Sound Performance Lab
Mute
Model 2602
Dual Channel Volume Control
Volume 2
Model 2602
2Volume 2 
Version 1.1 – 11/2009
Designer: Wolfgang Neumann
This user's guide contains a description of the product. It in no way repre-
sents a guarantee of particular characteristics or results of use. The informa-
tion in this document has been carefully compiled and veried and, unless
otherwise stated or agreed upon, correctly describes the product at the time
of packaging with this document.
Sound Performance Lab (SPL) continuously strives to improve its products
and reserves the right to modify the product described in this manual at any
time without prior notice. This document is the property of SPL and may not
be copied or reproduced in any manner, in part or fully, without prior authori-
zation by SPL.
SPL electronics GmbH
Sohlweg 80, 41372 Niederkruechten, Germany
Phone +49 (0)2163 983 40
Fax +49 (0)2163 983 420
E-Mail: info@spl.info
Internet: www.spl.info
The construction of the Volume 2, Model 2602, is in compliance
with the standards and regulations of the European Cummunity.
Notes on Environmental Protection
At the end of its operating life, this product must not be disposed
of with regular household waste but must be returned to a coll-
ection point for the recycling of electrical and electronic equip-
ment. The wheelie bin symbol on the product, user‘s manual and
packaging indicates that. The materials can be re-used in accor-
dance with their markings. Through re-use, recycling of raw mate-
rials, or other forms of recycling of old products, you are making an important
contribution to the protection of our environment. Your local administrative
ofce can advise you of the responsible waste disposal point.
WEEE Registration: 973 349 88
© 2009 SPL electronics GmbH. All rights reserved. Names of other companies and their products are trademarks of
their respective owners.
Manual Volume 2, Model 2602
3
Volume 2
Introduction ............................................................................................... 4
Installation and Security Advices .............................................................. 5
Power Supply .............................................................................................. 5
Rear Panel .................................................................................................. 6
Power Supply, ON/Off Switching ................................................................ 6
Rear Panel Graphic, Signal Connections, XLR Pin Wiring ............................. 6
Unbalanced Connections (i. e. RCA, TS Jack) .............................................. 7
Operation ................................................................................................... 7
Volume Control ........................................................................................... 7
Calibrating the Monitoring System ............................................................. 7
Mute ........................................................................................................... 8
Specications ............................................................................................ 8
Measurements ........................................................................................... 9
Guarantee & Product Registration ............................................................. 11
Contents
