A Division of Snow Joe®, LLC

Model No. SWJ701E Form No. SJ-SWJ701E-880E

OPERATOR’S MANUAL

18-Inch Electric Chain Saw

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

General Power Tool Safety Warnings

m WARNING!

Read all safety warnings and

instructions. All users of this chain saw must rst

carefully read this maintenance and operating manual and

familiarize themselves fully with all of the controls for its

correct operation.

Safety Rules

1. Replacement parts – When servicing, use only

identical replacement parts.

2. Polarized plugs – To reduce the risk of electrical

shock, this tool has a polarized plug (one blade is

wider than the other). The plug will t into a polarized

outlet only one way. If the plug does not t fully into the

outlet, reverse the plug. If it still does not t, contact a

qualied electrician to install the proper outlet. Do not

change the plug in any way.

3. Keep the work area clean – Cluttered areas invite

injuries. Do not start cutting until you have a clear work

area, secure footing, and a planned retreat path from

falling tree limbs.

4. Consider the work area environment – Use extreme

caution when cutting small size brush and saplings

because the slender material may catch the saw chain

and be whipped toward you or pull you off balance.

• Do not operate the chain saw in a tree unless

you are specically trained to do so.

• When cutting a limb that is under tension, be

cautious of spring back so that you will not be

struck when the tension in the wood bers is

released.

• Do not expose the chain saw to rain.

• Do not use the chain saw in damp or wet locations.

• Do not use the chain saw in the presence of

ammable liquids or gases.

5. Guard against electric shock – Avoid body contact

with grounded surfaces, such as metal pipes and wire

fences.

6. Keep children and bystanders away – Do not let

children, pets, or other bystanders contact the chain

saw or extension cord. All spectators should be kept a

safe distance away from the work area.

7. Store idle chain saw – When not in use, chain saws

should be stored in a dry and high or locked-up place

out of the reach of children. When storing the chain

saw, use a scabbard or carrying case.

8. Do not force chain saw – It will do the job better and

with less likelihood of injury if it is used at the rate for

which it was intended.

9. Use the right tool – Cut wood only. Do not use the

chain saw for purposes other than those for which it is

intended. For example, do not cut plastic, masonry, or

non-wood building materials.

10. Dress properly – Do not wear loose clothing or

jewelry. They can get caught in moving parts. Rubber

gloves and non-skid footwear are recommended when

working outdoors. Wear protective hair covering to

contain long hair.

11. Use safety glasses – Also use safety footwear,

snug-tting clothing, protective gloves, hearing and

head protection.

12. Carry the saw properly – Carry the chain saw by

the front handle with the saw stopped, nger off the

switch, and the guide bar and saw chain pointed

toward the rear.

13. Maintain the chain saw with care – Inspect the chain

saw cord periodically and, if damaged is found, have it

repaired by an authorized service facility.

• Keep the cord clear of the saw chain and operator

at all times. Never carry the chain saw by the

cord or pull the cord to disconnect it from the

receptacle. Keep the cord away from oil and sharp

edges.

• Inspect extension cords periodically and replace

them if damaged.

• Keep tools sharp and clean for better and safer

performance.

• Follow instructions for lubricating and changing

accessories.

• Keep handles dry, clean, and free from oil and

grease.

14. Disconnect the chain saw – Disconnect the chain

saw when not in use, before servicing, and when

changing accessories and attachments, such as the

saw chain and guard.

15. Outdoor use extension cords – Use only extension

cords that are marked and intended for outdoor use.

16. Stay alert – Watch what you are doing. Use common

sense. Do not operate the chain saw when you are

tired. Keep all parts of the body away from the saw

chain when the motor is operating.

Before you start the saw, make sure the saw chain is

not contacting anything.

17. Check for damaged parts – Before further use of

the chain saw, a guard or other part that is damaged

should be carefully checked to determine that it will

operate properly and perform its intended function.

Check for alignment of moving parts, binding of

moving parts, breakage of parts, mounting, and any

other conditions that may affect its operation. A guard

or other part that is damaged should be properly

repaired or replaced by an authorized service center

unless otherwise indicated in this instruction manual.

Have defective switches replaced by an authorized

service center. Do not use the chain saw if the switch

does not turn it on and off. Do not operate a chain

saw that is damaged, improperly adjusted, or is not

completely and securely assembled. Make sure

that the saw chain stops moving when the trigger is

released.

18. Guard against kickback –

mWARNING! KICKBACK

may occur when the nose or tip of the guide bar

touches an object, or when the wood closes in and

pinches the saw chain in the cut. Tip contact in some

cases may cause a lightning fast reverse reaction,

kicking the guide bar up and back towards the

operator. Pinching the saw chain along the top of the

guide bar may push the guide bar rapidly back towards

the operator. Either of these reactions may cause you

to lose control of the saw, which could result in serious

injury to the user. The following precautions should be

followed to minimize kickback:

a. Grip the tool rmly. When the motor is running,

hold the chain saw rmly by the front and rear

handle using both hands. Use a tight grip with

thumbs and ngers encircling the chain saw

handles. If a manual oil-regulator control NOTE:

is provided, additional or modied instructions

regarding its use are to be provided.

b. Do not overreach.

c. Keep proper footing and balance at all times.

d. Do not let the nose of the guide bar contact a log,

branch, ground or other obstruction.

e. Do not cut above shoulder height.

f. Use devices such as low kickback chain, guide bar

nose guard, chain brakes and special guide bars to

reduce the risks associated with kickback.

g. Only use replacement bars and chains specied by

the manufacturer or the equivalent.

19. Power supply – Connect the chain saw to the correct

voltage (i.e. make sure that the voltage supplied is the

same as that specied on the name plate of the tool).

