Sida 1/2
©20 Shure Incorporated13
27A20378 (Rev. )3
Model Variations
CVO-B/C: Cardioid, black
CVO-W/C: Cardioid, white
Centraverse Overhead Microphone
The Centraverse CVO is a professional low pro-
file electret condenser microphone designed for
overhead sound reinforcement applications. An in-
tegrated wire aiming hanger is included for optimal
placement above choirs and other ensembles with
minimal effort.
Note: Model availability depends on region.
See your local Shure dealer or distributor for
details.
45
Features
• Cardioid pickup pattern
• Commshield® technology guards against
unwanted RF interference from portable
wireless devices (smartphones, etc.)
• Superior Shure design and rugged, dependable
construction
• Attached 25 ft XLR cable
• Included snap-fit windscreen
Installation
1. Attach the wire hanger:
• Snap the wire into the groove on the microphone body.
• Guide the cable through the spiral at the end of the wire,
beginning at the bottom and working toward the exit.
2. Hang the microphone according to the guidelines for placement.
3. Aim the microphone toward the sound source by holding the wire
hanger in place and twisting the microphone body.
4. If necessary, tie a strong transparent thread or fishing line to the loop at
the end of the wire hanger and attach it to a ceiling anchor for additional
stability.
5. Connect the XLR cable to a mixer or P.A. system.
Note: This microphone requires +48V phantom power to operate.
.6 – 1 m
(2 – 3 ft.)
.6 – 1 m
(2 – 3 ft.)
1.8 – 3m
(6 – 9 ft.)
0.6 – 1m
(2-3 ft.)
Microphone Placement and Use
1. If using multiple Shure Centraverse overhead micro-3:1 Rule:
phones, the distance between the microphones should be three
times greater than the distance between the microphone and the
sound source.
2. Place the microphone in front of the choir, above Choir Installations:
their heads and aimed at the back row.
3. Use the supplied snap-fit windscreen to eliminate wind Windscreen:
noise and plosives. To install the windsreen, snap it into the first groove
on the microphone head. To remove the windscreen, locate the gap
in the ring and use your fingernail to pull the windscreen off from the
right-hand side.
Centraverse™ Series
Installed Sound Microphones
CVO
Cartridge Type
Electret Condenser
Polar Pattern
Cardioid
Frequency Response
70–16000 Hz
Output Impedance
180Ω
Sensitivity
open circuit voltage, @ 1
kHz, typical
–33 dBV/Pa[1] (22 mV)
Maximum SPL[2]
1 kHz at 1% THD
120 dB SPL
Signal-to-Noise Ratio[3]
Ref. 94 dB SPL at 1 kHz
67 dB
Dynamic Range
93 dB
Self Noise
equivalent SPL, A-weighted,
typical
27 dB SPL
Preamplifier Output
Clipping Level
@ 1 kHz, at 1% THD
-7 dBV
Common Mode Rejection
10 Hz to 100 kHz
>45 dB
Polarity
Positive pressure on diaphragm
produces positive voltage on pin 2
with respect to pin 3
Environmental Conditions
Operating
Temperature
–18 to 57°C (0
to 135°F)
Storage
Temperature
–29 to 74°C
(–20 to 165°F)
Relative
Humidity
0 to 95%
Power Requirements
11–52 V DC[4], 2.0 mA
Weight
4.7 oz. (133 g)
[1] 1 Pa=94 dB SPL
[2] THD of microphone preamplifier
when applied input signal level is
equivalent to cartridge output at
specified SPL
[3] S/N ratio is the difference be-
tween 94 dB SPL and equivalent
SPL of self noise, A-weighted
[4] All specifications measured
with a 48 Vdc phantom power sup-
ply. The microphone operates at
lower voltages, but with slightly de-
creased headroom and sensitivity.
Specifications
SHURE Incorporated http://www.shure.com
United States, Canada, Latin America, Caribbean:
5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A.
Phone: 847-600-2000 U.S. Fax: 847-600-1212 Int’l Fax: 847-600-6446
Europe, Middle East, Africa:
Shure Europe GmbH, Phone: 49-7262-92490 Fax: 49-7262-9249114
Asia, Pacific:
Shure Asia Limited, Phone: 852-2893-4290 Fax: 852-2893-4055
Accessories
Furnished Accessories
Wire aiming hanger (Black) 44A16928
Wire aiming hanger (White) 44B16928
Windscreen (Black) 95A20541
Windscreen (White) 95B20541
Optional Accessories
Windscreen (Black, 4-pack) ACVO4WS-B
Windscreen (White, 4-pack) ACVO4WS-W
20
15
10
5
0
-30
-25
-20
-15
-10
-5
dB
Hz
20 100 1k 10k 20k
2 ft. (0.6 m) from sound source
500 Hz
250 Hz
1,000 Hz
4,000 Hz
2,000 Hz
Certifications
Meets essential requirements of all applicable European Directives.
Eligible for CE marking.
The CE Declaration of Conformity can be obtained from Shure Incorporated or any of its European
representatives. For contact information please visit www.shure.com
The CE Declaration of Conformity can be obtained from: www.shure.com/europe/compliance
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Jakob-Dieffenbacher-Str. 12
75031 Eppingen, Germany
Phone: 49-7262-92 49 0
Fax: 49-7262-92 49 11 4
Email: EMEAsupport@shure.de
4.8”
(123 mm)
2.9”
(55 mm)
25’
(7.6 m)
0.6”
(15 mm)
0.9”
(24 mm)
