Introduction:
This ice machine is the result of Scotsman’s
decades of experience as an industry leader in the
design and manufacture of both commercial and
residential ice machines.
This manual includes the information needed to
install, start up and maintain the ice machine. Note
any Caution or Warning indicators, as they provide
notice of potential hazards. Keep this manual for
future reference.
September 2009
Page 1
SCCG30 & SCCP30
Service Manual
Table of Contents
Specifications Page 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cabinet Layout Page 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air flow Page 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Water Quality Page 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Covering Page 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Panel Attachment Page 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Custom Panel Page 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door swing change Page 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation: Water & Drain Page 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gravity Drain Page 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Page 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cube Size Adjustment Page 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Harvest Time Adjustment Page 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Settings Page 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Use ............................................... Page16
How to clean the condenser and winterize. Page 17. . . . . . . . . . . . . . . . . . . . . . . . . . .
How to remove scale from the ice making system. Page 18. . . . . . . . . . . . . . . . . . . . . . .
System Information Page 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Water System Page 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Components Page 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Controller Page 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Performance Information Page 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Refrigeration System Page 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermistor Values Page 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Diagnosis Page 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Diagnosis Page 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal and Repair Page 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal and Repair Page 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal and Repair - Cabinet Removal Page 30. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Refrigeration Service Page 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications
This ice machine is designed to be used indoors, in
a controlled environment. It can be used in a wide
variety of environmental conditions, but there are
limits. Use outside of the listed limitations is misuse
and will void the warranty.
Air temperature limits:
The ice machine will operate adequately within the
limits, but functions best in temperatures between
70 and 80 degrees F.
•Minimum – 50 degrees F. (10oC)
•Maximum – 100 degrees F. (38oC)
Water temperature limits:
•Minimum – 40 degrees F. (4.5o
C)
•Maximum – 100 degrees F. (38oC)
Water pressure limits:
•Minimum – 20 psi (1.4 bar)
•Maximum – 80 psi (5.5 bar)
Because the ice machine is making a food product,
the water supply to the ice machine must be
potable, or fit for human consumption.
Electrical
•115 volt, 60 Hz. Plug into dedicated 15 amp
circuit.
•Power consumption: 400-180 Watts. Varies
during Freeze and Harvest cycles.
Voltage limits:
•Minimum - 104 volts
•Maximum – 126 volts
Options:
Door Panel kits:
Finished door panels are available from Scotsman
for attachment to the machine, or a custom panel
can be made.
Kit Number Panel Finish Handle Finish
KDFS Stainless Steel Stainless Steel
Drain Conversion:
A gravity drain model can be converted to a drain
pump model by installing a drain pump kit. The
drain pump kit consists of a drain pump, wiring
harness and associated tubing. The kit number is
A39462-021.
Warranty Information
Warranty information is supplied separately from
this manual. Refer to it for coverage. In general, the
warranty covers defects in materials or
workmanship and does not cover corrections of
installation errors or maintenance.
September 2009
Page 2
SCCG30 & SCCP30
Service Manual
Models: There are six models, all air cooled:
•SCCPA30M-1SU – Pump model, stainless cabinet
•SCCGA30M-1SU – Gravity drain model, stainless cabinet
Cabinet Layout
September 2009
Page 3
SCCG30 & SCCP30
Service Manual
14 7/8"
AIR IN
AIR OUT
.75
SHEET METAL DOOR FRONT
.63 MIN. CABINET DOOR
29 1/4"
1"
LEG ADJUSTMENT
(4) PLACES
33 3/8" MIN.
34 3/8" MAX.
22"
2 3/4"
4"
3 3/4"
1 1/2"
2 1/2" 3 1/4"
7 3/8"
115 V
POWER CORD
DRAIN
FLEXIBLE TUBING
3/8 I.D. PUMP MODEL (INCLUDED)
5/8 I.D. GRAVITY MODEL (NOT INCLUDED)
POTABLE WATER INLET
1/4" COMPRESSION FITTING
3 7/8"
20 3/8"
FLOOR DRAIN
ACCESS HOLE