20. Intended/not intended use – This chain saw is only

designed for the cutting of brushes, trunks or timber

beams up to a diameter according to the guide bar

length. It is only allowed to cut wood. This machine

is not intended to be used for any other purpose.

Furthermore, using this machine for professional

tree cutting services is strictly forbidden. During

operation of the chain saw, the user must wear

personal protective equipment as instructed in the

manual and follow the warning labels on the chain

saw. Intended use of the chain saw is detailed in the

manual. Please follow safety warnings. Everyone who

either uses the chain saw or performs maintenance

on it must be familiar with the instruction manual. Use

only manufacturer's original or approved spare parts

(e.g. guide bar, saw chain) and use only the allowed

combinations of guide bar/saw chain specied in this

manual.

The user, not the manufacturer, is completely liable for every

accident that results from non-intended use of the tool or for

injuries sustained as a result of an impermissible alteration of

the machine.

The chain saw is only intended for outdoor use.

Residual Risks – Intended/Not Intended

Use

Even when using the machine in accordance with its

prescribed intended use, there always remains a residual

risk, which cannot be prevented. According to the type and

construction of the appliance, the following potential hazards

may apply:

• Contact with exposed saw teeth of the saw chain

(cutting hazards).

• Access to the rotating saw chain (cutting hazards).

• Unforeseen, abrupt movement of the guide bar

(cutting hazards).

• Flung/dispersed parts from the work piece.

• Skin contact with the oil.

• Loss of hearing, if required ear protection is not used during

work.

• There may be health risks caused by breathing in the

wood dust, especially during the sawing of oak, beech and

medium density reboard.

Extension Cords

• Make sure your extension cord is in good condition. When

using an extension cord, make sure to use one heavy

enough to carry the current your product will draw. An

undersized cord will cause a drop in line voltage, resulting

in loss of power and overheating. Table 1 shows the

correct size of cord to use depending on cord length and

nameplate ampere rating. If in doubt, use the next heavier

gauge. The smaller the gauge number, the heavier the cord.

• Ground Fault Circuit Interrupter (GFCI) protection should

be provided on the circuits or outlets to be used for this

electric chain saw. Receptacles are available having built-

in GFCI protection and may be used for this measure of

safety.

• Use only UL listed extension cords. Inspect extension

cord before use and never use damaged or altered

extension cords. Follow extension cord manufacturer

safety instructions.

• To reduce the risk of the appliance cord disconnecting

from the extension cord during operation, use the

plug-receptacle retaining straps provided or make a knot

with the two cords as shown in Table 2.

• Do not abuse the cord. Never use the cord to carry

the tools or pull the plug from the outlet.

• Keep cord away from heat, oil, sharp edges, or moving

parts. Replace damaged cords immediately. Damaged

cords increase the risk of electrical shock.

Table 1. Minimum Recommended Extension Cord Gauge

(AWG) Chart

Table 2. Method of Securing Extension Cord

General Safety Instructions

for Chain Saw User

• It is important that this tool be protected by the use of a

residual current device.

• Cluttered areas and benches can cause accidents.

• Read the following safety instruction manual before

attempting to operate this device. Be aware of the tool's

operation range and limitations as well as its dangers.

• When not in use, power tools must be stored in a dry place

and locked up securely, out of the reach of children and

unauthorized persons.

• When not in use, when transporting between work

locations, or when carrying out any form of maintenance,

the tool must be disconnected from the mains power and

the saw guard must be tted.

• Never allow the chain saw near your body or your clothing.

• When switching on the chain saw, make sure the chain is

not touching anything.

• Do not start up or use the chain saw near people,animals,

or obstructions.

• During operation, keep the tool a safe distance (at least

10 m) away from the above hazards.

• Always use both hands to operate the chain saw; place the

right hand on the rear handle and the left hand on the front

handle (see page 6 – Know Your Electric Chain Saw).

mWARNING! Never attempt to operate ‘left-handed’ as

serious personal injury may result.

• Stand in a safe and comfortable position with both feet

rmly planted on a level and secure surface.

• Never carry the chain saw by the cable.

• Keep the cable away from heat sources, oils, or sharp

edges.

100

150

Volts

120V

1 – 5

6 – 10

10 – 12

12 – 16

Total length of cord in feet

AWG

(Extension Cord Gauge)

Not Recommended

Ampere Rating

(B) Connect plug and receptacle

Cord set Appliance cord

(A) Tie cord as shown

Produktspecifikationer

Varumärke:	Snow Joe
Kategori:	Sågmaskin
Modell:	Saw Joe SWJ701E
Enhetsplacering:	Volledig ingebouwd
Vikt:	44000 g
Bredd:	595 mm
Djup:	545 mm
Höjd:	820 mm
Nettoskatt:	2170 W
Antal platsinställningar:	12 couverts
Dörrfärg:	Niet van toepassing
Sladdlängd:	1.7 m
Fördröjd starttimer:	Ja
Startfördröjning:	9 uur
Torkningsklass:	A
Ljudnivå:	49 dB
Årlig-energiförbrukning:	231 kWu
Förpackningens vikt:	47000 g
Energieffektivitetsklass (gammal):	A
Mått för installationsfack (BxDxH):	600 x 600 x 820 mm
Vattenförbrukning per cykel:	13 l
Var klass:	A
Antal tvättprogram:	6
Färgkontrollpanel:	Zwart
Antal temperaturinställningar:	4
Tvättprogram:	Eco, Glass/delicate, Intensive, Normal, Pre-wash, Quick
Energiförbrukning per cykel:	1.05 kWu
Årlig vattenförbrukning:	3080 l
Temperatur (max):	70 °C
AC-ingångsspänning:	220 - 240 V
AC-ingångsfrekvens:	50 Hz
