Sida 1/15

EN / FR

Euroset 5010

1 Repertory keys

2 Recall key

3 Last number redial key

(and pause key)

4 Direct call key

5 Shift key

6 Set key

7 Mute key

1 Touches d'accès rapide

2 Touche de double appel

3 Touche bis (et touche de

pause)

4 Touche d'appel direct (ba-

by call)

5 Touche Shift

6 Touche Enregistrer

7 Touche de désactivation

du haut-parleur (Mute)

Connections

Raccordement

Cable duct for

1 table top operation

2 wall mounting

Rainure pour le cordon, utilisa-

tion

1 sur bureau

2 murale

Wall mounting

(see figure)

Once the connecting leads

have been connected, you can

mount the telephone on the

wall:

◆Drill two dowel holes

(5 mm ∅) 110mm apart,

insert dowels and screw in

countersunk head wood

screws with a slight gap to

the wall.

◆On underside of tele-

phone: Lift out handset

bracket with screwdriver.

◆Clip handset bracket into

handset shell mounting.

◆Hang telephone on pro-

jecting screw heads.

Safety precautions

When installing, connecting

and operating the telephone,

always observe the following

precautions:

◆Only use the jacks and

leads supplied.

◆Only connect the connect-

ing lead to the intended

socket.

◆Only connect approved

accessories.

◆Lay the connecting lead

where it will not cause

accidents.

◆Position the telephone on

a non-slip surface.

◆For your safety and protec-

tion, the telephone may

not be used in the bath or

shower rooms (wet loca-

tions). The telephone is

not splash proof.

◆Never expose the tele-

phone to sources of heat,

direct sunlight or other

electrical devices.

◆Protect your telephone

from moisture, dust, cor-

rosive liquids and vapours.

◆Never open up the tele-

phone yourself.

◆Do not touch the plug con-

tact with pointed or metal-

lic objects.

◆Do not carry the telephone

by the leads.

◆If you give your telephone

to someone else, make

sure you also give them

the operating manual.

Setting up the

telephone for use

Recommended

installation of telephone

◆Do not expose the tele-

phone to direct sunlight or

other sources of heat.

◆Operate at temperatures

of between +5°C and

+40°C.

◆Maintain a distance of at

least one metre between

the telephone and radio

equipment, e.g. radio tel-

ephones, radio pagers or

TV sets. Otherwise, tele-

phone communication

could be impaired.

◆Do not install the tele-

phone in dusty rooms as

this can limit the service

life of the telephone.

◆Furniture lacquer and

polish can be adversely

affected by contact with

parts of the unit (e.g.

feet).

Making calls

Dialling a number

co Lift handset, dial

number.

The redial key ; can be

used to insert pauses when

dialling, starting at the 2nd

digit.

Dialling with the repertory

keys

cLift handset. (If

necessary press

shift key = for

2nd level reper-

tory key).

:Press repertory

key.

Last number redial

The last number dialled is

automatically saved (max. 32

characters).

c; Lift handset, press

last number redial

key.

Baby call dialling

Requirement: Baby call

(direct call) is activated. The

key K lights up when the

handset is lifted.

cLift handset then

press any key

(except ? and

J).

Mute is not possible with the

baby call function.

Mute

You can deactivate the tele-

phone's handset and micro-

phone during a call. You and

the other party will then no

longer be able to hear one

another. The connection will

not be broken; this will be indi-

cated by a waiting melody,

unless you have previously

deactivated the waiting mel-

ody.

JDuring a call: Press

mute key.

Switch the hand-

set and micro-

phone back on:

Press the key

again.

Saving numbers

Various settings on the tele-

phone have to be completed

with the Set ? key.

To cancel the save or setting

operation (e.g. after an incor-

rect entry) without saving,

replace the handset instead of

pressing ?. The original

setting is then retained.

◆When saving numbers,

pauses can be inserted by

pressing ; (not at the

1st digit!).

◆When saving numbers, the

last number dialled can be

inserted at the 1st digit by

pressing ; (max. 32

digits).

◆Saving deletes the previ-

ous content of the mem-

ory

Saving repertory numbers

You can save a total of up to

20 numbers (max. 32 digits)

on the two levels of repertory

keys.

c? Lift handset, press

Set key. (For 2nd

memory level,

also press = .)

:Press the reper-

tory key under

which you want to

save the repertory

number.

oEnter the number

to be saved.
