CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
OPEN COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
WARNING: REMOVAL OF THE
COVER SHOULD ONLY BE PER-
FORMED BY QUALIFIED SERVICE
PERSONNEL - NOT USER SER-
VICEABLE. THE UNIT SHOULD
ALWAYS BE UNPLUGGED BEFORE
REMOVING THE COVER, AND
REMAIN UNPLUGGED WHILE THE
COVER IS REMOVED.
WARNING: TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT
EXPOSE UNITS NOT
SPECIFICALLY DESIGNED FOR
OUTDOOR USE TO RAIN OR
MOISTURE.
INSTRUCTION
MANUAL
PUBLIC ADDRESS
MIXER POWER AMPLIFIER
PL-260A
RISK OF ELECTRIC
SHOCK, DO NOT OPEN!
260 WATT RMS
200 NEW HIGHWAY, AMITYVILLE, NY11701
PHONE : 1-800-645-5516, 631-957-8700 IN METRO NY
http://www.specotech.com
1.Unpacking
After removing the amplifier from the carton, inspect for any exterior damage to
the unit. If damage is noted, notify the carrier at once so that a claim can be
justified. Save all packing material. This is important when the claim is
processed.
PRECAUTIONS
2.Ventilation
To offset heat generated by the unit, it is necessary to provide ample ventilation
around the unit. Avoid blocking or impeding the ventilation holes on the unit. To
prevent unnecessary problems, install the unit in a place free from any
vibrations, direct sunlight, humidity or dust circulation.
3.Avoid spilling liquids or allowing materials to enter the cabinet
If the unit gets wet or any foreign material enters the cabinet, immediately
disconnect the A.C. line cord and consult your dealer or qualied technician.
IMPORTANT SAFETY INSTRUCTIONS
1. Read Instructions - All the safety and operating instructions should be read before the unit is operated.
2. Retain Instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to.
4. Follow Instructions - All operating instructions should be followed.
5. Do not use this unit near water-for example, near a bath tub, wash basin, kitchen sink, in a laundry room, in a wet basement,
near a swimming pool, in an unprotected outdoor installation, or any area which is classied as a wet location.
6. Unplug unit from AC outlet, use a damp cloth for cleaning. Do not use liquid cleaners or aerosol cleaners.
7. Do not block any of the ventilation openings. Install in accordance with the instructions provided.
8. Do not install near any heat sources such as radiators, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not mount amplifier in an enclosure or a closed, unventilated closet while operating.
10. Do not place any object or accessory equipment such as Tuners, Mixers, Cassette Decks, etc. on top of the amplifier.
Obstructing or closing the cabinet ventilation openings may cause overheating.
11. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third grounding prong. The wide blade and or the third prong is provided
for your safety. When the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
12. Protect the power cord form being walked on or pinched particularly at plugs, convenience outlets, and the point where they exit
from the apparatus.
13. Use only the attachments and accessories specied in this manual.
14. If a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
15. Unplug this apparatus during lightning storms or when not used for long periods of time.
16. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power supply cord or plug damage, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been dropped.
17. Do not replace fuse unless power cord is disconnected from the AC wall outlet.
18. Do not install accessories unless the power cord has been removed from the AC wall outlet.
19. Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such as vases, shall be placed on the
apparatus.
20. Warning To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture. –
21.Caution Use of any controls or adjustments or performance of procedures other than those specied herein may result in –
hazardous radiation exposure.
Controls and Connections for the PL-260A P.A. Amplifier
FRONT PANEL
11
12
14
15
16
1
2
4
5
6
7
9
10
REAR PANEL
11
1
2
3
4
5
6
8
7
9
10 11 12 13 1 4 15
17
18
16
20
19
21
22
23
24
25
26
FRONT PANEL
1) MIC-1 input jack (1/4’’ phone jack).
2) MIC-5/AUX-1 Volume control.
3) AUX-2 Volume control.
4) AUX-3 Volume control.
5) Bass Control.
6) Treble Control.
7) Zone 1-7 selector switches.
8) All zone selector switch.
REAR PANEL
1) AC power cord.
2) Ground.
3) DC input terminals for battery backup.
4) Speaker output terminals.
5) AUX output RCA jacks.
6) Preamp output RCA jacks.
7) EQ / MIX input RCA jacks.
8) AUX-3 input RCA jacks.
9) AUX-2 input RCA jacks.
10) AUX-1 input RCA jacks.
11) AUX1/MIC5 input select switch.
12) MIC-5 (XLR connector) input.
13) MIC-4 (XLR connector) input.
*MOH = Music on hold
**TEL/PAGING= Connection input terminals for
general or emergency paging.
**TEL/PAGING is not to be connected directly to a
telephone circuit or TNV circuit.
9) Power on/o switch.
10) Power on indicator.
11) MIC-1 Volume control.
12) MIC-2 Volume control.
13) MIC-3 Volume control.
14) MIC-4 Volume control.
15) Master Volume control.
16) Output level indicator.
14) Individual Phantom Power on/o switches.
15) MIC-3 (XLR connector) input.
16) MIC-2 (XLR connector) input.
17) MIC-1 (XLR connector) input.
18) MIC-1 VOX voice override on/o switch.
19) AC accessory outlet (Unswitched).
20) Zone output 25V/70V select switch.
21) AC fuse holder.
22) Zone 1~7 output terminals.
23) MOH output level control.*
24) MOH output terminals.*
25) TEL / PAGING input terminals. (Balanced )**
26) TEL / PAGING input level control.**
