www.shure.com
© 2011 Shure Incorporated
27A15531 (Rev. 1) Printed in U.S.A.
N108
Wired Microphones
VP82
Microphone canon compact
Kompaktes Richtrohrmikrofon
Micrófono de cañón compacto
Microfono a canna di fucile compatto
Компактный линейный микрофон
コンパクトショットガンマイクロホン
컴팩트 샷건 마이크
紧凑型枪式话筒
Compact Shotgun Microphone
VP82
3
Cartridge Type Electret Condenser
Polar Pattern Supercardioid/lobar
Frequency Response 150 to 20,000 Hz
Output Impedance 144 Ω
Sensitivity
open circuit voltage, @ 1 kHz,
typical
-36.0 dBV/Pa[1] (2.11 mV)
Maximum SPL
1 kHz at 1% THD[2]
2500 Ω load: 137.5 dB SPL
1000 Ω load: 131.5 dB SPL
Signal-to-Noise Ratio[3] 79 dB
Dynamic Range
@ 1 kHz
2500 Ω load: 122.5 dB
1000 Ω load: 116.5 dB
Clipping Level
@ 1 kHz, 1% THD
2500 Ω load: 7.0 dBV
1000 Ω load: 0.0 dBV
Self Noise
equivalent SPL, A-weighted,
typical
15.0 dB SPL-A
Common Mode Rejection
20 to 20,000 Hz ≥55 dB
Operating Temperature Range -18°C (0°F) to 57°C (135°F)
Storage Temperature Range -29°C (-20°F) to 74°C (165°F)
Operating Relative Humidity 0 to 95%
Polarity Positive pressure on diaphragm produces positive voltage on
pin 2 with respect to pin 3
Housing Satin-black vinyl painted aluminum alloy with stainless steel
screen
Power Requirements 11–52 V DC[4]
phantom power (IEC-61938), <2.0 mA
Net Weight 76 g (2.7 oz.)
[1] 1 Pa=94 dB SPL
[2]THD of microphone preamplifier when applied input signal level is equivalent to cartridge output
at specified SPL
[3]S/N ratio is the difference between 94 dB SPL and equivalent SPL of self noise, A-weighted
[4]All specifications measured with a 48 Vdc phantom power supply. The microphone operates at
lower voltages, but with slightly decreased headroom and sensitivity.
General Description
The VP82 is a professional shotgun microphone for use in sound capture and
reinforcement. Compact and lightweight, with wide aperture and excellent
off-axis rejection, the VP82 is the affordable and reliable choice for camera-
mounted A/V media production applications.
Features
• Premier production microphone crafted with Shure quality, ruggedness,
and reliability
• Highly directional, uniform polar pattern optimized for distant pickup
• Low self-noise and high output level
• Lightweight, compact design accommodates prolonged operation,
minimizing operator fatigue attributed to many shotgun microphones
• Class A, discrete, transformerless preamplifier provides transparent,
extremely fast transient response with no crossover distortion and minimal
harmonic and intermodulation distortion
• Aircraft-grade aluminum alloy construction resists wear and abuse
• Operates over a wide range of temperatures and humidity
Rycote Custom Accessories
Shure offers custom Rycote
® suspension mounting and wind-protection solu-
tions designed for Shure VP shotgun microphones.
Wind-Protection
Use the supplied foam windscreen to reduce wind-noise. For increased pro-
tection, Shure offers two premium Rycote
® windshield accessories:
• Attenuates up to 25 dB of wind-noise.Softie Windshield:
• Attenuates up to 38 dB of wind-noise while Suspension Windshield Kit:
preserving critical high frequencies. Included Lyre suspension mounts
provide up to 25 dB of isolation.
Suspension Mounts
Shure offers three Rycote® Softie Lyre Mounts to reduce handling noise and
low-frequency vibrations by up to 15 dB:
• Secures directly onto standard camera shoe.InVision Video:
• Fits into a standard camera clamp.Camera Clamp Adapter (CCA):
• Adjustable handheld mount.Pistol Grip:
Note: All Softie Lyre Mounts (except InVision Video) are equipped with 3/8”
and 5/8” female threaded adapters for additional mounting options.
Load Impedance
Maximum SPL capability, output clipping level, and dynamic range vary with
the input load impedance of the preamplifier to which the microphone is con-
nected. Shure recommends a minimum input load impedance of 1000 Ohms.
Most modern microphone preamplifiers meet this requirement. Higher imped-
ance results in better performance for these specifications.
Power Requirements
This microphone requires phantom power and performs best with a 48 V DC
supply (IEC-61938), but it can operate with supplies as low as 11 V DC. Most
modern mixers provide phantom power and require the use of a balanced
microphone cable: XLR-to-XLR or XLR-to-TRS.
Specifications
XLR Connector Gasket
This microphone is supplied with a small corrugated rubber ring in the XLR
connector to absorb the mechanical slack between the microphone and
cable. Many high-end cables are made with a rubber shoulder on the XLR-F
for the same purpose. When connecting this microphone to a cable with a
rubber shoulder XLR-F connector, remove the corrugated rubber ring from
the microphone to ensure a proper fit.
XLR-F
rubber shoulder
corrugated
rubber ring
MICROPHONE
12
A89SW-KIT
A89SW 95A2313
Accessoires fournis
Accessoires fournis
Mitgeliefertes Zubehör
Mitgeliefertes Zubehör
Accesorios suministrados
Accesorios suministrados
Accessori in dotazione
Accessori in dotazione
Отдельно заказываемые
аксессуары
Принадлежности,
входящие в комплект
付属アクセサリー
付属アクセサリー
기본 제공 액세서리
기본 제공 액세서리
Foam Windscreen
Bonnette anti-vent en mousse
Schaumstoff-Windschutz
Paravientos de espuma
Antivento in schiuma poliuretanica
Пенопластовый ветрозащитный экран
フォームウィンドスクリーン
폼 윈드스크린
海绵防尘罩
Windshield Kit
Kit de bonnette de protection
Windschutzsatz
Juego de paravientos
Kit antivento
Комплект ветрозащитного подвеса
ウィンドシールドキット
윈드쉴드 키트
防风套件
Furnished Accessories
Optional Accessories 可选配附件
提供的附件
拉链便携包
지퍼가 부착된 휴대용 백
Zippered Carrying Bag
Fourre-tout pour le transport à fermeture éclair
Tragetasche mit Reißverschluss
Bolsa para transporte con cremallera
Custodia con cerniera, adatta per il trasporto
Футляр на застежке-молнии
ジッパー付きキャリングバッグ
1
2
3
