CLEANING
To clean, wipe xture with a soft and dry cloth. Do not use
abrasive materials such as scouring pads or powders, steel
wool or abrasive paper.
ORDERING PARTS
Keep this sheet for future reference, and in case you need
to order replacement parts. All parts for this xture can be
ordered from place of purchase. Be sure to use exact
wording from illustration when ordering parts.
LINE ART SHOWN MAY NOT EXACTLY MATCH THE
FIXTURE ENCLOSED. HOWEVER, THE INSTALLATIONS
DO APPLY TO THIS FIXTURE.
A
B
C
D
E
F
G
H
I
J
SLLMP14 USER MANUAL
FOR YOUR SAFETY
WARNING: BE SURE THE ELECTRICITY TO THE WIRES
YOU ARE WORKING ON IS SHUT OFF; EITHER THE FUSE
IS REMOVED OR THE CIRCUIT BREAKER IS SHUT OFF.
GENERAL
You don’t need special tools to install this xture. Be sure
to follow the steps in the order given. Under no circum-
stances should a xture be hung on house electrical
wires, nor should a swag type xture be installed on a
ceiling, which contains a radiant type heating system.
Read instructions carefully. If you are unclear as to how
to proceed, consult a qualied electrician.
NOTE: Proper wiring is essential for the safe operation of
this xture.
FIXTURE ASSEMBLY
Carefully removed the xture from the carton and check
all parts are included as shown in gure. Be careful not
to misplace any of the screws or parts, which are needed
to install this xture.
INSTALLATION
IMPORTANT: Do not attach xture directly to outlet box.
STEP 1: Remove the mounting bar (C) from the canopy (F).
GROUNDING INSTRUCTIONS
STEP 1: Mount ground wire on mounting bar (C) onto
ground screw in the outlet box (A). Firmly connect the
mains supply wires to the light tting using the connec-
tors provided (B). Ensure that wires are secure and that
no bare wire is exposed.
NEVER CONNECT GROUND WIRE TO BLACK OR WHITE
POWER SUPPLY WIRES.
STEP 2: Take note of the color of the wire(s) on your
xture. Identify which group your xture wire(s) falls into
and connect the wires according to the directions below:
NOTE: When parallel wire (SPT-I & SPT-2) is used, the
tracer wire is square shaped or ridged and the less tracer
wire is round in shape or smooth (seen best when
viewed from wire end.)
STEP 3: Install the mounting bar (C) to the outlet box (A)
using the screws (D).
STEP 4: Install the canopy (F) to the mounting bar (C),
tighten it using the securing screws (E).
FINAL ASSEMBLY
STEP 1: Install the glass shade (H) onto the lamp holder
(G). use lamp holder ring (I) locked.
STEP 2: Install the E26 bulb (J) into lamp holder (G).
GROUP A: Connect to Black
House Wire
BLACK
*PARALLEL WIRE
(round & smooth)
WHITE OR GREY WITH TRACER
BROWN, GOLD, OR BLACK
WITHOUT TRACER
GROUP B: Connect to White
House Wire
WHITE
*PARALLEL WIRE
(square & ridged)
WHITE OR GREY
WITHOUT TRACER
BROWN, GOLD, OR BLACK
WITHOUT TRACER
