Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 29, 2023
Product ID
2S232422485-PC-CARD
PS74ADF-SERIAL-CARD
Port/LED/
Connector Function
1Bracket
Secures the card to the Host Computer Case
The comes pre-installed Full Prole Bracket
The is included Low Prole Bracket
2Activity LEDs Data Receive LED: GreenFlash to show activity
Data Transmit LED: YellowFlash to show activity
3DB9 Serial Ports Connect Serial Peripheral Devices
4Serial Mode
Switch
Change the between , , DB9 Serial Ports RS-232 RS-422
or RS-485
PCIe p1-x1 RS232/422/485 Serial Card - Low-Prole Brackets Included
5J1/J2/J3/J4
Jumper
Optional: Used to change the of Voltage Output DB9
Pin 9
RI DB9 Pin 9disables power on . This is the default
setting.
12V SATA Power Connector draws power from the
( 12VOutputs )
5V SATA Power Connector draws power from the
( 5VOutputs )
6PCIe p1-x1
Connector Insert into a on thePCI Express Slot Host Computer
7SATA Power
Connector
Optional: Connect an available SATA Power Connector
from the to provide power over Host Power Supply
DB9 Pin 9
Package Contents
2S232422485-PC-CARD:
Serial Card x 1
Low-Prole Bracket x 2
Ribbon Cable x 1
Quick-Start Guide x 1
Requirements
For the latest requirements, please visit: www.StarTech.com/2S232422485-PC-CARD
Computer with an available PCI Express Slot (x1, x4, x8, or x16)
Installation
DIP Switch Settings
To change the between , , and , use the DB9 Serial Ports RS-232 RS-422 RS-485
respective located on the . enables/Serial Mode Switch Serial Card Dip Switch 3
disables a , used for impedance matching between the 120 Ω Termination Resistor
Tx+/Tx- and Rx+/Rx- (RS-422/RS-485 4-wire) and D+/D- (RS-485 2-wire) lines. The
purpose is to prevent reections on the line that may cause signal errors.
RS-232 RS-485 (Half-Duplex) RS-422/485 (Full-Duplex)
1
3
3
2
2
6
4
4
5
5
7
*2S232422485-PC-CARD shown above
PS74ADF-SERIAL-CARD:
Serial Card x 1
Low-Prole Bracket x 4
Ribbon Cable x 3
Quick-Start Guide x 1
Linux
1. Navigate to: www.StarTech.com/2S232422485-PC-CARD
2. Click the tab.Drivers/Downloads
3. Under , download the for the Linux .Driver(s) Driver Package Operating System
4. Follow the that was extracted.Linux Driver Installation Guide
Verify Driver Installation
Windows
1. Navigate to the .Device Manager
2. Under , right-click and Ports (COM & LPT) AX99100 PCIe to High Speed Serial Port
click .Properties
3. Conrm that the is installed and working as expected.Driver
Verify Driver Installation (Linux)
1. Run from the command line.lsmod | grep r8125
2. Verify that the is present in the command line. Driver
DB9 Pin Out
Pin RS-232 RS-422/RS-485 (4 Wire) RS-485 (2 Wire)
1DCD TXD- -(485)
2RXD TXD+ +(485)
3TXD RXD+ X
4DTR RXD- X
5GND GND GND
6DSR
7RTS
8CTS
9RI/PWR
Install the Card
Note: If the is to be installed into a or PCIe Card Small Form Factor Low-Prole
Desktop Full-Prole Bracket, it’s required to replace the pre-installed with the included
Low-Prole Brackets DB9 Serial Ports Ribbon Cables. The that use will need to be
installed on the separate .Low-Prole Brackets
1. Turn o the and disconnect the and any Computer Power Cable Peripheral
Devices that are connected (e.g. printers, external hard drives, etc.).
2. Remove the from the .Cover Computer Case
Note: Consult the documentation that came with the computer for details about how
to do this safely.
3. Locate an open and remove the corresponding from PCIe Slot Metal Cover Plate(s)
the rear of the . In most instances, the is attached Computer Case Metal Cover Plate
to the rear of the with a single . Save this Computer Case Phillips Head Screw
Phillips Head Screw for the next step.
4. Gently insert the into the open and fasten the to Serial Card PCIe Slot Bracket(s)
the rear of the , using the from .Computer Case Phillips Head Screw Step 4
5. (Optional) Connect from the to the SATA Power Computer Power Supply SATA
Power Connector Serial Card, located on the rear of the .
6. Replace the from the that was removed in . Cover Computer Step 2
7. Reconnect all of the that were disconnected in .Peripheral Devices Step 1
8. Reconnect the to the rear of the .Power Cable Computer
Install the Driver
Windows
1. Navigate to: www.StarTech.com/2S232422485-PC-CARD
2. Click the tab.Drivers/Downloads
3. Under , download the for Windows .Driver(s) Driver Package Operating System
4. Open the and locate the corresponding folder for theDriver Package Windows
Version.
5. Execute the to install the driver.Setup File
Regulatory Compliance
FCC - Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could
void the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer to .
www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss
of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the
product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks,
registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related
documents are the property of their respective holders. PHILLIPS® is a registered trademark of Phillips Screw Company in the
United States or other countries.
