Operation
Manual
By
Models: SM-351WCR
&
SM-353WCR & SM-353WCRU
(International)
Buffet
Induction
Cookware
The Evolution of Intelligent Design®
Spring USA®
127 Ambassador Drive
Suite 147
Naperville, IL 60540-4079
Phone: (1) 630-527-8600
Fax: 630-527-8677
Email: springusa@springusa.com
Web: www.springusa.com
1
8
Never touch the glass plate immediately after cooking. The surface of the
cooktop may remain hot due to the heat transferred from the cookware.
Do not damage the glass surface of the induction range. If the glass plate
is broken, turn the unit off and unplug it immediately. Call Spring USA
at (1) 630-527-8600 for service or warranty. Be sure to have your Model
# and Serial Number available when you contact our office or when
completing the service form on the website.
To clean your MAX Induction® Range, unplug the unit from its power
source. Wipe the unit down with a sponge or cloth with a mild
dishwashing liquid. Dry with a clean, soft cloth. Do not immerse the
induction range directly in water for cleaning – this will damage the unit.
Remember to clean the vent located on the underside and at the back of the
unit. Inspect the mesh air filter on the underside of the induction range,
each day. If it is soiled, remove the filter and wash it with dish washing
detergent. Dry and replace before operating the induction range.
Keep your induction range away from other ovens or stoves. If the
surrounding temperature is hot, your induction range may stop heating.
Before You Begin:
Read the following instructions in their entirety.
Use proper cookware. See specifications, below.
Check your ventilation. Your MAX Induction® Wok Range must have
the proper ventilation in order to operate correctly. There must be at least
4” of space available around your induction range.
Ensure that you have dedicated power to the installed location. Verify the
electrical requirements for your specific model induction range, as shown
on Page 4.
2 7
Suitable Cookware:
Your MAX Induction® Wok Range requires the use of induction-ready
Wok Pans.
For optimal heating and performance the induction woks shown below
should be used. The hemispherical shape of these Wok Pans are
specifically matched to the radius of the range glass and induction coil
inside the induction range.
Alternative wok pans may heat on the range, but optimal performance will
be achieved by using the pans designed specifically for this system.
The following Spring USA components are recommended for use with the
MAX Induction® Wok Range.
Mounting of the Control Panel:
To install the control panel, use the template provided. Please the template
on a plane or panel, perpendicular to the Wok Range, centering it to the
range whenever possible. Once you have cut the opening, insert the control
panel. Using the bracket provided, secure the control panel into place.
Connect the control box cable to the induction range.
Maintaining Your MAX Induction® Range:
Vulcano 32 cm Non-Stick
Wok Pan
4 Qt (130 oz)
Item # 8217-60/32 Primo! 34 cm Wok Pan
7.3 Qt (232 oz)
Item # 8217-60/34
5.315”
[135mm]
Safety Precautions:
Plug the power cord into a dedicated circuit. Nothing else should be Note:
plugged into this circuit. Each MAX Induction® Range must have its own,
sufficient power supply as outlined below. Once you have plugged the unit
in, it will beep, and an ‘EO’ code will appear in the display window.
To Begin:
Turn the unit on. An ‘EO’ code will appear next in the digital window,
indicating the induction range is searching for cookware.
Turn the knob clockwise to turn the unit on. Your MAX Induction® range
will always start out in the “Cook” mode. “Cook” is the default mode.
Place suitable cookware within the circle on top of the MAX Induction®
Range.
Select either the “Cook” Mode or the “Temp” Mode.
In “Cook” mode, turn the dial clockwise. The LED will display cook
power levels of 1 thru 20.
In “Temp” mode, turn the dial clockwise. The LED will display
temperature levels from 110° to 400° fahrenheit (43° to 204° celsius).
Turn the knob clockwise to set the power level or temperature.
To shut the induction range off, turn the knob counter clockwise until you
hear the unit ‘click’ and turn off.
Actual range temperatures may vary due to a number of variables, such
as ambient temperature in the immediate surrounding area, content and
volume of food being heated or cooked, and whether or not you are
using a cover on the cookware.
Never attempt to service any part of your MAX Induction® Range on
your own. Contact our Service Department by calling (1) 630-527-
8600. Attempting to service your Induction Range on your own, or
through an unauthorized repair facility automatically voids your
warranty. For service forms, visit the Spring USA website.
For Limited Warranty Information, visit www.springusa.com
Note:
This equipment uses, generates and can radiate radio frequency energy.
If not installed correctly and used in accordance with the instructions,
may cause harmful interference to radio communications. Users or
guests with Pacemakers should contact their health care professional
prior to using this product.
CEE 7/7 16A
1.8 m Cord
3000 Watts ~ 50 Hz220-240 Volts / 15
Amps
SM-353WCRU
NEMA 6-20P
6’ Cord
3500 Watts ~ 60 Hz208-220 Volts / 15
Amps
SM-351WCR
CEE 7/7 16A
1.8 m Cord
3500 Watts ~ 50 Hz220-240 Volts / 15
Amps
SM-353WCR
Plug TypePeak PowerVoltage / AmpsModel #
Specifications:
Induction Range Error Codes:
www.springusa.com
(1) 630-527-8600
Review your dedicated power
requirements. Each range must
operate with the power required on
Page 4.
Range will not turn on. Range is
experiencing temporary voltage
overload or is not on its own,
dedicated circuit.
E3
Remove the cookware from the
range and let the range cool. Make
sure the vents are clear. Verify you
are using induction-ready
cookware. Once the range has
cooled, restart.
The range has overheated.
E2
Clear vents, let range cool down,
then restart. If error message
continues, your range needs to be
serviced.
Range has overheated due to
blocked ventilation and has shut
down the range.
E1
Place an induction ready pan on
the range.
Induction range does not sense
induction-ready cookware has
been placed on the glass surface
E0
SolutionCauseError
4 5
All International Ranges ship with a CEE 7/7 16A plug. International
plugs must be changed to match the national standard, based on country
requirement.
