Sida 1/24
Confidence Monitors
User Handbook
RM-CA2 Confidence Monitor, 2 LED Meters & 2
Analogue Stereo Inputs
RM-CAD8 Confidence Monitor, 2 LED Meters, 2
Analogue & 6 Digital Stereo Inputs
Condence Monitors User Handbook
This handbook is for use with the following product:
RM-CA2 Confidence Monitor, 2 LED Meters & 2 Analogue Stereo Inputs
RM-CAD8 Confidence Monitor, 2 LED Meters, 2 Analogue & 6 Digital Stereo Inputs
©Sonifex Ltd, 2009
All Rights Reserved
Revision 1.00, May 2009
Sonifex Ltd, 61, Station Road, Irthlingborough,
Northants, NN9 5QE, England.
Tel: +44 (0)1933 650 700
Fax: +44 (0)1933 650 726
Email: sales@sonifex.co.uk
Website: http://www.sonifex.co.uk
Information in this document is subject to change without notice and does not represent a commitment on the part of
the vendor. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising from the use of information or any
error contained in this manual.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying, recording, information storage and retrieval systems, for any purpose other than the purchaser’s
personal use, without the express written permission of Sonifex Ltd. Unless otherwise noted, all names of companies,
products and persons contained herein are part of a completely fictitious adaptation and are designed solely to
document the use of Sonifex product.
CONFIDENCE MONITORS
USER HANDBOOK
CO N F I D E N C E M O N I TO R S U S E R H A N D B O O K
Condence Monitors User Handbook
CONTENTS
CONTENTS
Warranty i
Warranty and Liability i
Unpacking the Condence Monitor iii
Returning the Warranty Card iii
Safety Information iv
Safety of Mains Operated Equipment iv
Voltage Setting Checks iv
Fuse Rating iv
Power Cable and Connection iv
Ordering the Correct Mains Lead v
Installation Information v
Atmosphere v
Electromagnetic Radiation v
WEEE & RoHS Directives - Sonifex Statement vi
Condence Monitors Introduction 1
Detail In The Design 1
Anti-Vibration 1
Accurate Sound System 1
Features Summary 2
DSP Based Design 2
RM-CA2 Condence Monitor, 2 LED Meters & 2 Analogue Stereo Inputs 3
RM-CAD8 Condence Monitor, 2 LED Meters, 2 Analogue & 6 Digital Stereo Inputs 4
System Block Diagram 4
Front Panel Indicators & Controls 5
Power LED 5
Source Selector 5
Sync Lost indicator 6
Main Meters 6
PHASE Error LED 6
Level and Balance Controls 7
Headphone Output 7
Rear Panel Connections & Operation 8
Line Level Audio Outputs 9
Mains Power 9
DIPSwitch Settings 10
Reduce Meter Levels by 10dB - DIPSwitch 1 10
Reduce Output Levels by 10dB - DIPSwitch 5 10
Meter Characteristics Selection - DIPSwitch 7 10
Technical Specication RM-CA2 & RM-CAD8 11
