1-800-SCOTSMAN Fax: 847-913-9844 customer.relations@scotsman-ice.comwww.scotsman-ice.com
101 Corporate Woods Parkway, Vernon Hills, IL 60061
Features
New sleek, contemporary styling. A perfect match to Prodigy Plus cube ice machines and
other Scotsman ice machines.
Convenient, built-in scoop holder.
Easily removable baffle, no tools required for cleaning.
Lightweight.
Unique recessed drain fitting for maximum installation flexibility.
Corrosion resistant.
Spring loaded door with hidden hinges for easy opening and closing (except for B230P).
Available in metallic finish or durable rotocast plastic.
Ice scoop included.
B322S, B330P, B530P/S, B842S, B948S -
Storage Bins
B322S, B330P, B530P/S, B842S, B948S - Storage Bins
Modular Storage Bins
Storage Capacity
AHRI
Capacity
lb/kg
290/132
B322S
B530S show with optional KLP8S legs.
AHRI
Capacity
lb/kg
270/123
B330P
AHRI
Capacity
lb/kg
420/191
B530P/S
AHRI
Capacity
lb/kg
610/277
B842S
AHRI
Capacity
lb/kg
700/319
B948S
Certification
Warranty
• 3 y rs rts and labor on ea pa all components.
Polyurethane
Insulation
Foam insulation is forced between the wall
and liner under heat and pressure to form a
perfect wall to wall bond, preserving ice
supply for long periods.
Bin Interior
The polyethylene bin interior is sanitary and
easy to clean. Resists scratches and scuffs
from ice scoops.
®
• Warranty valid in North, South & Central
America for commercial installations.
• Con ct factory for warranty er reg ns.ta in oth io
AHRI capacity is based on 80% of total volume in cubic feet x 30 lb/ft
3
D E S I G N E D
ENGINEERED
ASSEMBLED
USA
IN T HE
B322S, B330P, B530P/S, B842S, B948S -
Storage Bins
1-800-SCOTSMAN Fax: 847-913-9844 customer.relations@scotsman-ice.comwww.scotsman-ice.com
101 Corporate Woods Parkway, Vernon Hills, IL 60061
SIS-SS-BIN-NG 01-17© 2017 Scotsman Ice Systems.
B322S, B330P, B530P/S, B842S, B948S - Storage Bins
Modular Storage Bins
In la Not A ow 6” ace at ba for u lity c ec s.stal tion e: ll sp ck ti onn tion
D
C
B
J
K
A
FG
H
E
P
L
M
N
S
R
BIN DRAIN
T
Overall Dimensions
Model # Carton (W x D x H)*
Shipping Information
Model # Carton (W x D x H) Weight (lb/kg)
B322S
B330P
B530P
B530S
B842S
24” x 36” x 47”
32” x 36” x 33”
32” x 36” x 47”
32” x 36” x 47”
44” x 36” x 47”
104/47
90/41
110/50
132/60
174/79
B948S 196/8950” x 36” x 47”
Dimensions
Model # A B C ED F G H J K L M N P R S
B322S 28.23 34 45.5 1861.24 3.88 25 32.75 44 6 22 15.5 3.25 22.5 11 6 .75 NPT
B330P 28.15 34 45.5 1847.24 3.33 25 32.42 31 6 30 23.5 3.08 30.5 15 6 .75 NPT
B530P/S 28.15 34 45.5 1861.24 3.09 25 31.93 44 6 30 23.5 2.83 30.5 15 6 .75 NPT
B842S 28.07 34 45.5 1861.87 3.88 25 32.75 44 6 42 35.5 3.25 42.5 21 6 .75 NPT
B948S 28.05 34 45.5 1861.24 3.88 25 32.75 44 6 48 41.5 3.25 48.5 24 6 .75 NPT
T
Accessories*
Kit, bit casters for B530S, B842S, B948S and SB380.** Not
for use with B322S or SB480 when using extensions.
Kit, bin casters for B330P and B530P.**
Kit, legs, 6”, flanged feet, for B bins, HD dispensers, AFE,
CU1/2/3 and NSE.
Kit, legs, 6”, stainless steel, for B bins, HD dispensers,
AFE, CU1/2/3 and NSE.
KBC1
KBC1P
KLP7
KLP8S
Bagger, hooks on any bin.
Kit, bags, 1000, for BGS10.
Kit, tape sealer, for BGS10.
Kit, tape, 180 ft. roll, for BGS10.
BGS10
KBAG
KSEALER
KTAPE
Kit, scoop holder, stainless steel.KHOLDER
Model De Number scription
B322S
B330P
B530P
B530S
B842S
22” x 34” x 44”
30” x 34” x 31”
30” x 34” x 44”
30” x 34” x 44”
42” x 34” x 44”
B948S 48” x 34” x 44”
W
D
H
**3.5” Diameter, 2 locking, raises bin 4.5”.
* Add 6” Height for bin legs.
