Sida 1/5
Item Model: ZO1000
Manual
Transmitter*1 User Manual*1
5
Receiver*1
2
Antenna*5
3
Type-c power cable*1
4
Wireless Video Transmission System
ZOlink series
Shenzhen ZO Video Technology Co., Ltd.
02/Packing List
Transmit Range
Ultra-Low-Power Multiple Power Supply
Ultra Low Latency
Multiple Monitoring
01/Features
UVC Live Streaming
1
Left Button
3OLED Screen
2USB Type-c Port ( Power &
UVC Live streaming（RX) )
4
Power switch 5
Right Button
7HDMI Input( TX)/ Output(RX)
8SDI Input( TX)/ Output(RX)
6
Menu Button
X to 1 RX Mode
X to 2 RX Mode
or
or
03/Product Interfaces
2
1
8
7
654
3
04/Typical Setup
RX1
TX
RX
RX2
TX
1
3
2
4
5
6
1
3
2
4
5
6
1 TX to 1 RX Mode
1 TX to 2 RX Mode
Device Connection Number
Signal Strength
Video Format
Brand
Power Supply Method
Frequency Channel
Device Connection Number
Signal Strength
Video Format
Brand
Power Supply Method
Frequency Channel
After the transmitter is paired with one single receiver, an additional mobile
device can be connected;
1 TX to 1 RX Mode
The transmitter can be paired with two receivers. After the pairing is completed,
an additional mobile device can be connected. NOTE: Only after one receiver is
successfully paired with the transmitter, the other receiver can be paired;
TX TX
TX RX1
RX1
RX2
RX
ZO1000 can be paired with all "Shimbol" brand transmission systems and
monitors;
1 TX to 2 RX Mode
Full Compatible with Shimbol Brand
06/Product Status
1 2
1080P60
1080P60
1080P60
SHIMBOL USB
CH 00
05/OLED Display
1 2
1080P60
SHIMBOL USB
CH 00
2
1080P60
SHIMBOL USB
CH 00
3
1 11
2
4
5
63
12
4
5
6
2
SHIMBOL USB
CH 00
1
SHIMBOL USB
CH 00
1
SHIMBOL USB
CH 00
1 2
1080P60 1080P60
SHIMBOL USB
CH 00
1. When the receiver is not connected, the frequency channel will not be displayed;
2. After the receiver is booted, the frequency channel will not be displayed until the
transmitter is connected;
Notice
4. In one TX to two RX paring mode, it is recommended to select two different
receiver numbers to prevent IP conflicts. If both receivers select the same number
(RX1 or RX2 at the same time), you need to manually change the number on the
receiver to display the corresponding RX1 and RX2.(The number refers to the device
connection number);
3. If it is used in connection with Shimbol brand series video transmission system
that does not support the one TX to two RX mode, it is recommended to use the
ZO1000 Receiver “Device connection number” adjusted to ZO500/ZO600S.
The adjusting method is as follows:
Long press the receiver "Menu Button"3s to enter System Setting-Number-
ZO500/ZO600 to adjust. Otherwise, there will be a problem of sound but no picture;
