Conferencing and Discussion Systems
AO 6004 Audio Output
USER GUIDE
DCS 6000 Digital Conference System User Manual
@2015 Shure Incorporated User Manual AO 6004 rev C.docx
Table of Contents
Table of Contents .................................... 2
Important ................................................ 3
Installation precautions ....................... 3
Cleaning ............................................... 3
Repacking ............................................. 3
Warranty .............................................. 4
Your DCS 6000 Conference System ......... 5
The DCS 6000 system ........................... 5
System components ............................. 6
Central equipment etc. ........................... 6
Interpreter equipment ............................ 6
Conference units and Ch. selectors .......... 6
Accessories ........................................... 6
Operating instructions ............................. 7
AO 6004 Audio Output Unit................... 7
General description ............................... 7
Features .............................................. 7
User controls, indications & connections ... 8
System settings .................................... 8
Normal operation .................................. 8
System Setup .......................................... 9
General guidelines ................................ 9
Typical schematics ................................. 10
Using AO 6004 with DT 60xx Digital IR-
Transmitter ......................................... 10
Technical Specifications ......................... 11
System Specification ........................... 11
Connection Details .............................. 12
Accessories ......................................... 12
DIS Digital Conference System User Manual
3
Important
Installation precautions
Do not install the unit in a location near heat
sources such as radiators or air ducts, or in a place
exposed to direct sunlight, excessive dust or
humidity, mechanical vibration or shock.
To avoid moisture condensations do not install the
unit where the temperature may rise rapidly.
Compliance
The equipment is intended to be used in
professional audio applications.
Note: This device is not intended to be connected
directly to a public internet network.
EMC conformance to Environment E2:
Commercial and Light Industrial.
Testing is based on the use of supplied and
recommended cable types.
The use of other than shielded (screened) cable
types may degrade EMC performance.
Changes or modifications not expressly approved
by Shure Incorporated could void your authority
to operate this equipment.
This Class B digital apparatus complies with
Canadian ICES-003. Cet appareil numérique de la
classe B est conforme à la norme NMB-003 du
Canada.
Authorized under the verification provision of FCC
Part 15B.
Please follow your regional recycling scheme for
batteries, packaging, and electronic waste.
Information to the user
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the receiver.
• Connect the equipment to an outlet on a
circuit different from that to which the
• receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Cleaning
To keep the cabinet in its original condition,
periodically clean it with a soft cloth. Stubborn
stains may be removed with a cloth lightly
dampened with a mild detergent solution. Never
use organic solvents such as thinners or abrasive
cleaners since these will damage the cabinet.
Repacking
Save the original shipping cardboard box and
packing material; they will become handy if you
ever have to ship the unit. For maximum protection,
re-pack the unit as originally packed from the
factory.
