16 Port Megabit PoE Switch with
2 Gigabit Uplink ports - PoE 802.3at
Features
P16S182
16 Port Megabit PoE Switch with 2 Gigabit
Uplink ports - PoE 802.3at
• 16 x 10/100M PoE ports + Uplink 2x10/100/1000M
Ethernet ports + 1xGigabit SFP port Ethernet Switch
• Detects and supports IEEE802.3af or IEEE802.3at
PoE standards
• Flow control mode: full-duplex adopts IEEE 802.3x
standard, half-duplex adopts Back pressure standard
• Compatible with 1U rack installation (rack ears included)
I/O Interface
Power Input AC 100-240V, 50/60Hz,
Power supply 52V 5.76A
Fixed Port
16 x 10/100M PoE Port
2 x 10/100/1000M
Ethernet Uplink ports
1 x Gigabit SFP Uplink port
Standard
Network protocol
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab(1000Base-TX)
IEEE802.3z(1000Base-FX)
IEEE802.3x (Flow control)
PoE Protocol IEEE802.3af (15.4W)
IEEE802.3at (30W)
Industry Standard
EMI: FCC Part 15 CISPR
(EN55032) class A
EMS: EN61000-4-2 (ESD),
EN61000-4-4 (EFT),
EN61000-4-5 (Surge)
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Network Medium
10Base-T: Cat3, 4, 5
or above UTP( 250m)≤
100Base-TX: Cat5
or above UTP( 150m) ≤
1000Base-TX: Cat5 or
above UTP( 100m) ≤
Optical Media
Multi-mode ber:
50/125, 62.5/125, 100/140μm
Single mode ber:
8/125, 8.7/125, 9/125, 10/125μm
Environment
Working Environment
Working Temperature:
14°F to 122°F (-10 ~ 50°C)
Storage Temperature:
-40°F to 158°F (-40 ~ 70°C)
Working Humidity:
10%~90%, non-condensing
Storage Humidity:
5%~90%, non-condensing
Working Height: Maximum 10,000 ft
Storage Height: Maximum 10,000 ft
Certificates
Security Certicate CE, FCC, RoHS
Mechanical
Dimensions and weights
Product Dimension (L*W*H):
12.5” x 8.1” x 1.77” (319*207*45mm)
Weight: 3.96lbs (1.8kg)
Indication
LED Indicators PWR (Power Supply), SW(DIP),
1-19 Green (Link & Data)
PWR Lighting: Powered, No Light: No Power
SW Lighting: VLAN, No Light: OFF
Flashing: Extend
1-19 Green
Lighting: Connecting/Connected
Flashing: Data Transmit
No Light: Disconnected
DIP Switch
(VLAN) Port isolation mode. In this mode,
the PoE ports (1-16) of the switch cannot
communicate with each other, and can
only communicate with the Uplink port.
(OFF) Normal mode, all ports can
communicate with each other, the
transmission distance is within 100 meters,
the transmission rate is 10M/100M adaptive
(Extend) Link extension mode, 1-16 ports
PoE power supply and data transmission
distance can be extended to 250 meters,
the transmission rate becomes 10M
Performance
Switching Capacity 9.2Gbps
Throughput 6.844Mpps
Packet Buffer 1.5Mb
MAC Address 2K
Jumbo Frame 9216bytes
Transfer Mode Store and forward
MTBF 100,000 hours
Max PoE power (all ports) 280w
*Products are in compliance with NDAA Section 889 Part B Guidelines
®
800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • www.specotech.com
Speco Technologies is constantly developing and improving products. We reserve the right to modify
product design and specifications without notice and without incurring any obligation. Spec Rev. 3/25/24
Front View
Back View
