11 6 .75 NPT

B330P 28.15 34 45.5 1847.24 3.33 25 32.42 31 6 30 23.5 3.08 30.5 15 6 .75 NPT

B530P/S 28.15 34 45.5 1861.24 3.09 25 31.93 44 6 30 23.5 2.83 30.5 15 6 .75 NPT

B842S 28.07 34 45.5 1861.87 3.88 25 32.75 44 6 42 35.5 3.25 42.5 21 6 .75 NPT

B948S 28.05 34 45.5 1861.24 3.88 25 32.75 44 6 48 41.5 3.25 48.5 24 6 .75 NPT

Accessories*

Kit, bit casters for B530S, B842S, B948S and SB380.** Not

for use with B322S or SB480 when using extensions.

Kit, bin casters for B330P and B530P.**

Kit, legs, 6”, ﬂanged feet, for B bins, HD dispensers, AFE,

CU1/2/3 and NSE.

Kit, legs, 6”, stainless steel, for B bins, HD dispensers,

AFE, CU1/2/3 and NSE.

KBC1

KBC1P

KLP7

KLP8S

Bagger, hooks on any bin.

Kit, bags, 1000, for BGS10.

Kit, tape sealer, for BGS10.

Kit, tape, 180 ft. roll, for BGS10.

BGS10

KBAG

KSEALER

KTAPE

Kit, scoop holder, stainless steel.KHOLDER

Model De Number scription

B322S

B330P

B530P

B530S

B842S

22” x 34” x 44”

30” x 34” x 31”

30” x 34” x 44”

42” x 34” x 44”

B948S 48” x 34” x 44”

**3.5” Diameter, 2 locking, raises bin 4.5”.

* Add 6” Height for bin legs.
