1. Changing the bulb ( g.4 )

A. Turn o the power and unscrew the head from the handle

of device;

B. Pull the old bulb downwards, and replace with new one;

C. Screw the head back on to the handle.

Attention:

• Please use the specialized bulb (Model: 8107) for this

device.

• After the bulb burns out, the temperature will remain high

for approximately 5 minutes. Please wait for a moment to

avoid injury.

2. Changing the batteries ( g.5 )

A. Unscrew the bottom cover from the handle

B. Remove the old AA batteries, and replace with new ones.

Ensure the anode of the batteries points to the head of the

device

C. Screw on the bottom cover of the handle.

Attention:

• AA alkaline batteries are recommended.

• Replace all batteries simultaneously and do not use alkali

manganese batteries with lithium as bulb life will be

reduced.

• Do not leave worn batteries in the handle.

• Please take out batteries from the device if not in use for a

prolonged period.

• Batteries should be disposed of in accordance with local

regulations.

Cleaning and Disinfection:

A. Clean the surface of device with 75% alcohol solution at

least once a week, avoiding the magnifying glass (viewing

window) in the head. And corrosive or polishing detergent

is prohibited.

B. Disinfect the tips of otoscope with saturated steam for 20

minutes at 273.2°F

Attention:

Do not soak, autoclave or let water dip into the device

SLOTOSPE014

OTOSCOPE

User Manual

OTOSCOPE

USER MANUAL

Otoscope instructions for ophthalmologist. It is an internally

powered device. Please read through this brochure before

use, and keep it handy for future reference.

Manufacturer

Authorized Representative in the

European Community

Symbol for the marking of electrical and

electronics devices according to Directive

2002/96/EC. The device, accessories and the

packaging have to be disposed of waste

correctly at the end of the usage. Please

follow Local Ordinances or Regulations for

disposal.

Type B Applied Part

Attention, consult accompanying doctuments

SAFETY INFORMATION

To assure the correct use of the product, basic safety

measures should always be followed including the

warnings and cautions listed in this instruction manual.

WARNINGS & CAUTIONS:

• Do not use the device where it may be exposed to

ammable gas.

• Protect this device from water, moisture, Impact,

dropping, direct sunlight, heat and re.

• Do not touch the lens directly by hand or something hard.

• Please use the bulb type specied in this instruction

brochure.

• Keep the device out of the reach of unsupervised infants

and children.

• Do not disassemble or attempt to repair the device or

components.

GENERAL

DESCRIPTION:

The otoscope is a classic medical device in ENT. The devices

adopt the total reection of optical ber, and make the

light path and observation of light tend to be coaxial

through the optimization design, which increase the visual

eld of view. It is used to view the tympanic membrane and

external ear canal to diagnose outer and middle ear

pathologies.

TECHNICAL SPECIFICATIONS:

• Enhanced XHL Xenon Halogen Technology.

• 3x magnication for the viewing window.

• 8107 bulb used.

• Fiber optic illumination.

• An insuﬄation bulb for pneumatic testing.

HOW TO USE THIS DEVICE

• Turn on (or oﬀ) the device by pushing downwards

(or upwards) as g.1;

• Select a reasonable tip for patient's ear canal and push it

onto the head and screw the tip clockwise, refer to g.2.

Generally, the tip size of 4mm is for adults and 2.4mm is for

children;

• Put the otoscope with a tip into the ear canal of patient

(g.3) , and exarnine through the viewing window which is

with 3x magnication;

ATTENTION:

The otoscope should only be used to examine ear when a tip

is tted. It is an intermittent operated device, 1 minute ON, 5

minutes OFF.

SYMBOLS:

MAINTENANCE

CHANGING SPARE PARTS:

PERIODIC SAFETY CHECKS

Preventive inspection and maintenance to be performed

including the frequency of such maintenance. The following

safety check should be performed at least every 12 months

by a qualied person who has adequate training, knowledge,

and practical experience to perform these tests.

SPECIFICATION

ELECTRICAL CLASSIFICATION

• Inspect the equipment and accessories for rnechanical and

functional damage.

• Inspect the safety relevant labels for legibility.

• Verify that the device functions properly as described in the

instructions for use.

Equipment Classication with respect to protection from

electric shock: Internally powered equipment.

Degree of protection from electric shock: TYPE B.

Equipment not suitable for use in the presence of ammable

mixture: Yes.

Mode of operation: intermittent operation.

The manufacturer reserves the right to make technical

changes without notice in the interest of progress. Prior

notices will not be given in case of any amendments within

this manual.

Illumination

Luminance

Magnication

Tip Sizes

Bulb

Batteries

Operation

Storage &

Transport

Standards

Fiber Optic Illumination / Direct Illumination

18. 5 Lumen

3 x

2.4mm, 3mm, 4mm, 5mm

Specied Model: 8107 2.5V, 0.7A, Φ = 4.8mm

2 AA alkaline batteries

Temperature 50°F~ 95°F

Humidity 30% ~ 75%

Air pressure 700 hPa - 1060 hPa

Temperature -68°F ~ 158°F

Humidity 10% ~ 90%

(without condensation)

Air pressure 500 hPa - 1060 hPa

MDD 93/42/EEC Class I

IEC 60601-1:1995, IEC 60601-1-2:2007
