Sida 1/2

1-800-SCOTSMAN Fax: 847-913-9844 customer.relations@scotsman-ice.comwww.scotsman-ice.com

101 Corporate Woods Parkway, Vernon Hills, IL 60061

Features and Benefits

Spring loaded door hinge keeps door open when accessing ice.

Seamless poly liner inside the bin for better sanitation. Resists scratches and

scuffs.

All models available with all stainless steel construction or stainless steel with

galvanized back and bottom.

Features a roto-molded pouch door that is dent and scratch resistant and doesn’t

sweat.

The pouch style door can be installed without tools in less than ﬁve minutes. It is

shipped inside the bin to provide a narrower bin for delivery through doorways.

Adjustable bin top ﬁller panels included for use with most Scotsman ice

machines.

BH1100, BH1300, BH1600 - Storage Bins

Large Modular Storage Bins

Storage Capacity

Application

Capacity

lb/kg

1100/499

BH1100BB/SS

Application

Capacity

lb/kg

1400/635

BH1300BB/SS

Application

Capacity

lb/kg

1755/796

BH1600BB/SS

Certification

Dimensions (W x D x H)*

Warranty

Polyurethane

Insulation

First Ice In

First Ice Out

The ﬁrst ice that drops in the bin is the ﬁrst

ice that comes out and is used, ensuring

fresh tasting all the time.

* Add 6” Height for bin legs.

48” x 34” x 50”

(121.9 x 86.4 x 127.0 cm)

60” x 34” x 50”

(152.4 x 86.4 x 127.0 cm)

60” x 34” x 62”

(152.4 x 86.4 x 157.5 cm)

BH1100BB/SS BH1300BB/SS BH1600BB/SS

BB - All stainless steel except galvanized back and bottom.

SS - All stainless steel with polyethylene liner.

Application capacity is based on 90% of total volume in cubic feet x 34 lb/ft 3

• 5 y rs rts and labor on ea pa all components.

Foam insulation is forced between the wall

and liner under heat and pressure to form a

perfect wall to wall bond, preserving ice

supply for long periods.

• Warranty valid in North, South & Central America

for commercial installations.

• Con ct factory for warranty er reg ns.ta in oth io

D E S I G N E D

ENGINEERED

ASSEMBLED

USA

IN THE

• Residential Applications: 1 year parts and labor

900 1:20 15

BH1100, BH1300, BH1600 - Storage Bins

Large Modular Storage Bins

Shipping Information Field Installed Stainless Steel Bin Tops

Model # Carton (W x D x H) Weight (lb/kg)

BH1100BB-A

BH1100SS-A

BH1300BB-A

BH1300SS-A

BH1600BB-A

BH1600SS-A

54” x 39” x 56”

65” x 41” x 56”

65” x 41” x 67”

280/127

310/141

370/168

EH222

(2) 22” units side-by-side

(2) 30” Cubers

side-by-side

Model BH1100BB/SS BH1300BB/SS Number

KBT52

KBT53

KBT54

KBT52

KBT53

KBT54

KBT50

KBT51

BH1600BB/SS

1100 UPRIGHT

In la Not A ow 6” ace at ba for u lity c ec s.stal tion e: ll sp ck ti onn tion

Dra : 1” FPT dr n fi gin ai ttin

1300/1600 UPRIGHT

customer.relations@scotsman-ice.com

www.scotsman-ice.com

1-800-SCOTSMAN Fax: 847-913-9844

101 Corporate Woods Parkway, Vernon Hills, IL 60061

Th r xc cee Spi it of E ellen

an Ali Group Company
