Sida 1/2

Installation Guide

www.si l v erstonetek . c om

Connect hard drive

to the PCB

Collegare il disco rigido

alla PCB

Подключите жесткий диск

к печатной плате

Festplatte an die Platine

anschließen

하드 드라이브를

PCB에 연결합니다

Conecte el disco duro al PCB

Connectez le disque dur au PCB

ハードディスクドライ

ブをPCBに接続します

將硬碟與電路板(PCB)連接将硬盘与电路板(PCB)连接

Slide the hard drive into

the aluminium case

Far scorrere il disco rigido

nel case di alluminio

Установите жесткий диск

в алюминиевый корпус

Festplatte in das

Aluminiumgehäuse

schieben

하드 드라이브를 알루미늄

케이스에 밀어 넣습니다

Deslice el disco duro en la

carcasa de aluminio

Glissez le disque dur dans le

boîtier en aluminium

ハードディスクドラ

イブをアルミニウム

製ケースに装着します

將硬碟滑入鋁外殼中将硬盘滑入铝外壳中

Secure the cover

with screws

Fissare il coperchio con le viti

Закрепите крышку винтами

Deckel mit Schrauben

fixieren

나사로 커버를 고정

합니다

Fije la cubierta con tornillos

Fixez le couvercle avec les vis

ネジでカバーを

固定します

用螺絲固定外蓋用螺丝固定外盖

mm 2.5” HDD/SSD

USB 3.0 enclosure

9.5

mm 2.5” HDD/SSD

USB 3.0 enclosure

This product has a limited 1 year warranty in North America, and Australia.

For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.

1. Product component defects or damages resulted from defective production is covered under warranty.

Defects or damages with the following conditions will be fixed or replaced under SilverStone Technology’s jurisdiction.

a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other inappropriate actions.

b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc…)

c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.

d) Warranty mark/stickers are not removed or broken.

Loss or damages resulted from conditions other than ones listed above are not covered under warranty.

2. Under warranty, SilverStone Technology’s maximum liability is limited to the current market value for the product (depreciated value, excluding

shipping, handling, and other fees). SilverStone Technology is not responsible for other damages or loss associated with the use of product.

3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no circumstances will SilverStone

Technology be liable for damages in connection with the sale, purchase, or use including but not limited to loss of data, loss of business, loss of

profits, loss of use of the product or incidental or consequential damage whether or not foreseeable and whether or not based on breach of

warranty, contract or negligence, even if SilverStone Technology has been advised of the possibility of such damages.

4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and is not transferable to a second hand

purchaser.

5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty eligibility.

6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone authorized distributors or SilverStone

http://www.silverstonetek.com.

Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt; (ii) You shall bear the cost of shipping

(or otherwise transporting) the product to SilverStone authorized distributors. SilverStone authorized distributors will bear the cost of shipping

(or otherwise transporting) the product back to you after completing the warranty service; (iii) Before you send the product, you must be issued a

Return Merchandise Authorization (“RMA”) number from SilverStone. Updated warranty information will be posted on SilverStone’s official

website. Please visit for the latest updates.http://www.silverstonetek.com

For North America (usasupport@silverstonetek.com) SilverStone Technology in North America may repair or replace defective

product with refurbished product that is not new but has been functionally tested.

Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All products

should be sent back to the place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA

procedure with SilverStone Technology in USA by first downloading the “USA RMA form for end-users” form from the below

link and follow its instructions.

http://silverstonetek.com/contactus.php

For Australia only (support@silverstonetek.com)

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable

loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

Please refer to above “Warranty terms & conditions” for further warranty details.

SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C.

+ 886-2-8228-1238

(standard international call charges apply)

For Europe (support.eu@silverstonetek.de)

For all other regions (support@silverstonetek.com)

NO:G11218331

www.si l v erstonetek . c om

Installation complete Installazione completata

Сборка завершена

Die Installation ist

damit abgeschlossen

설치가 완료 되었습니다

Instalación finalizada

Installation terminée

インストールは完了です安裝完成安装完成

1.Connect USB type

A connector to the

computer

2.Connect USB 3.0

micro-B connector

to the enclosure

1.Collegare il connettore

USB di tipo A al computer

2.Collegare il connettore

USB 3.0 Micro-B al box

1.Подключите разъем

USB типа A к компьютеру

2.Подключите

микроразъем USB 3.0

типа устройству B к

1.USB-A-Stecker an

den Computer

anschließen

2.Micro-USB 3.0

-B-Stecker an das

Gehäuse anschließen

1.USB 타입 A 커넥터

를 컴퓨터에

연결합니다

2.USB 3.0 마이크로

B 커넥터를 인클로저에

연결합니다

1.Enchufe el conector USB tipo

A al ordenador

2.Enchufe el conector USB 3.0

micro-B a la carcasa

1.Connectez le connecteur USB

de type A à l'ordinateur

2.Connectez le connecteur

micro-B USB 3.0 à l'accessoire

1.USB タイプAコネクタ

をコンピュータに接続

します

2.USB 3.0マイクロBコ

ネクタをエンクロージ

ャーに接続します

1.將USB type A型接頭與電腦連接

2.將USB 3.0 micro-B型接頭與

外接盒連接

1.将USB type A型接头与

计算机连接

2.将USB 3.0 micro-B型接头

与外接盒连接

Produktspecifikationer

Varumärke:	SilverStone
Kategori:	Extern hårddisk
Modell:	TS10
Färg på produkten:	Groen
Vikt:	32 g
Bredd:	58 mm
Djup:	80 mm
Höjd:	20 mm
Förpackningens vikt:	90 g
Förpackningens bredd:	125 mm
Djuppackning:	175 mm
Förpackningshöjd:	30 mm
Typ av förpackning:	Doos
Ursprungsland:	China
Avsedd för:	PC
Internera:	Ja
Antal portar USB 3.2 Gen 2 (3.1 Gen 2) Typ C:	2
Stöder Linux:	Ja
Snabbinstallationsguide:	Ja
Värdgränssnitt:	PCIe
Medföljande drivrutiner:	Ja
Monteringsfästen ingår:	Ja
Chipset:	ASM1142
(Ytter) huvudpaketets höjd:	405 mm
(Ytter) huvudförpackningens bredd:	340 mm
(Ytter) huvudförpackningens bruttovikt:	2700 g
(Ytre) huvudpaketets längd:	205 mm
Kvantitet per (yttre) huvudkartong:	30 stuk(s)
Harmoniserad systemkod (HS):	84733020
Hot-swap:	Ja
Expansionskort standard:	PCI 2.0
Dataöverföringshastighet (max):	10 Gbit/s
Antal interna SATA-portar:	1
Utgångsgränssnitt:	USB 3.2 Gen 2 (3.1 Gen 2)
UASP-stöd:	Ja
SATA-strömkontakttyp:	SATA 15-pin
