PSD 4000
SPL‘s PERSONAL SOUND DESIGNER PSD 4000
offers high-end tube circuits and latest profes-
sional audio technologies for individual sound
design in HiFi and home theatre applications.
These applications are essentially characteri-
zed by individual parameters – combination of
AV equipment, room acoustic, personal sound
preferences and the quality of audio sources.
The PSD 4000 is the all new tool to design the
sound you love.
The PSD 4000 ”dis-covers” previously masked
audio elements by shifting the timing of per-
ception differently in accordance to their loud-
ness. The result is a substantial improvement
of detail and depth creating a vivid sound
atmosphere and amazing naturalness of the
audio. Previously lost details are recovered
and the perceived loudness is increased.
What you like is what you get
While preserving amplifi ers, especially Pop/
Rock material gains enormous loudness. Too
harsh sounds in the mid-hi range are
smoothened without negative side-effects.
Intelligibility and detail are improved remar-
kably, while the enhanced presence let vocals
come ready-to-hand. A brilliant and silky top
end rounds off the processing.
Due to its excellent tonal quality and disarmin-
gly ease of use, the PSD 4000 defi nes the refe-
rence in sound optimizing.
Applications
The PSD 4000 will bring more hearing pleasure
to almost any HiFi or home theatre situation:
• fi Room- lling sounds from smallest speakers
• Big movie cinema sound in your home theatre
• More powerful sounds from your TV set
• More natural sounds from digital sources
• „Reanimation“ of compressed audio (MD)
• Room acoustic adjustment
• CD or DAT storage of vinyl recordings with
your personal sound design
• Optimized recordings for special environ-
ments (e. g. car)
• Overwhealming sound enhancement for
computer games or multimedia applications
Features
• High-end tube circuits for highest possible
fi delity
• Drive Control to set the input level between
-20 dB and +6 dB
• Bass Compressor smoothens unsteady levels
• Stereo Expander to control the stereo width
• GND-Lift switch to eliminate hum problems
• Hard Bypass Relay / Power Fail Safety
Specifi cations
Instrumentation amplifi er, electronically balanced
(differential), transformerless
Nominal input level +6 dB
Input impedance = 22 kOhms
Output impedance ‹ 600 Ohms
Max. input level +20 dBu
Max. output level +20 dBu
Minimum load ohms 600 Ohms
Frequency response 20 Hz - 100 kHz
EQ frequency range 20 Hz - 22 kHz
CCMR - 80 dBu @1 kHz
THD & N 0,01855 % @ 1 kHz
S/N (A-weighted) - 99 dBu
Toroidal transformer 15 VA
Fuse 315 mA (slow blow)
Housing 440 x 75 x 235 mm
Weight 3,4 kg
Hard bypass relay/power fail safety, GND-lift switch,
voltage selector
Note: 0 dBu = 0.775 V. Subject to change without notice.
HiFi Stereo
The PSD 4000 should
either be connected to
the amplifi er‘s TAPE
IN/OUT insert or
directly between audio
source (CD player) and
preamplifi er.
Dolby® ProLogic®
To use the PSD 4000
in Dolby® ProLogic®
environments, simply
connect it as described
above.
Stereo units like the
PSD 4000 are ideally
suited to process the
complete ProLogic®
information.
Dolby Digital® (AC3) &
DTS®
To process certain
channels of discrete
mulitchannel formats,
use the respectivve
insert points of the
receiver.
We recommend to
process the left and
right front channels.
