Scotsman SB550 Bruksanvisning

Scotsman Ismaskin SB550

Läs nedan 📖 manual på svenska för Scotsman SB550 (2 sidor) i kategorin Ismaskin. Denna guide var användbar för 9 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/2

Years Warranty

Subject to certain limitations and exclusions

This product qualifies for the following listings:

Models and specifications are subject to change without notice.

6/2016

Certied ISO 9001

Slope Bin 252 kg

SB 550

[WxDxH mm]

1082x824x968

[kg]

252

[lbs]

554,4

[kg]

197

[lbs]

433,4

0,513

[WxDxH inches]

42 x 32 x 38 5/8” 7/16” 1/8”

W D

Other models in this range:

SB193 - SB322 - SB393 - SB530 - B842

SB948 - SB1025

Ice Capacity

(Application)

Ice Capacity

(AHRI)

Internal

Volume

SB550

Features

• Slope front ice storage bin, for Gourmet & Dice Cubes,

Flake, Superflake, Nugget, Cubelet ice.

• New sleek, contemporary styling. A perfect match to MC,

MF, MV, PMV and Prodigy Scotsman modular cube ice

machines in 108,2 cm / 43” width.

• Convenient & hygienic internal ice scoop holder.

• Exterior panels in durable stainless steel.

• Polyurethane Insulation,

• High density, non-corroding Polyethylene bin liner, is

designed with easy-to-clean rounded corners, and resists

scratches and scuffs from ice scoops.

• Robust door frame will resist operational abuse.

• Rounded door-lip profile allows an easy reach for

enhanced ease of operation.

• Fully removable door gasket seals door opening to reduce

ice melt, easily disassembled for manual cleaning.

• Internal ice deflector enhances ice distribution to maximize

bin storage capacity.

• Load resistant, stainless steel adjustable legs.

• Bin Caster available on request for selected models.

• Storage bin base drain tube conveniently rotates at 360°

radius to allow ease-of-connection with any floor water

drain position

(Application) capacity is calculated on 90% of total volume in the

cubic feet x 34 lb/ft3 - 545 kg/m

(AHRI) capacity is calculated on 80% of total volume in the cubic feet

x 30 lb/ft3 - 481 kg/m3.

www.scotsman-ice.it

www.scotsman-ice.com

MC46 - 310 Kg

MV / P-MV456 - 240 Kg

MV460 - 200 Kg

MV / P-MV606 - 320 Kg

MV / P-MV806 - 430 Kg

MV / P-MV1006 - 465 Kg

Bin Top

CBT42EMCD

(sold separately)

MC16 Short - 160 Kg

Bin Top

CBT16

(sold separately)

MFN46 - 270 Kg

MFN56 - 470 Kg

N622 - 292 Kg

MF26 - 120 Kg

MF36 - 200 Kg

F1222 - 445 Kg

Bin Top

CBT42EFSD

(sold separately)

Bin Top

CBT42EFSD

(sold separately)

MF46 / MF47 - 330 Kg

MF56 / MF57 - 600 Kg

MF58 Split - 600 Kg

MF59 Split - 850 Kg

Bin Top

CBT42EFSD

(sold separately)

SB 550

[kg]

n.a.

[lbs]

n.a.

[kg]

n.a.

[lbs]

n.a.

SB 550

Storage capacity 252 Kg

Other models in this range:

SB193 - SB322 - SB393 - SB530 - B842

SB948 - SB1025

IMPORTANT NOTICE:

Models and specifications are subject to change without notice.

This spec sheet is meant for commercial purpose only.

For technical documentation please refer to our service manuals.

www.scotsman-ice.it

www.scotsman-ice.com

Milano Madrid Chicago Dubai Singapore Shanghai Johannesburg

6/2016

Produktspecifikationer

Varumärke:	Scotsman
Kategori:	Ismaskin
Modell:	SB550
Färg på produkten:	Zwart, zilver
Vikt:	2970 g
Bredd:	160 mm
Djup:	95 mm
Höjd:	395 mm
Snäll:	Blender voor op aanrecht
Antal hastigheter:	2
Kraftkälla:	AC
Avtagbar bricka:	Ja
Tillgångar:	600 W
Innehåll behållare/burk:	1.5 l
Iskross:	Ja
Antihalkfötter:	Ja
Pulsfunktion:	Ja
Knivmaterial:	Roestvrijstaal
Fin skärare:	Ja
Smoothiebägare:	Ja
